Summary of Contents for Countryman H7
- Page 1 COUNTRYMAN H7 HEADSET...
-
Page 2: Table Of Contents
Contents The H7 Headset Microphone Microphone Care Fitting the H7 Headset Positioning the Microphone Switching the Microphone Side Snap-On Cables Water-Resistant Windscreen Collar Clips Accessories and Replacement Parts Declarations... - Page 3 Thanks for choosing the Countryman H7 Headset. ur toughest directional microphone yet, the precision side-address pattern of the H7 captures your performance and shuts out feedback and surrounding noise. This booklet describes how to use and protect your H7 to get the best performance.
-
Page 4: Microphone Care
Microphone Care The H7 Headset is designed for exceptional audio clarity and durability. Following some basic guidlines will ensure you get maximum performance from your H7 Headset for years to come: • Avoid touching the end of the capsule with fingers or obstructing the mesh opening with foreign substances. -
Page 5: Fitting The H7 Headset
You may need to take the headset off momentarily to slide the boom exactly If the H7 feels loose on the head, slide the where you want it, then put the headset earwires back to tighten the fit. -
Page 6: Positioning The Microphone
Positioning the Microphone The capsule should rest on or just off the To avoid breath noise, you may wish to position the skin and about 0.25” to 0.5” back from the microphone slightly below the mouth line. corner of your mouth when smiling. We recommend that you use the windscreen to address wind noise. - Page 7 Positioning the Microphone (cont.) If the capsule is too far back, If the capsule is too far forward, Be careful not to press the tip you will not get the maximum you will get breath pops. of the mic into your cheek, as isolation from your microphone.
-
Page 8: Switching The Microphone Side
Switching the Microphone Side The mic boom detaches from the frame and Unclip the boom from Tip the boom to remove can switch to either the left or right side: first, the clips along the back it from the hooks on the remove the boom as shown to the right. -
Page 9: Snap-On Cables
Snap-On Cables Press the H7 Snap-On Cable firmly into the boom The H7 Snap-On Cable The H7 Cable uses connector until there is no visible gap. The connector will is tightly-sealed against Aramid strength members not release accidentally. moisture and dust. -
Page 10: Water-Resistant Windscreen
The H7 Headset includes a water- resistant windscreen coated with a superhydrophobic nanocoating to repel water and sweat. This coating is robust but may lose some of its properties after repeated washing. Use only soap and water when cleaning the H7 windscreen. -
Page 11: Collar Clips
Collar Clips The H7 Headset includes two collar clips— one black, and one white—that provide strain relief for the cable. By using a collar clip, even if your mic cable gets tugged, the mic itself will remain securely in place on your head. -
Page 12: Accessories And Replacement Parts
Accessories and Replacement Parts Accessory Name 1 H7 Collar Clip 2 H7 Snap-On Cable 3 H7 Headframe 4 H7 Back Mic Clip 5 H7 Front Mic Clip 6 H7 Mic Boom... -
Page 13: Declarations
Declarations We, Countryman Associates Inc., declare under our sole responsibility that the following product: H7 Headset To which this declaration relates is in compliance with the essential requirements of: RoHS 2004/108/EC EN 55103-1 EN 55103-2 2002/96/EC WEEE 2003/108/EC 2011/65/EU RoHS... - Page 16 Countryman Associates, Inc. 195 Constitution Drive, Menlo Park, CA 94025 Phone: (800) 669-1422 or (650) 364-9988 Fax: (650) 364-2794 Email: sales@countryman.com Web: www.countryman.com...
