Summary of Contents for Yard Tuff ACR-500T
- Page 1 Acreage Rake OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# ACR-500T 04252011...
-
Page 2: Intended Use
Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: ____ACR-500T__________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This machine is designed for certain applications only. -
Page 3: Work Area
WORK AREA • Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating an acreage rake. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •... -
Page 4: Hardware Pack Contents
ASSEMBLY TOOLS REQUIRED FOR ASSEMBLY (1) Pliers (2) 1/2” Wrenches (2) 3/4” Wrenches (1) 7/8” Wrench REMOVE ALL PARTS FROM CARTONS Remove the hardware packs and all parts from the cartons. Layout and identify parts included in carton contents. (See parts listing below) Layout and identify parts included in the hardware pack. - Page 5 Assembly STEP 1: ATTACH TONGUE TO AXLE Place tongue assembly (#4) and axle assembly (#1) on a flat surface. Position the tongue so that the diameter of 19mm x length of 118mm shaft welded to the tongue is straight up. Orientate the axle (#1) so the lift arm hinges welded to the axle face away from the tongue.
- Page 6 STEP 4: ATTACH CABLE PIVOT BAR Attach the two lift chain bars (K) to the 19mm x 118mm shaft on the tongue assembly. Install each chain bar on top of shaft; use a 5/16” nylock nut (M). The chains should be positioned facing the rear of rake.
- Page 7 STEP 7: ATTACH LIFT ARMS TO AXLE Attach the lift arm (#5) to the wheel axle (#1) using 1/2” x 4-1/2” hex bolt (A) and 1/2” nylock nut (G). See figure 7. Repeat on opposite side. Usage Note: Note the lift arm offset in figure 7. Assembling lift arms with the offset towards inside will make a narrower space when raking.
- Page 8 CAUTION: Do not over tighten locknut as it will cause bearing damage in the rake tine wheel hub. Rake tine wheel should spin freely. Assemble opposite side. Make certain that the three rake tine wheels on opposite side are positioned as shown in figure 10.
- Page 9 ADJUST THE OPERATING HEIGHT of LIFT ARMS NOTE: Adjustments may be needed based on the height of the towing vehicle hitch. Step 10: Attach the Acreage Rake to the towing vehicle hitch. Follow Steps 11, 12, and 13 for each lift arm. These steps are to make sure rake reel tines will: (1) lift high enough for towing clearance, and (2) rake tines will reach the ground properly for raking or de-thatching.
-
Page 10: Operation
OPERATION WARNING: Keep the operating speed LOW!!!!! Do not operate over 5 MPH (8KMH). Allow only responsible adults who are familiar with these instructions to operate this machine. Never allow children to operate this machine. Be sure the area is clear of other people before operating. Children are often attracted to the machine and the operating activity. -
Page 11: Maintenance
MAINTENANCE • Maintain your acreage rake. It is recommended that the general condition of any acreage rake be examined before it is used. Keep your acreage rake in good repair by adopting a program of conscientious repair and maintenance. If any abnormal vibrations or noise occurs, have the problem corrected before further use.
