Summary of Contents for TX HDBaseT
- Page 1 User Manual HDMI HDBaseT 4K Transmitter (TX) All Rights Reserved...
- Page 2 HDMI HDBaseT 4K Transmitter (TX) Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till June 20, 2017.
- Page 3 HDMI HDBaseT 4K Transmitter (TX) SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...
-
Page 4: Table Of Contents
HDMI HDBaseT 4K Transmitter (TX) Table of Content 1. Introduction ......................... 1 1.1 Features ......................1 1.2 Package Contents ..................... 1 2. Panel Description ......................2 3. System Connection ..................... 3 3.1 Usage Precaution ....................3 3.2 System Diagram ....................3 3.3 Connection Procedure .................. -
Page 5: Introduction
HDMI HDBaseT 4K Transmitter (TX) 1. Introduction The HDMI HDBaseT 4K Transmitter (TX) is used to transmit high-resolution 1080p/ 4k signal from transmitter to a receiver via a CAT5e/CAT6a cable at a distance of up to 70/40m.Moreover, it supports CEC, bi-directional RS232&IR control, and bi-directional PoH function. -
Page 6: Panel Description
HDMI HDBaseT 4K Transmitter (TX) 2. Panel Description Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ② HDCP GREEN: Traffic with HDCP ... -
Page 7: System Connection
HDMI HDBaseT 4K Transmitter (TX) 3. System Connection 3.1 Usage Precaution System should be installed in a clean environment and has a prop temperature and humidity. All of the power switches, plugs, sockets and power cords should be insulated and ... -
Page 8: Twisted Pair Cable Connection
HDMI HDBaseT 4K Transmitter (TX) Step4. Both transmitter and receiver have IR IN and OUT. When one end is used as an IR receiver, the signal sent from the end can only be transmitted via the other end. For example: When “IR IN” of transmitter connects with an IR receiver, the IR emitter must connect to IR OUT of Receiver. -
Page 9: Specification
(1) Female HDMI; (1) 3.5mm mini jack; Input Connector (1) 3p captive screw connector Digital audio, transmit through HDMI audio Audio Output (1) HDBaseT (1) IR; (1) RS232 (1) RJ-45; (1) 3.5mm mini jack; (1) 3p captive screw Output Connector connector General Resolution Range 640x480@60Hz~4K×2K@30Hz... -
Page 10: Panel Drawing
HDMI HDBaseT 4K Transmitter (TX) 5. Panel Drawing LINK HDCP RS232 IR IN IR OUT HDMI IN HDBT OUT DC 24V 115 mm... -
Page 11: Troubleshooting & Maintenance
Ensure proper grounding of the power supply. Known issues with HDMI 1.2 source devices: Older compatibility (HDMI 1.2) may result in HDBaseT transmission issues. Please contact Technical Support of your director for a solution to these issues. -
Page 12: Customer Service
HDMI HDBaseT 4K Transmitter (TX) 7. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
