Step 5: Attach the back cushion to the pre-drilled holes using four (B) bolts, The metal back bar
frame will overlap on the seat plate.See detailed diagram below. Tighten all bolts fully with the
wrench (G).
Diagram
Back bar will overlap seat plate metal when aligning to holes.
7
G
B
