GPSWOX CCTR-700 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CCTR-700 GPS TRACKER USER MANUAL
Welcome to use this GPS tracker CCTR-700. It has many new functions, such as
recording tracking, uploading history tracking to website, uploading current
location to website, locating immediately and sending SMS with latitude and
longitude, built in shock sensor to control power saving, object shock & move
alarm, over area alarm, over speed alarm, emergency help etc.
Many specifications are special, such as free uploading history tracking, google
map link SMS locate, waterproof, magnetic pin, shock sensor control power
saving, long battery life(10-15 days, standby mode), etc.
It can be used as tracking cars, company vehicles, buses, taxis, trucks, elders,
children, outside workers, travelers, explorers, overlanders, pets, moving
equipments, transportations, criminals etc.
This product is with GPS module and GSM module. The user can call the tracker
with mobile phone and then the tracker will automatically hang up the call. When
the GPS module received the GPS signal, it will get the latitude and longitude, and
then upload the location to our website through GPRS or send the information
(latitude, longitude, speed, battery, time etc) to the caller by SMS. The user can
visit our free website
information, then the location will be displayed on the map(It is unnecessary for
the user to download any software, but certainly the user can change the map to
satellite earth map or flat map); or the user can visit our free register website
www.followmegps.net
product to register on the website). To sign in, the user can upload the tracking to
the website, and also can display the tracking on the map, which is completely
free, but only available to the products from our company.
Service charge is not necessary for this product, and the only charge is the SMS
sending charge or GPRS data charge without voice talking charge and service
charge for which the charge is very low to the user. The user can use the GSM
prepaid phone card, which needs SMS, incoming caller ID display and GPRS
function (If the user needs to upload the tracking through GPRS).
Our free latitude and longitude located map website:
www.followmegps.com
to register personal name (Use the serial number of the
and input the latitude and longitude

Advertisement

loading
Need help?

Need help?

Do you have a question about the CCTR-700 and is the answer not in the manual?

Questions and answers

Summary of Contents for GPSWOX CCTR-700

  • Page 1 CCTR-700 GPS TRACKER USER MANUAL Welcome to use this GPS tracker CCTR-700. It has many new functions, such as recording tracking, uploading history tracking to website, uploading current location to website, locating immediately and sending SMS with latitude and longitude, built in shock sensor to control power saving, object shock & move alarm, over area alarm, over speed alarm, emergency help etc.
  • Page 2 http://www.followmegps.com Our free uploading tracking and displaying map website: http://www.followmegps.net Google earth down load website: http://earth.google.com Packing list GPS tracker, car charger, USB charger wire, manual. USB Charging Wire Car Adapter Before Using At first to buy a GSM phone SIM card, which needs SMS service and incoming caller ID display function (If you’d like to upload the tracking, the card should enable GPRS function), and then to install the card to the tracker, in which, the SIM card phone number is the very tracker number and all the operations (calling and sending SMS) to...
  • Page 3 Pulling out the long narrow rubber stopple beside the tracker, you can see the SIM card socket, beside which, press the yellow switch point with a tool and then the holder will come out. Pull it out and put the SIM card in the holder and then push the holder into the tracker, (Pay attention to that the SIM card metal contact pin can not face down to the holder) at last push the long narrow rubber stopple into the tracker to cover the SIM card socket.
  • Page 4 hours to finish the recharging. When the battery is low, the GREEN LED on tracker will flash three times, and then the tracker will automatically send battery low information to the first preset phone number. When the battery voltage is too low, the tracker will power off automatically but when you recharge the tracker, it will power on automatically.
  • Page 5 water. 9. Shock Sensor Control Power Saving This tracker built in shock sensor, user can enable SHOCKCONTROL function, then the shock sensor can trigger GPS ON or OFF, then when the tracker is not moving, the GPS will turn off, this can make the battery life longer. 10.
  • Page 6 password to tracker also can trigger locate immediately. Report location by Google map link mode: Use preset phone call the tracker, after ring 3 times, the tracker will hang up the call automatically, the tracker will locate immediately, about 30 seconds, the tracker will send the information (including a Google map link and speed battery time etc, ) of current location to the caller by SMS, user can visit click the link to visit google map website to locate current location on google map by using a smart phone, if the GPS signal is too weak...
  • Page 7 Start/Stop Record tracking: The upload tracking mode setting is just a phone calling trigger mode setting, it will not start to record tracking, user need sending a SMS to tracker to start record tracking and stop record tracking, please note that: when start record tracking, the GPS will power on continuously (STANDBY mode), this will reduce the battery life to 1-2 days, and the capacity of record point is 32768, when the memory is full, it will overwrite the early data.
  • Page 8 will not reduce battery power. Over Area Alarm (Electronic Geo-force): Can set 2 point, the tracker will check every 5 minutes, if the tracker go out the rectangle area of the 2 point, the tracker will send alarm information by SMS to the phone who enable the over area alarm, including the latitude longitude speed battery time etc, please noted that, this mode maybe cost a lot of SMS charge and battery if the object is out of the area.
  • Page 9 number location, every tracker have is 3 preset phone number location, A , B and C, so you can preset 3 phone number, if the add operation is success, the tracker will send back the information ”Add Preset Phone OK”, if the command or password is not right, the operation is fault, the tracker will send back information “Bad Command ”...
  • Page 10 “Password：888888”; “888888”is an example. Note: Only preset phone can check the password. Set Langue: Send SMS “ENGLISH*123456” to the tracker, “ENGLISH” is a command, “123456” is password; if the operation is success, the tracker will send back the information “ Set Langue to English” , If the command or password is not right, the operation is fault, the tracker will send back information “Bad Command ”...
  • Page 11 The first line is the latitude of the tracker. The second line is the longitude of the tracker. The third line is the speed of the tracker (the speed maybe is not zero if the object is not moving because of the GPS precision) The fourth line is the direction of the tracker( It is the direction of the tracker moving to, from the north it is 0, and the east is 90, and the south is 180, and the west is 270, full circle is 360, it is clockwise, the direction maybe is not right...
  • Page 12 the information “ Set Report Mode to Google Map Link” , if the command or password is not right, the operation is fault, the tracker will send back information “Bad Command ” or “Wrong Password”. 2. Under this report mode, using preset phone call the tracker, after ring 3 times, the tracker will hang up the call automatically and locate immediately, about 30 seconds, the tracker will send back the SMS location information (Google map link and speed battery time etc) of current location to the caller.
  • Page 13 Send SMS “UPLOADMODE*123456” to the tracker, “UPLOADMODE” is a command, “123456” is password; if the operation is success, the tracker will send back the information “ Set Report Mode to Upload Current Location” , if the command or password is not right, the operation is fault, the tracker will send back information “Bad Command ”...
  • Page 14 name, if the serial number is used by other people, please contact us to delete the user name. When user sign in the website, click on the tracking display menu, the display location is the latest location of the tracker. Sending SMS to Trigger Uploading Current Location: Suit for internet user Send SMS “UPLOADLOCATE*123456”...
  • Page 15 Under this mode, the GSM phone card should enable the GPRS function and user need set the IP address (the default IP address is : 121.14.148.19,2088, the address maybe change if the server is upgraded). The command for setting IP is as follow, if the IP is not set or the website has no response the tracker will send back the information of let you set IP or website has no response (maybe the IP has been changed or the server computer is too busy, please try later).
  • Page 16 not start record the tracking, user need sending SMS to start & stop record the tracking. Start Record Tracking 1. Send SMS “STARTRECORD*123456” to the tracker, “STARTRECORD” is a command, “123456” is password; the tracker will start record tracking immediately, and send back a successful SMS to notice begin record tracking, if the flash memory in the tracker is full, the earliest data will be overwrite, if the command or password is not right, the operation is fault, the tracker will send back information “Bad Command ”...
  • Page 17 Send SMS “IP*123456*121.14.148.19,2088” to the tracker, “IP” is a command, “123456” is password; “121.14.148.19,2088” is upload website IP address, if the operation success, tracker will send back information “IP:121.14.148.19,2088” , the default IP address is : 121.14.148.19,2088, the address maybe change if the server is upgraded, any change we will notice on the website : www.followmegps.net , if the command or password is not right, the...
  • Page 18 But under this mode, when the tracker can not receive GPS signal (in room or underground), it will not report location before enter room, it will report the location last located. Set GPS Power Control SHOCKCONTROL Mode: Send SMS “SHOCKCONTROL*123456” to tracker, “SHOCKCONTROL” is a command;...
  • Page 19 will stop, user can send SMS to enable the shock alarm again, this function will not turn on GPS, so it will not reduce battery power. The shock & move alarm SMS is as follow: ObjectMove Latitude:22.680206N Longitude:114.146998E Speed(km/h):45.0 Direction(Degrees):303.30 GMT:2008/04/25 08:29:06.000 Battery:78% Over Area Alarm:...
  • Page 20 Latitude:22.680206N Longitude:114.146998E Speed(km/h):45.0 Direction(Degrees):303.30 GMT:2008/04/25 08:29:06.000 Battery:89% Over Speed Alarm: Send SMS “SETSPEED*123456*040” to tracker, “SETSPEED” is a command, “123456” is password, “040” is the preset report speed, the speed must be 3 digits , from 000 to 999, unit is Km/hour, the tracker will send back the information “Set Over Speed Alarm OK”...
  • Page 21 times. After set the real tracking mode, the tracker will locate the object once every preset interval time and send SMS to preset phone with the location information, when it reach to the max locate times it will cancel the tracking mode automatically.
  • Page 22 location of the tracker must can receive the GPS signal, normally the back of the seat or arm rest box or under the back window or room on the panel etc. please leave away the tracker from big metal, and please do not place the tracker under the big metal. The tracker built in high capacity Li battery, recharge one time can use about 7-10 days, also you can connect the tracker and DC adapter to the 12V car battery, this can keep the tracker has power supply continuously, and not necessary recharge an...

  • Page 23: Change Password

    ADDPHONE* Add phone Any mobile phone Add Preset Phone Reply to the 123456*A*13 number can set operation phone 322990998 Delete phone DELETEPHO Any mobile phone Delete Preset Reply to the number NE*123456*A can delete Phone OK operation phone Preset Phone A： 13322990998；B：...
  • Page 24 history tracking Send SMS to STARTRECO Any mobile phone Start record Reply to operation Start record RD*123456 can set tracking phone tracking Send SMS to STOPRECO Any mobile phone Stop record Reply to operation Stop recod RD*123456 can set tracking phone tracking IP*123456*12...
  • Page 25 LED turn off Notes: 1. The default password is 123456, for example the tracker phone number is 13088803220, if you like set the preset phone is 13322990998, then send SMS “ADDPHONE *123456*A*13322990998" to 13088803220 is OK, if the tracker reply "SET OK", it means operation is success.
  • Page 26 Customer Addr Date year month Model CCTR-700 Serial Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, any other problems please contact us, thanks!
