INSTALLATION GUIDE
SecureMesh™ Gateway
GATE-1000
Contents
INTRODUCTION ............................................................................................................................................................................ 3
............................................................................................................................................................................................. 6
PREPARING FOR INSTALLATION .................................................................................................................................................... 7
.............................................................................................................................................................................. 7
..................................................................................................................................................................................... 8
INSTALLING THE GATEWAY .......................................................................................................................................................... 10
Mounting the Device ....................................................................................................................................................................... 11
Grounding and Protecting the Device ............................................................................................................................................. 12
Connecting the Device to a Source of Power ................................................................................................................................... 13
Completing the installation ............................................................................................................................................................. 14
Mounting the Device ....................................................................................................................................................................... 15
Connecting the Device to a Source of Power ................................................................................................................................... 17
Completing the Installation ............................................................................................................................................................. 18
Attaching the Optional Wi-Fi Antennas........................................................................................................................................... 19
COMMISSIONING THE GATEWAY ................................................................................................................................................. 20
APPENDIX .................................................................................................................................................................................... 21
........................................................................................................................................................................... 21
(US)............................................................................................................................................................................... 23
Installation_Guide_SecureMesh_GATE-1000_110502.docx
.......................................................................................................................................................... 4
..................................................................................................................................................... 7
................................................................................................................................................................. 7
....................................................................................................................................................................... 11
........................................................................................................................................... 15
.................................................................................................................................................... 19
.................................................................................................................................................. 20
..................................................................................................................................................... 20
) ....................................................................................................................................... 23
Advertisement
Table of Contents
Related Manuals for Trilliant SecureMesh GATE-1000
Summary of Contents for Trilliant SecureMesh GATE-1000
-
Page 1: Table Of Contents
INSTALLATION GUIDE SecureMesh™ Gateway GATE-1000 Contents INTRODUCTION .................................... 3 ................................4 ECURE ATEWAY OMPONENTS ......................................6 CCESSORIES PREPARING FOR INSTALLATION ..............................7 ..............................7 EQUIRED ROVISIONING QUIPMENT ................................. 7 EQUIRED UTDOOR QUIPMENT ....................................7 NSTALLATION OCATION ..................................... 8 ROVISIONING INSTALLING THE GATEWAY ................................10 .................................. - Page 2 AFETY NFORMATION Trilliant strongly urges that you always follow all locally approved safety procedures and safety instructions when working around high voltage lines and equipment. The instructions in this manual are not intended as a substitute for proper training or adequate experience in the safe operation of the equipment described.
-
Page 3: Introduction
Adding more Gateways to a SecureMesh WAN deployment enhances network reliability and, more importantly, modularly increases the network’s total capacity. The overall SecureMesh WAN capacity is then defined by the total number of Gateways times the throughput through each Gateway. Trilliant Incorporated page 3 of 23... -
Page 4: Securemesh Gateway Components
The following diagram shows the major components of the SecureMesh Gateway. water intrusion gasket Ethernet, 8P8C optional: Wi-Fi data and power access point bulkhead connector status lights serial, 8P8C grounding lug optional: Wi-Fi access point bulkhead connector side view bottom view Trilliant Incorporated page 4 of 23... - Page 5 Gateway Installation Guide The following diagram shows the SecureMesh Gateway package contents. SecureMesh Gateway Wi-Fi antennas (if ordered with this option) Indoor Power Supply w/ PoE Injector Power Cord IEC320-C13 plug for the Americas Trilliant Incorporated page 5 of 23...
-
Page 6: Accessories
Indoor Power Supply w/ PoE Injector 171-R0005-01 IEC320-C13 plug for Americas 171-R0005-02 IEC320-C13 plug for UK 171-R0005-03 IEC320-C13 plug for Europe 171-R0005-05 IEC320-C13 plug for Australia 171-R0005-06 IEC320-C13 plug for Latin America Trilliant Incorporated page 6 of 23... -
Page 7: Preparing For Installation
24V Power Service Unit, any type of Ethernet cable can be used; otherwise, a cross-over cable must be used. • A surge suppressor, either the unit identified on the accessory list above (Trilliant part number 620- 00705-01) or an equivalent unit. •... -
Page 8: Pre-Provisioning
Telnet session to IP address 192.168.0.2, and invoke the supply command line interpreter. Please refer to the “SecureMesh™ WAN Command-Line Interface” (Trilliant document number DP-0985) for complete information. Ethernet cable straight through The following Gateway parameter must be configured: Shared network key (“netkey”) —... - Page 9 Extenders, Extender Bridges, and Connectors are expected to connect. Specify the primary frequency in MHz as a four digit number (e.g. 5745). If IPsec VPNs are being used (note that Trilliant strongly recommends their use), the following Gateway parameter must also be configured: VPN credentials —...
-
Page 10: Installing The Gateway
• Connecting to a source of power • Completing the installation • Optionally: Attaching the Wi-Fi antennas Installation of the Gateway on either a utility pole or streetlight is discussed in the following subsections. Trilliant Incorporated page 10 of 23... -
Page 11: Utility Pole Installation
Note that screws 1" in length can accommodate a pole diameter up to 1½" while screws 2" in length accommodate a pole diameter of 2 1/8”. The screws should be tightened to 20 foot-pounds (27 Newton-meters) of torque. Trilliant Incorporated page 11 of 23... -
Page 12: Grounding And Protecting The Device
Run the CAT5e cable under the gasket and plug it into the Ethernet port in the cavity on the device base (see the diagram to the right) CAT5e Ethernet Cable 8P8C Ethernet Port 8P8C serial port View of underside with cover plate removed Trilliant Incorporated page 12 of 23... -
Page 13: Connecting The Device To A Source Of Power
The Power Service Unit can be used to provide PoE power and battery backup for the Gateway. Please refer to the Power Service Unit Installation Guide for more information (Trilliant document PL-0042A, Installation Guide, SecureMesh 24V PSU). Alternatively, the site may have its own Uninterruptible Power System that can be used along with a PoE injector to provide 24V power and data over an Ethernet cable;... -
Page 14: Completing The Installation
Secure the Cabling Use sturdy cable ties or Velcro wraps (not included) to secure all the cabling against strain, especially if the installation is subject to high winds. sturdy cable ties or Velcro wraps Trilliant Incorporated page 14 of 23... -
Page 15: Streetlight Pole Mounting And Grounding
Make the mounting pipe plumb (straight) by moving the main bracket from side to side and moving the plumb adjustment bracket forward and backward. The accuracy should be checked using a magnetic level. When the mounting pipe is plumb, tighten all nuts. Trilliant Incorporated page 15 of 23... - Page 16 If the streetlight is a metal arm attached to a wooden pole the ground wire must extend to a proper ground location. Ethernet PoE cable ground wire Trilliant Incorporated page 16 of 23...
-
Page 17: Connecting The Device To A Source Of Power
Replace the photocell on top of the photocell adapter; twisting clockwise until hand tight. • Coil any excess cable. Place it in the space provided under the mount stand and secure it. photocell adapter / power tap Trilliant Incorporated page 17 of 23... -
Page 18: Completing The Installation
Secure the Cabling Use sturdy cable ties or Velcro wraps (not included) to secure all the cabling against strain, especially if the installation is subject to high winds. sturdy cable ties or Velcro wraps Trilliant Incorporated page 18 of 23... -
Page 19: Optional Wi-Fi Antenna Installation
Use self-fusing rubber insulation and sealing tape to • wrap the antenna bulkhead connector and the antennas to avoid water penetration of any kind. Trilliant Incorporated page 19 of 23... -
Page 20: Commissioning The Gateway
Installation Guide OMMISSIONING ATEWAY Configuring the SecureMesh Gateway Assuming the Gateway is properly pre-provisioned, use of automatic provisioning as described in the “Trilliant Network Element Management System (NEMS) Administration Guide” (Trilliant document number TLT-CS- ADM-94) recommended. Monitoring the Power-On Sequence... -
Page 21: Appendix
• A cold-water pipe. Make sure it is well connected to earth. Trilliant Incorporated page 21 of 23... - Page 22 Run the CAT5e cable inside the tower structure, tying the cable to the tower leg at every 4 feet of length. For increased protection, run the CAT5e cable through metallic conduit installed on the tower. Trilliant Incorporated page 22 of 23...
-
Page 23: Fcc Statement (Us)
SkyPilot logo are trademarks of Trilliant Incorporated and/or its subsidiaries. All other trademarks are the property of their respective owners. This material is provided for informational purposes only; Trilliant assumes no liability related to its use and expressly disclaims any implied Trilliant Incorporated warranties of merchantability or fitness for any particular purpose.
