Summary of Contents for Aristel AN-P28
- Page 1 4G LTE AN-P28 Quick Installation Guide...
- Page 2 Overview...
- Page 3 Indicators Type Status Description RSSI signal strength No signal 4G/LTE disconnected or SIM is not ready Blue 4G/LTE connected Blue WPS function open Flicker WPS client connecting WPS function closed Blue Wi-Fi open...
- Page 4 Wi-Fi off. Blue In use Idle Blue Battery normal Yellow Low battery BATTERY No battery Blue AC adapter connected ADAPTER AC adapter disconnected Blue Power on Power off...
- Page 5 Interface Interface Description 1. Phone Port Connect to telephone or alarm system. 2. Battery Interface Slide off the cover and install the battery, then close the cover. 3. LAN Port Connect to PC/laptop through Ethernet cable. 4. USB Only for firmware upgrading. 5.
- Page 6 Slide off the cover and install the external antenna. Interface 8. Power Switch Press this button to power on or off the AN-P28. 9. WPS Button Press this button to wait for WPS connection from WPS client. 10. Reset Button Press and hold for about 3-4 seconds to restore the default settings.
- Page 7 If the signal is poor when using built-in antenna, install an external antenna • If required, connect telephone/alarm system to phone port through RJ11 cable. • Installing the battery. • Connecting the AC adapter to DC power interface. • Press the power switch to power on the AN-P28.
-
Page 8: Setting Up An Ethernet Connection
2. Setting up an Ethernet Connection Connect your PC, laptop, or SIP server to LAN port through Ethernet cable for wired internet access. For multiple SIP lines use a SIM with static IP address. Note. Ensure that the network connection on your PC or laptop is configured as Obtain IP address and DNS server address automatically. - Page 9 Press Edit to see the Wi-Fi Key as shown below Method 2: Setting up a Wi-Fi connection through WPS If the device supports WPS, you can set up a WPS connection as follows: Ensure that Wi-Fi is switch on and WPS function is enabled. Press the WPS button, and then WPS indicator will starts blinking.
- Page 10 Web-based Configuration 1. Accessing the Configuration Page Make sure the connection between your device and the client is active. Launch the Internet browser and enter http://192.168.0.1.The user name is admin and password is admin. For logging into the WEB Configuration Page, proposed browsers are as follows :...
- Page 11 ● at least IE 7.0 ● at least Firefox 3.0 ● at least Safari 4.0 ● at least Opera 10.0 ● at least Chrome 10.0 2. Settings Changing SSID and Wi-Fi Key 1. Select WLAN Configure > Basic Settings 2.
- Page 12 WPS Settings 1. Select WLAN Configure >WPS Settings 2. Select Enable(Enabled by default) 3. Press Apply Static IP 1. Select Route Function > Static IP 2. Press Add Entry, and input the MAC and IP you want to bind. 3.
- Page 13 Do not dismantle the device and it's accessories as this voids the warranty of the device. The device is for indoor use only. Do not use it outdoors. SIM card with Static IP required E.&O.E. www.aristel.com.au...
