Page 1
Halex Impact 5.0 Electronic dartboard Impact 5.0 Electronic Dartboard With Designer Mirror Cabinet Owner’s Manual And Game Instructions...
Page 2
Halex Impact 5.0 Electronic dartboard LIMITED-1 YEAR WARRANTY This Halex product is warranted to be free from defects in workmanship or materials at the time of purchase for a period of 1 (one) year. Should any evidence of defects appear within the limited warranty period after the date of purchase, Regent Sports will either send replacement parts or advise another course of action.
Page 3
Halex Impact 5.0 Electronic dartboard Setup / Mounting Instructions Choose a location to hang the dartboard where there is about 10 feet of open space in front of the board. The “toe-line” should be 7’ 9 1/4” from the face of the dartboard. Since this dartboard can be powered with the included AC adapter, you may want to mount it close to an electric outlet for convenience.
Page 4
Halex Impact 5.0 Electronic dartboard Dartboard Functions POWER button - Press to turn game on or off. Dartboard has an automatic suspend mode to conserve power and battery life (if using batteries). The dartboard will make sound effect and display “SLEEP” on the display after approximately 3 minutes of non-use. However, the scores are stored in memory and can be restored by pressing any button.
Page 5
Halex Impact 5.0 Electronic dartboard Electronic Dartboard Operation Press the POWER button to activate dartboard. A short musical introduction is played as the display goes through power-up test. Press GAME buttons until desired game is displayed (see game chart on page 16).
Page 6
This makes it easier to remove darts and extends the life of the tips. If you need to replace your AC adapter, use only a genuine Halex AC adapter (available directly from Halex) for this dartboard. Use of a non-Halex AC adapter...
Page 7
Halex Impact 5.0 Electronic dartboard Game Rules The Halex Impact 5.0 electronic dartboard is loaded with games and options. The rules for each game are detailed below in the order they appear on the display when paging through the games. The game number is indicated next to each game for your reference.
Page 8
Halex Impact 5.0 Electronic dartboard CRICKET (G02) Cricket is a strategic game for accomplished players and beginners alike. Players throw for numbers best suited for them and can force opponents to throw for numbers not as suitable for them. The object of Cricket is to “close” all of the appropriate numbers before one’s opponent while racking up the highest number of points.
Page 9
Halex Impact 5.0 Electronic dartboard NO-SCORE CRICKET (Press SELECT button when Cricket is displayed) Same rules as standard Cricket except there is no point scoring. The object of this version is to be the first to simply “close” all the appropriate numbers (15 through 20 and the bullseye).
Page 10
Halex Impact 5.0 Electronic dartboard High Score (G06) The rules for this competitive game are simple - Rack up the most points in three rounds (nine darts) to win. Doubles and triples count as 2x and 3x that segment’s score respectively.
Page 11
Halex Impact 5.0 Electronic dartboard GOLF (G08) This is a dartboard simulation of the game golf (but you don’t need clubs to play). The object is to complete a round of 9 through 18 “holes” with the lowest score possible. The Championship “course”...
Page 12
Halex Impact 5.0 Electronic dartboard given pin total: Segment Score Double 9 pins Outer Single 3 pins Triple 10 pins Inner Single 7 pins There are several rules for this game as follows: A perfect game score would be 200 in this version of bowling You cannot hit the same singles segment twice within the same “frame”...
Page 13
Halex Impact 5.0 Electronic dartboard KILLER (G12) This game will really show who your friends are. The game can be played with as few as two players, but the excitement and challenge builds with even more players. To start, each player must select his number by throwing a dart at the target area.
Page 14
Halex Impact 5.0 Electronic dartboard DOUBLE DOWN 41 (G14) This game follows similar rules as standard Double Down as described above with two exceptions. First, instead of going from 15 through 20 and bullseye, the sequence is reversed which will be indicated on the LCD display. Second, an additional round is included toward the end in which players must attempt to score three hits that add up to 41 points (20, 20, 1;...
Page 15
Halex Impact 5.0 Electronic dartboard Super Shanghai In addition, we added as a difficulty option. This game is played exactly as described above except various doubles and triples must be hit as specified by the LCD display. Adjustable Difficulty Settings for Super Shanghai include the following options:...
Page 16
Halex Impact 5.0 Electronic dartboard NINE-DART CENTURY (G20) The object of this game is to attempt to score 100 points, or come as close as possible, after 3 rounds (9 darts). Doubles and triples count as 2x and 3x their value respectively.
Page 17
Halex Impact 5.0 Electronic dartboard Electro-light Cricket Scoring Display This dartboard utilizes a dedicated cricket scoreboard within the scoring display that keeps track of each player’s segment status when playing Cricket. When Cricket is selected, individual characters will be utilized to register marks. There are 3 separate lights within each number (15 through 20 and bullseye).
Page 18
Cleaning your Electronic Dartboard Your Halex electronic dartboard will provide many hours of competition if cared for properly. Regular dusting of the cabinet is recommended using a damp cloth. A mild detergent can be used if necessary.
