Page 1
Installation Instructions CAUTION Read this document before installing the snowplow. CAUTION See your sales outlet/website for specifi c vehicle application recommendations before installation. The online selection system has specifi c vehicle and snowplow requirements. A DIVISION OF DOUGLAS DYNAMICS, LLC...
33230 SAFETY DEFINITIONS WARNING/CAUTION & INSTRUCTION LABELS WARNING Become familiar with and inform users about the Indicates a potentially hazardous situation warning and instruction labels on the back of the that, if not avoided, could result in death or blade.
33230 SAFETY PRECAUTIONS PERSONAL SAFETY Improper installation and operation could cause • Remove the ignition key and set the vehicle personal injury and/or equipment and property damage. parking brake to prevent others from starting the Read and understand labels and the Owner's Manual vehicle during installation or service.
33230 NOISE TORQUE CHART Airborne noise emission during use is below 70 dB(A) CAUTION for the snowplow operator. Read instructions before assembling. Fasteners should be fi nger tight until VIBRATION instructed to tighten according to the torque chart. Use standard methods and practices...
33230 INSTALLATION INSTRUCTIONS 2. Remove the exhaust defl ector; save for reinstallation. NOTE: For easier assembly and installation, the vehicle and all snowplow components should be on a smooth, level, hard surface, such as concrete. 1. Detach the loader from the vehicle, if equipped, then remove the brush guard.
Page 6
33230 4. Place a 1/2" washer on a 1/2" x 2" cap screw. 5. Repeat Steps 3 and 4 on the opposite side of the Install the cap screw and washer through the vehicle. location shown. Secure the fastener with a 1/2"...
Page 7
33230 For vehicles with existing holes in the frame: CAUTION 6. Place the left thrust arm against the frame of the Before drilling holes, check to be sure that no vehicle as shown. Install two 1/2" x 2-1/2" cap vehicle wiring or other components could be screws through the thrust arm, frame, and hanger.
Page 8
33230 For vehicles without existing holes in the frame: CAUTION Before drilling holes, check to be sure that no 6. Place the left thrust arm against the frame of the vehicle wiring or other components could be vehicle as shown. Ensure that the bottom stop of the damaged.
Page 9
33230 12. Install the cross bar using four 1/2" x 1-1/2" cap All vehicles: screws. Secure with 1/2" washers and 1/2" locknuts. 11. Reinstall the exhaust defl ector by attaching a shield bracket to each of the defl ector connector 13.
Page 10
33230 The company reserves the right under its product improvement policy to change construction or design details and furnish equipment when so altered without reference to illustrations or specifi cations used. This equipment manufacturer or the vehicle manufacturer may require or recommend optional equipment for snow removal.
