Northern 168618 Assembly And Operation Instructions

Deluxe Stainless Electric Meat Grinder (#168618)
Assembly and Operation Instructions
For technical questions and replacement parts, please call 1-800-556-7885.
Thank you very much for choosing a NORTHERN TOOL & EQUIPMENT CO.,
Product! For future reference, please complete the owner's record below:
Model: _______________
Save the receipt, warranty and these instructions. It is important that you read the
Entire instruction sheet to become familiar with this product before you begin using it.
The Electric Meat Grinder is part of a range of well designed appliances which will make
life easier for you. Ideally used at restaurant, refectory, and private dining room, etc. All
stainless structure provides a quite easy way to cleaning and maintenance.
Before using this Stainless Electric Meat Grinder, please read the following instructions
carefully.
Power Supply: AC110V, 60HZ
Power : 1000W
Capacity : 480 lbs. of meat per hour!
Dimension : 16-1/8"*9-3/8"*17-3/4"
Weight : 77lbs
1. Unplug when assembling or disassembling the unit.
2. Close supervision is necessary when any appliance is used near children
3. When carrying the unit, be sure to hold Motor Housing with both hands, not to hold
only Hopper plate.
4. Never feed food with hands. Always using Food Pusher.
5. Don't grind hard foods such as bones and nuts.
6. Don't disassemble the grinder or place anything(especially finger , spoon, fork, etc.)
in the grinder during operation.
7. Avoid contacting moving parts. Never feed food by hand. Always use food pusher.
2800 Southcross Drive, West. P.O. Box 1219. Burnsville, MN 5537-0219
Purchase Date: _______________

Technical Specifications

Warning and Precaution

Page: 1 of 4
Phone 612-894-9510. Fax: 612-894-1020
