Summary of Contents for Vogue VGWD34 Series
- Page 1 & Owner s Manual Installation Instructions Model Line Series VGWD34/VGWD12 Write the model and serial numbers for your Disposer here: Model # _______ _____ _____ ____ Serial # _____________________ You can find them on a label on the bottom of the dispos er.
- Page 2 Safety Information Safety Precautions..............Connecting El ectricity............. 2, 3 Installation Instructions Before your begin..............Components and Installation of Sink Flange................Attaching the Discharge Elbow ..................Dishwasher Connec tion............. Connecting Disposer to Sink Flange................Dimensions/Typical Installations......
-
Page 3: Instructions Pertaining To A Risk Of Fire, Electric Shock Or Injury To Persons
IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK OR INJURY TO PERSONS WARNING! WARNING! When using electrical appliances, basic safety precautions should be followed, including the following: SAFETY PRECAUTIONS Use this appliance only for its intended When not operating a disposer, leave the drain purpose as described in the owner's manual. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS. READ ALL INSTRUCTIONS BEFORE USING. WARNING! The appliance must be installed so that the reset buttons and reversing switches are readily accessible. 2.To reduce the risk of electric shock the appliance plug should be connected to mains socket outlets provided with an RCD having a rated residual operating current not exceeding 30mA. -
Page 5: Installation Instructions
Installation Disposer Instructions BEFORE YOU BEGIN WHAT YO U WILL NEED Read these instructions completely and carefully IMPORTANT - Save these instructions for local inspector s use. Phillips and flat blade screwdrivers IMPORTANT - Observe all governing codes and ordinances . Note to Installer - Be sure to leave these Channel lock pliers slip joint... -
Page 6: Components And Installation
Installation Instructions COMPONENTS AND INSTALLATION COMPONENTS NOTE: Pay close attention to the order of the sink flange parts, as they have bee n correctly assembled by the factory. A. Disassemble the sink flange assembly from the Stopper disposer by turning the mount ring to the left (clockwise) and removing it. -
Page 7: Connect Hose
Installation Instructions DISHWASHER CONNECTION IF REQUIRED If you are connecting to a dishwasher, complete the following step. If a dishwasher is not to be connected go on to "Attaching the Discharge Elbow" section. 2 CONNECT HOSE 1 KNOCK OUT PLUG 1 KNOCK OUT PLUG Using a blunt instrument steel punch or wooden Connect the dishwasher hose using a hose clamp If... -
Page 8: Connecting Disposer To Sink Flange
Installation Instructions CONNECTING DISPOSER TO SINK FLANGE 1 ATTACH TO SINK FLANGE 3 LOCK MOUNT RING Line up the disposer Turn the mount ring to the right until it locks u p tight Mount under the sink flange Hopper projections must be to the extreme le ft of Ring Slot Guide the hopper the mounting slots If the mount ring is hard t o turn... - Page 9 Installation Instructions DIMENSION S A Disposer height Dimen sio n B Disposer from bottom of sink bowl to M odel centerline of discharge outlet C Distance from centerline of the discharge VG WD12 outlet to end of discharge tube D Disposer width VG WD34 E Distance form disposer vertical centerline to centerline of discharge elbow...
- Page 10 Operating Instructions This disposer uses anti-jam swivel impellers that make a clicking sound as they swing into place. This indicates normal operation. Operating Instructions . Remove the sink stopper and turn on a medium flow of cold water. . Turn on the wall swit h .
-
Page 11: Troubleshooting Tips
Troubleshooting tips Before you call for service... Troubleshooting Tips Save time and money Review the chart on this page first and you may not need to call for service SAFETY NOTE: Before investigating you must disconnect the power supply WARNING! Before rese tting, disconnect the power supply-please see SAFETY NOTE above. -
Page 12: Warranty And Service
The entire disposer if there is a defect in materials or workmanship relating to functional parts only (appearance parts are excluded). During this limited one-year warranty , VOGUE kitchenware will also provide, Free of charge , all labor charges related to replacing the original disposer along with the replacement disposer within the first year.
