- Page 1 LGATE-951 Universal Gateway Installation instructions Instructions de montage Instruzioni di montaggio Montageanweisung Instrucciones de montaje Montagevoorschrift Monteringsanvisning max 50º C min 0º C 10 - 90 % 0,350 kg LOYTEC...
- Page 2 USB-B microSD RESET DIAL DISPLAY POWER USB1 Ethernet1 RS-485 EXT1 EXT2 1 2 3 USB2 Ethernet2 4 5 6 7 8 9 10 1112 131415 2 x 10/100Base-T 24-35 VDC (RJ45) 24 VAC 2 x USB-A Modbus RTU, M-Bus, KNX TP1, TP/FT-10 BACnet MS/TP ZigBee PRO...
- Page 3 Ethernet1 Ethernet2 RS-485 EXT1 EXT2 LINK BBMD OPC DISPLAY Status LEDs Install the cover LINK GREEN Ethernet link GREEN flashing Ethernet traffic BBMD GREEN BBMD is enabled GREEN OPC client connected GREEN flashing OPC activity RS-485 GREEN flashing fast Traffic on BACnet port BACnet GREEN flashing 1 Hz Not commissioned Modbus...
- Page 4 Node ID of CEA-709 Port 1 Node ID of CEA-709 Port 1 Virtual (Node) ID of CEA-852 port (Ethernet) Virtual (Node) ID of CEA-852 port (Ethernet) LOYTEC electronics GmbH LOYTEC electronics GmbH Date Code Date Code MAC address of CEA-852 Ethernet port...
