Table 2: Termination details
Type of Input/
Type of field device
Output
Voltage Input - Internal
UI
Source
Voltage Input (Self-
UI
Powered)
Temperature Sensor
UI
Dry Contact
UI
0–10 VDC Output to
Actuator (Internal
CO
Source)
0–10 VDC Output to
Actuator (External
CO
Source)
Termination diagrams
VMA1826/1832 VAV Controller Installation Guide
