Summary of Contents for Twin-Star International TCS54-6127

  • Page 1 TCS54-6127...
  • Page 2 REGISTER ENREGISTREMENT REGISTRAR LA INFORMACIÓN PRODUCT INFO INFO PRODUIT DEL PRODUCTO INFO Thank you for purchasing our Merci d’avoir acheté ce produit. Gracias por comprar nuestro Veuillez prendre un moment pour producto. Tómese un momento product. Please take a moment inscrire votre nouvel achat à...
  • Page 3 PRODUCT DETAILS AND NOTES DÉTAILS ET NOTES DU PRODUIT/DETALLES DEL PRODUCTO Y NOTAS Place of purchase/Lieu de l’achat/Lugar de compra: Date of purchase/Date de l’achat/Fecha de compra: Model #/No de modèle/Número de modelo: Notes/Remarque/Notas: TCS54-6127REV1.0...
  • Page 4 SAFETY INFORMATION INFORMACIÓN DE INFORMATION DE SÉCURITÉ SEGURIDAD Please read and understand this Assurez-vous de lire et de comprendre Lea y comprenda completamente entire manual before attempting l’intégralité du présent manuel avant este manual antes de intentar to assemble, operate or install the de tenter d’assembler, d’utiliser ou ensamblar, usar o instalar el product.
  • Page 5 TCS54-6127REV1.0...
  • Page 6 MAXIMUM LOAD 13.6 kg / 30 lb CHARGE MAXIMALE DE 13.6 kg / 30 lb MAXIMUM LOAD CARGA MÁXIMA 34 kg / 75 lb 13.6 kg / 30 lb CHARGE MAXIMALE DE 47.6 kg / 105 lb CARGA MÁXIMA 47.6 kg / 105 lb MAXIMUM LOAD MAXIMUM LOAD 15.9 kg / 35 lb...
  • Page 7 HARDWARE/QUINCAILLERIE/FERRETERÍA [x45] [x45] [x38] [x4] [x40] Ø8x30mm Ø3x12mm PH-KDBBLK001 PH-KDCBLK001 PH-DWLNTL001 Ø6.3x25mm PH-SCRBLK007 [x2] [x2] [x20] [x4] [x6] Ø4x50mm Ø3.5x15mm PH-SPNPCSPLB2 PH-SCRBLK006 PH-SCRNKL008 PH-BDGBLK001 Stop Block [x2] [x14] [x8] [x4] [x8] Ø6.3x12mm PH-BKTWHT003 Plastic Cover Ø15mm Barn Door Roller PH-BLTBLK002 TCS54-6127REV1.0...
  • Page 8 [x4] [x4] [x4] TCS54-6127REV1.0...
  • Page 9 [x4] [x4] TCS54-6127REV1.0...
  • Page 10 [x6] [x8] TCS54-6127REV1.0...
  • Page 11 [x6] [x6] [x4] TCS54-6127REV1.0...
  • Page 12 [x4] [x12] TCS54-6127REV1.0...
  • Page 13 [x2] [x2] TCS54-6127REV1.0...
  • Page 14 [x2] [x2] TCS54-6127REV1.0...
  • Page 15 [x6] [x12] TCS54-6127REV1.0...
  • Page 16 [x4] TCS54-6127REV1.0...
  • Page 17 TCS54-6127REV1.0...
  • Page 18 [x2] TCS54-6127REV1.0...
  • Page 19 [x10] [x12] TCS54-6127REV1.0...
  • Page 20 [x12] [x8] TCS54-6127REV1.0...
  • Page 21 [x8] [x4] [x8] TCS54-6127REV1.0...
  • Page 22 TCS54-6127REV1.0...
  • Page 23 [x2] [x6] TCS54-6127REV1.0...
  • Page 24 [x2] [x4] TCS54-6127REV1.0...
  • Page 25 [x38] TCS54-6127REV1.0...
  • Page 26 [x16] [x3] TCS54-6127REV1.0...
  • Page 27 [x2] [x2] TCS54-6127REV1.0...
  • Page 28 [x4] TCS54-6127REV1.0...
  • Page 29 [x2] Wall Stud Poteau Mural Montante De Madera Warning: You must install the tip restraint hardware to help prevent any accidents or damage to the unit. We strongly recommend attaching the tip restraint hardware to a wall stud and your unit. For all other wall types, please visit your local hardware store to obtain the proper hardware.
  • Page 30 CARE / SOIN / CUIDADO / MAINTENANCE ENTRETIEN MANTENIMIENTO Care and Maintenance Soin / Entretien Cuidado / Mantenimiento • Use a soft, clean cloth that will not • Lors de l’époussetage, utilisez • Use un paño suave y limpio que no scratch the surface when dusting.
  • Page 31 INSTALLED REPLACEMENT PARTS TCS54-6127 PIÈCES DE REMPLACEMENT INSTALLÉES TCS54-6127 PIEZAS DE REPUESTO INSTALADAS TCS54-6127 [x4] PH-GLDBRW001 TCS54-6127REV1.0...
  • Page 32 Sound System: TS-1806 PRODUCT SPECIFICATIONS Adapter Input AC100-240V, 50/60Hz Adapter Output DC15V 2.5A Power Consumption 30 Watts Standby Power Consumption < 1 W WIRING 1. AUDIO INPUT R/L - RCA (not included) plug AUX IN for connecting to an audio source 2.
  • Page 33: Operation

    OPERATION POWER The POWER button supplies power to all of the functions of the sound system. The POWER button will put the sound system in a standby mode. CLOCK Manual Time Set: Hold "clock" for 3 seconds until the hour digits flash. Press the "+ / -"...
  • Page 34: Learning Function

    OPERATION Learning Function The learning function allows your Sound System to be controlled by your TV remote control (Note: Remote must send infrared signals). Any unused button on your TV remote control can be used to control the Sound System. For example, when you connect your TV to the Sound System using the RCA Stereo cables or Digital Fiber Optic Cable, the TV volume and mute will no longer be controlled by the remote that came with it.
  • Page 35: Troubleshooting

    CONTROLS - Power / Standby - Display time CLOCK CLOCK - Mute ® - Bluetooth BLUE BLUE LINE IN OPTICAL - Line in LINE IN - Optical in OPTICAL - Back (Previous) - Play/Pause - Forward (Next) TREBLE VOLUME BASS - Adjust Treble TREBLE - Adjust Bass...
  • Page 36: Care And Maintenance

    CARE AND MAINTENANCE Warning: 1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 2. Only a qualified service person should repair this product. 3.
  • Page 37: Year Limited Warranty

    1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Media Console with Sound Bar is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this Media Console with Sound Bar in accordance with the installation and operating instructions furnished with the product at all times.
  • Page 38 Sistema de Sonido: TS-1806 Especificaciones de Producto Entrada de Adaptador AC100-240V, 50/60Hz Salida de Adaptador DC15V 2.5A Consumo Eléctrico 30 Watts Consumo Eléctrico en Espera < 1 W Cableado (no incluido) 1. ENTRADA DE AUDIO R / L - Enchufe de RCA EN AUX para conectar a una fuente de audio.
  • Page 39: Operación

    Operación Encendido El botón de ENCENDIDO suministra corriente a todas las funciones del equipo de sonido. El botón de ENCENDIDO pondrá el sistema de sonido en modo de espera. RELOJ Ajuste Manual del Reloj: Pulse "clock" durante 3 segundos hasta que los dígitos de la hora parpadeen. Pulse el botón "+ / -"...
  • Page 40: Función De Aprendizaje

    Operación Función de aprendizaje La función de aprendizaje permite su sonido estante para ser controlado por el control remoto de la TV (Nota: Remote debe enviar señales de infrarrojos).Cualquier resto de botón en el control remoto de la TV se puede utilizar para controlar el sonido estante.Por ejemplo, cuando se conecta a tu TV a la estante de sonido utilizando los cables de RCA estereo o digital de TV cable de fibra óptica el volumen y muto ya no estará...
  • Page 41: Guía Para Solución De Problemas

    Controles - Encendido / En espera - Muestra la hora CLOCK - Silencio CLOCK - Bluetooth BLUE - línea en OPTICAL BLUE LINE IN LINE IN - óptico OPTICAL - Volver (Anterior) - Reproducir / Pausa - Avanzar (Siguiente) TREBLE VOLUME BASS - Ajuste de agudos...
  • Page 42: Cuidado Y Mantenimiento

    Cuidado y Mantenimiento Advertencia: 1. Si el cable de alimentación está dañado, deberá ser reemplazado por el fabricante, el agente de servicio o por personal cualificado con el fin de evitar un peligro. 2. Sólo un técnico calificado debe reparar este producto. 3.
  • Page 43: Garantía Limitada De 1 Año

    GARANTÍA LIMITADA DE 1 AÑO El fabricante garantiza que el Consola de Comunicación con Barra de Sonido está libre de defectos de fabricación y materiales por un período de un año desde la fecha de compra, sujeto a las siguientes condiciones y limitaciones.
  • Page 44 Si vous n’êtes pas en mesure d’effectuer l’enregistrement, conservez votre preuve d’achat pour le remplacement de pièces. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. © 2018, Twin-Star International, Inc. Delray Beach, FL 33445 Made in China TCS54-6127REV1.0 MP#VR...
