- Page 1 K I M O INSTRUCTION MANUAL 23802 20V Max Cordless Compact Reciprocating Saw www.kimotool.com If you have questions or comments, contact us. Kimo-support@kimotools.com...
-
Page 2: Work Area
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS OR ANY KIMO TOOL, EMAIL US AT: Kimo-support@kimotools.com General Safety Rules - For All Tools WARNING! Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire or serious personal injury or property damage. - Page 3 Stay alert, watch what you are doing and use common • sense when operating a power tool. Do not use tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury.
- Page 4 that cannot be controlled with the switch is dangerous and must be repaired. Store idle tools out of reach of children and other • untrained persons. Tools are dangerous in the hands of untrained users. Maintain tools with care. Keep cutting tools sharp and clean. •...
- Page 5 ADDITIONAL SPECIFIC SAFETY INSTRUCTIONS Hold power tool by insulated gripping surfaces, when • performing an operation where the cutting accessory may contact hidden wiring. Cutting accessory contacting a “live” wire may make exposed metal parts of the power tool “live” and could give the operator an electric shock.
-
Page 6: Tool Components
7. Battery Slide Button 4. Hand Grip 8. Battery ACCESSORIES 1. Cordless Reciprocating Saw 4. 1-hour Fast Charger 2. 3 × Wood Blades 5. KIMO Battery 3. 3 × Metal Blades SPECIFICATIONS Model 23802 Stroke Length 20mm No Load Speed... -
Page 7: Installation
INSTALLATION INSTALLING OR REMOVING BLADE WARNING: To reduce the risk of serious personal injury, turn unit off and remove the battery pack before making any adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury. Different blade lengths are available. Use the appropriate blade for the application. -
Page 8: Operation
OPERATION WANGING: This reciprocating designed professional • sawing applications. DO NOT use under wet conditions or in presence of flammable liquids or gases. This reciprocating saw is a professional power tool. DO NOT let • children come into contact with the tool. Supervision is required when inexperienced operators use this tool. - Page 9 CAUTION: Use of very slow speed is recommended only for beginning a cut. Prolonged use at very slow speed may damage your saw. CUTTING WARNING: Always use eye protection. All users and bystanders must wear • eye protection. Exercise extra caution when cutting towards operator. Always •...
-
Page 10: Maintenance
REPAIRING WARNING: To assure product SAFETY & RELIABILITY, repairs, maintenance and adjustment (including brush inspection and replacement) should be performed by a KIMO factory service center or a KIMO authorized service center. Always use identical replacement parts. -
Page 11: Battery Instructions
BATTERY INSTRUCTIONS CAUTION: Only use genuine KIMO batteries. Use of non-genuine KIMO batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the KIMO warranty for the KIMO tool and charger. - Page 12 INDICATING THE REMAINING BATTERY CAPACITY Battery Pack LED Indicator KIMO battery packs include a fuel gauge which consists of four LED lights that indicate the level of charge remaining in the battery pack.The fuel gauge is an indication of approximate levels of charge remaining in the battery pack according to the following indicators: NOTE: 1.
- Page 13 Charging Indicator NOTE: It takes 1-2 hours to full charge KIMO battery.
-
Page 14: Warranty
WARRANTY Every KIMO power tool is warranted to the original purchaser only to be free from defects in material and workmanship. Subject to certain exceptions, KIMO will replace any part on an electric power tool that is defective in material or workmanship for a period of 2 years after the date of purchase unless otherwise noted.
