INSTALLATION GUIDE

FS-DUO

Wastewater Sampling Port

Contents

Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Getting to Know the FS-DUO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Buried Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6

On the Floor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

On the Floor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Part #: 8070-011-02

Find these instructions online at: schierproducts.com/fs-duo

Table of Contents

Need help?

Do you have a question about the FS-DUO and is the answer not in the manual?

Questions and answers

Summary of Contents for Schier Products FS-DUO

Page 1 Special Precautions .........2 Getting to Know the FS-DUO ....... .3 Buried Installation .
Page 2 A concrete slab to finished grade with rebar is required when INSTALLATIONS installing interceptor below grade. Rebar 4" min. slab Rebar 8" min. slab Pedestrian Traffic or Vehicular Traffic Areas Greenspace Areas THE FS-DUO MUST BE INSTALLED LEVEL TO FUNCTION PROPERLY FS-DUO Installation Guide page 2 of 8...
Page 3 GETTING TO KNOW THE FS-DUO Pickable Cast Iron Cover (standard) 7. Flow Distributor Body 13. Inlet Diffuser Retaining Nut 2. Cover Gasket 8. Bulkhead Connection Retaining Nut 14. Inlet Bulkhead Connection 4" FPT 3. Safety Star 9. Bulkhead Connection Gasket 15.
Page 4 Lay a level bed of well-packed, crushed aggregate Excavate hole at least 12" larger than sampling port (approximately 3/4" size rock or sand, with no fines) on all sides and 6" deeper than port bottom. in the base of hole. FS-DUO Installation Guide page 4 of 8...
Page 5 Wet or Air Test Piping Per Local Code Have a Leak? Call customer DO NOT AIR TEST UNIT OR RISER SYSTEM! care at 913-951-3300 Doing so may result in property damage, personal injury or death. Hours 8am-5pm CST, M-F FS-DUO Installation Guide page 5 of 8...
Page 6 BURIED INSTALLATION Bring Cover Flush-to-Grade The FS-DUO is ready for burial depth of 22" from finished grade to bottom of unit (or 13-1/2" to centerline of inlet). Deeper burials will require extending the Cover Adapter and possibly adding risers. Measure dimension X to determine riser height needed.
Page 7 Wet or Air Test Piping Per Local Code Leak? Call customer care at DO NOT AIR TEST UNIT OR RISER SYSTEM! 913-951-3300 Doing so may result in property damage, personal injury or death. 8a – 5p M – F CST FS-DUO Installation Guide page 7 of 8...
Page 8 INSTALLATION DETAILS Parallel Installations For ﬂow rates above 100 GPM and higher grease storage requirements the FS-DUO flow distributor must be piped in parallel with two grease interceptors as shown to ensure the system works properly as designed. Units must be equally spaced to ensure equal effluent ﬂow distribution.
