START-UP
Battery
The system is powered by 1 7.2V Lithium-Ion battery,
with an approximate autonomy of +8 hours in basic
mode.
The battery must be inserted by sliding it through the
flap. To extract the battery, press on lower flap, sliding
the battery in the opposite direction.
Become familiar with the Settop
CellXtrem
LED Battery
Off
On
LED Signal
Flash
Steady
LED Client (Rover)
Off
On
LED Server (Base)
Off
On
BASE port
(Correction input)
SIM Card slot
GUIA DE INICIACIÓN
Battery OK
Battery low
Coverage OK
No coverage
Not connected
Connected
Not connected
Connected
RADIO/ROVER port
(Correction output)
