- Page 1 U S E R M A N U A L HDMI-CAT-HDMI Extender Model No: HDEX007M1 Enjoy the vivid world!
- Page 2 Our series of HDMI converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient. The HDEX007M1 Extender use cat-5E or cat-6(recommended) cables up to 50 meters Single instead of HDMI cable to transmit high definition signal, for cutting down cost.
- Page 3 The accessories with the machines lists as picture： ： ： ： 1、HDMI Transmitter 1PCS 2、HDMI Receiver 1PCS 3、Windband IR Tx cable 1PCS 4、windband IR Rx cable 1PCS 5、 1PCS 5V/1A power adapter 6、 1PCS User manual Physical Connection Showing Picture： ： ： ： Picture1.0 Transmitter Port Showing Picture HDMI In: HDMI Signal Input Port EDID:...
- Page 4 CAT： RJ45 Port: it can use one standard cat cable to connect the transmitter with the receiver. : Power Led Light: it will go bright when power is connected. DC 5V: 5V DC Port Picture 1.1 Receiver Port Showing Picture EQ：Equalizer Switch EQ Set-Up Tips Position...
- Page 5 IR Extender Function Introduction 1、30KHz-50KHz Wide-band IR Frequency Support Range:30 KHz-50 KHz 2、To insert the TX IR Blaster Cable to the IR OUT port and put the IR Head at the front of the 3、To use the RX IR Receiver Cable to the IR IN Port and use the Remote to point at the IR Receiver Head to do control and can transmit the IR signal to the RX IR Cable by cat cable.
- Page 6 4. To use one cat 5e or cat 6 cable to connect the transmitter with the receiver( the cat cable length can be up to 50m) 5. connect the 5V power adaptor to the extender SPECIFICATIONS: HDEX007M1 Length of CAT-6 cable between Rx and TX ..Up to 50 meters...
- Page 7 HDMI Input ... 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i HDMI Output ..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Max bandwidth 165MHz Max baud rate 4.95Gbps Input Video signal 0.5~1.5Volts p-p Output DDC signal 5Volts p-p (TT1L) Input/Output HDMI cable distance ...≤5m AWG26 HDMI standard cable Max working current ...600mA Power adapter format..Input: ...AC (50HZ, 60HZ) :100V-240V;...
- Page 8 are normally connected. The common trouble shooting way shows below: Trouble Serial NO Cause and Ways to deal with Description 1 、 Check if the power adaptor head is truly and Non-Power- correctly inserted the power socket. Connected 2、Check the power switch if it is in on status. 1、Pls to make sure that the TV is on and has been connected with the machine.
