USER MANUAL
POOLS • DRINKING WATER • POND
MK7/CF1-75 • MK7/CF1-75UV • Pools up to 75m
MK7/CF1-150 • MK7/CF1/150UV • Pools up to 150m
MK7/CF1-250 • MK7/CF1-250UV • Pools up to 250m
MK7/CF1-500 • MK7/CF1-500UV • Pools up to 500m
MK7/CF1-750 • MK7/CF1-750UV • Pools up to 750m
MK7/CF1-1000 • MK7/CF1-1000UV • Pools up to 1000m
On Request • Pools up to 10 000m
3
3
0
3
3
3
3
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MK7/CF1-75 and is the answer not in the manual?

Questions and answers

Related Manuals for E-Clear MK7/CF1-75

Summary of Contents for E-Clear MK7/CF1-75

  • Page 1 USER MANUAL POOLS • DRINKING WATER • POND MK7/CF1-75 • MK7/CF1-75UV • Pools up to 75m MK7/CF1-150 • MK7/CF1/150UV • Pools up to 150m MK7/CF1-250 • MK7/CF1-250UV • Pools up to 250m MK7/CF1-500 • MK7/CF1-500UV • Pools up to 500m MK7/CF1-750 •...

  • Page 2: Table Of Contents

    Electrodes connections ....................6 3.3.2. Large Box and assembly ....................7 3.3.3. UV connections ......................7 3.3.4. e-Clear water purification systems technical specifications ..........8 3.3.4.1. General specifications ....................8 3.3.4.2. Specifications per model ..................9-11 Section 4: System Start-up ..................11 Controls Orientation ....................
  • Page 3 11.3.4. Siliphos filter ......................... 65 11.3.5. 55watt UVC high spectrotherm lamp ................66 11.3.6. e-Clear high output oxygen & copper ionization chambers – Science explanation ....67 11.4. e-Clear Eco-Fussion™ rainwater harvesting kit ..............69 11.4.1. Rainwater Harvesting Averages for South Africa .............. 70 11.4.2.

  • Page 4: Section 1: General Information

    Product Overview The e-clear 100% Chlorine free New Generation 7 series- provides multiple forms of toxic free oxygen which splits into 4 powerful oxidisers (01)- (02)- (OH)- (H2O2). These chemically free oxidisers are produced from and delivered directly into, the water stream, in grams per minute via Electronic Oxidation.

  • Page 5: Section 3: Installation

    SECTION 3: INSTALLATION _________________________________________________ What's in the box Unpacking -...

  • Page 6: Switches Orientation

    DANGER: AC mains outlets in wet or potentially wet locations must always be provided with a ground fault circuit interrupting circuit breaker (GFCI/GFI). Switches Orientation Mains ON/OFF - bottom of box Power Cable Mains ON/OFF Side of box:...
  • Page 7 Oxidation ON/OFF Ionization ON/OFF UV ON/OFF...

  • Page 8: Connections

    UV ON/OFF Switch Connections 3.3.1 Electrodes connections...

  • Page 9: Large Box And Assembly

    3.3.2 Large Box and Assembly 3.3.3 UV Connections 4- p in connector at bottom of Ebox (pre-connected) UV Chamber with Ebox mounted...

  • Page 10: Eclear Water Purification Systems Technical Specifications

    3.3.4. eClear Water Purification Systems Technical Specifications 3.3.4.1. GENERAL SPECIFICATIONS ULTRAVIOLET CHAMBER Extended chamber for longer contact time to water. Removes 99.9% of all waterborne parasites and diseases-including the deactivation of cryptosporidium. Special long life high Spektrotherm germicidal UV lamps. 10 000hrs. ELECTRONIC MANAGEMENT UNIT Microprocessor technology with integrated digital display.

  • Page 11: Specifications Per Model

    3.3.4.2. SPECIFICATIONS PER MODEL MK – 75 Size Electrical Inline chamber: 63mm straight 5v •40w•2.5A (470mm x 100mm) 12hrs=0.3kWh/day Electronic box: 300mm x 180mm x 150mm Flow rate: Weight 90ℓ/ min Inline chamber: 2.25kg 0.5 m/sec Electronic box: 2.7 kg MK –...
  • Page 12 MK – 250UV Size Electrical Inline chamber:4 x 470mm x 130mm 230v•380w•10A UV chamber and E-box: 12hrs=4kWh/day 500mm x 1020mm x 400mm Flow rate: Weight 1800ℓ/ min Inline chambers: 13.5kg 2 m/sec UV chamber and E-box:23kg MK – 500 Size Electrical Inline chambers: 8 x 470mm x 130mm 5v•320w•20A...

  • Page 13: Section 4: System Start-Up

    MK – 1000 Size Electrical Inline chambers: 16 x 470mm x 130mm 5v•640w•40A E-box: 4 x 400mm x 300mm x 160mm 12hrs=5kWh/day Weight Flow rate: Inline chambers: 54kg 7200ℓ/min E-box:4 x 6kg 8 m/sec MK – 1000UV Size Electrical Inline chamber:16 x 470mm x 130mm 230v•1450w•40A 4 x UV chamber and 4 x E-box: 12hrs=16kWh/day...

  • Page 14: Large Box Control Orientation

    CAUTION-the e-clear system will not operate properly without this pre-requisite calcium hardness. 4.4.2 The correct operating pH in the pool water, for the e-clear system to operate efficiently, is in the 6.8- 7.2. range of If the pool water's pH is allowed to rise above 7.3 for longer than 48 hours, the...

  • Page 15: Filtration

    Upon initial operation of the e-clear system, the copper residual will take a period of time to reach 0.5ppm. In the interim, additional help is required to ensure clean and clear pool water during this shock treat 'set-up' period it is necessary to the water with, either, chlorine or active oxygen (until the copper residual reaches 0.5ppm) This initial set-up period may last a couple of weeks,...

  • Page 16: Section 5: Standard Operation

    _________________________________________________ Oxidation (black electrodes, white cable, 2 pin) When the e-clear electronic box is powered, the oxygen plates should always be powered, i.e. They need never be switched off independently of the mains power. The electronic box must only be powered when the pool water is circulating see section 4.4.4.

  • Page 17: Electrode Replacement

    It is not necessary to change oxygen plates as they are not sacrificial. UV lamp replacement It is preferable for this to be carried out by a qualified electrician or e-clear Technician. Switch off pool pump and unit Carefully remove endcaps form UV chamber (be careful to not pull on wires.) Undo electrical wires from 'chocolate blocks' using a screwdriver Carefully unscrew grey threaded bush, making sure to retain o-rings.

  • Page 18: Repair/ Spares Service

    Office: +27 21 854 6356 Fax: +27 21 854 6117 Email: jason@eclearsa.com Mail: PO Box 2308 Somerset West 7129 South Africa Download our new E-clear App to your smartphone/tablet Available on the Available on the Android App Store App Store...

  • Page 19: Section 7:Certification And Limited Warranty

    In the event that a defect is discovered during the warranty period E-clear agrees that, at its option, it will repair or replace the defective product or refund the purchase price excluding original shipping and handling charges.
  • Page 20 INSTALLATION AND MAINTANCE GUIDE FOR E-CLEAR POOLS SECTION 8: _________________________________________________...

  • Page 21: Installation Guide

    8.1. INSTALLATION GUIDE...

  • Page 22: Physical Installation

    8.1.1. Physical Installation Step 1 Step 7 The e-Clear must only operate when the pool The entire pool volume should flow through pump is running. the pool filters every 4 hours, according to Step 2 international DIN standard The e-Clear system must be installed as last...

  • Page 23: Water Balancing

    With the pool pump running and e-Clear process we recommend running your pool system switched off, adjust the calcium pump and e-Clear 24 hours a day. During this hardness to 200 - 300ppm using calcium time, it may be necessary to shock the water flakes (available from your local pool shop).

  • Page 25: Eclear Pump And Filter Guidelines

    8.1.3. E-Clear Pump and Filter Guidelines Domestic Swimming Pools – 50m Pool 1. Pool pump 0,75 kw/1 hp – 2m head - 20m 6m head - 16m 12 head - 10m 2. 3 or4 bag glass media filter 3. Recycled glass media 75% fine and 25% coarse.

  • Page 26: Technical Installation Guidelines For Eclear Water Sanitizers

    8.1.4. TECHNICAL INSTALLATION GUIDELIES FOR e-CLEAR WATER SANITIZERS...

  • Page 40: Maintenance Guide

    8.2. MAINTENANCE GUIDE...

  • Page 41: Weekly Maintenance

    8.2.2. Annual Maintenance 1. Check calcium level of pool water at pool shop or using e-Clear purchased calcium test kit. Calcium Level should be between 200-300ppm. Calcium is added at e-Clear installation to produce conductivity in the water in order for the plates to pass current between them. Calcium does not get used up or evaporate but only leaves the pool during back washing.

  • Page 42: Do's And Don'ts

    High alkalinity causes the pH to drift upwards quickly. CALCIUM Calcium is added at e-Clear installation to produce conductivity in the pool water so that an electrical charge can travel between the electrodes. 250-400ppm is necessary. Have water tested 1 week after installation for calcium.
  • Page 43 CYCLE TIMES When water quality is an issue, run the e-Clear system 24 hours a day to clear up the water. At start up run the e-Clear 24 hours a day until copper residual reaches 0.5ppm Thereafter run the e-Clear 6-12 hours a day during daylight hours, under normal circumstances.

  • Page 44: Common Issues

    You should never need to add chlorine to the pool but if you must. Add chlorine to a bucket of pool Never add chlorine to water, stir and let it stand for 10 min. Add water with e-Clear system off. the pool while the e-Clear system is powered, it will cause an electrical surge and damage your plates.

  • Page 45: Section 9: Problem Solving Guide

    SECTION 9: _____________________________________________________ PROBLEM SOLVING GUIDE...
  • Page 51 SECTION 10: _____________________________________________________ SPARE PARTS...
  • Page 52 10.1 SPARE PARTS OXYGENATION AND IONIZATION MK-75 QUANTITY UNIT LIFE SPAN 63mm IONIZATION ELECTRODES 1-3 YEARS MK-150 QUANTITY UNIT LIFE SPAN 90mm IONIZATION ELECTRODES 1-3 YEARS MK-250 QUANTITY UNIT LIFE SPAN 90mm IONIZATION ELECTRODES 1-3 YEARS MK-500 QUANTITY UNIT LIFE SPAN 90mm IONIZATION ELECTRODES 1-3 YEARS MK-750...
  • Page 53 10.2. OXYGENATION, IONIZATION AND UV MK-75UV MK-500UV LIFE QUANTIT LIFE QUANTITY UNIT UNIT SPAN SPAN 63mm IONIZATION 90mm IONIZATION ELECTRODES YEARS ELECTRODES YEARS 55 WATT UVC HIGH 10 000 55 WATT UVC HIGH 10 000 SPECTROTHERM HOURS SPECTROTHERM LAMP HOURS LAMP MK-750UV MK-150UV...
  • Page 54 SECTION 11: _____________________________________________________...

  • Page 55: Can You Trust Eclear

    11.1. Can you trust eClear ™ eClear Technologies has been making eClear systems for over 20 years. We export to around 30 countries worldwide, with more than 25 000 installations. eClear’s natural oxygenator (O2) technology delivers over 40,000g oxidation/hr making it the most powerful water treatment system currently available.
  • Page 56 ™ ECO-FUSION ONE-TAP DRINKING WATER SYSTEM...

  • Page 57: Eco-Fusion One-Tap Drinking Water System

    ™ 11.2. ECO-FUSION ONE-TAP DRINKING WATER SYSTEM 11.2.1. 10ꞋꞋ BIG BLUE FILTER HOUSING Large capacity housing suitable for high flow applications. Accepts 4 ½ diameter cartridges. Big Blue housing® filter housings offer the versatility to meet all of your large-capacity filtration needs, including high-flow and heavy- sediment applications.

  • Page 58: Meltblown 5 Micron Pre-Filter

    HOUSING SPECIFICATIONS AND PERFORMANCE DATA MODEL MAXIMUM DIMENSIONS INITIAL AP (psi) @ FLOW RATE (gpm) 10 ꞋꞋ BB-1ꞋꞋ 13-1/8ꞋꞋ x 7-1/4ꞋꞋ 1 psi @ 15 gpm (0.1 bar @ 57 L/min) (333 mm x 184 mm) MATERIALS OF CONSTRUCTION Housing Polypropylene O-Ring Bana-N...

  • Page 59: Uv T5 16W High Output Uvc With Quartz Sleeve

    SPECIFICATIONS DIMENTIONS MATERIAL OF CONSTRUCTION PERFORMANCE Outside Filter Media: Removal Rating: Diameter: Acid washed bituminous GAC & water 5µm 4.5 ꞋꞋ (115mm) washed coconut shell GAC Max Differential End Caps Material: Pressure: Inner Diameter: Polypropylene 7 Bar @ 68℉ (20℃) 1.2 ꞋꞋ...
  • Page 60 ECO-FUSION ™ WHOLE HOUSE DRINKING WATER SYSTEMS...
  • Page 61 11.3. ECO-FUSION WHOLE HOUSE DRINKING WATER SYSTEMS ™...

  • Page 62: Eco-Fusion Drinking Water Systems Technical Specifications

    11.3.1.Eco-Fusion Drinking Water Systems Technical Specifications SHUT OFF VALVES: Enables Shut Down of Mains Water for Easy Cartridge Replacement and Maintenance of System. ULTRAVIOLET CHAMBER: Extended Chamber for longer contact time to water. Removes 99.9% of all waterborne parasites and diseases-including the deactivation of cryptosporidium.

  • Page 63: Meltblown 5 Micron Pre-Filter

    HOUSING SPECIFICATIONS AND PERFORMANCE DATA MODEL MAXIMUM DIMENSIONS INITIAL AP (psi) @ FLOW RATE (gpm) 20 ꞋꞋ BB-1 – 1/2 ꞋꞋ 23 – 7/8 ꞋꞋ x 7 – 1/4 ꞋꞋ (606 mm x 184 mm) 1 psi @ 20 gpm (0.1 bar @ 76 L/min) MATERIALS OF CONSTRUCTION Housing Polypropylene...
  • Page 64 20 ꞋꞋ BIG BLUE CARBON BLOCK FILTERS 11.3.2.3. Our Activated Carbon Filter Cartridges are formed using extruding carbon fibers and food-grade binders. This makes it FDA approved for the Food/Beverage industry. It also ensures that no bad taste is left behind. This filter is also great for filtering organic matter effectively. SPECIFICATIONS DIMENTIONS MATERIAL OF CONSTRUCTION...

  • Page 65: Kdf Filters

    11.3.3. KDF FILTERS KDF process media, however, improve water treatment performance by protecting, and in some cases replacing, existing filtration/purification technologies. The exceptional filtration/purification performance and versatility of KDF media make them an economical and easy-to-use water treatment technology in both new systems and retrofit applications. Improve your system’s economy while improving performance.
  • Page 66 KDF PROCESS MEDIA PRODUCT SPECIFICATIONS Medium composition Atomized high purity copper/zinc alloy Color Golden (55), reddish brown (85) Physical form Granular Screen size (U.S mesh) -10 +100 Particle size range 0.149mm – 2.00mm Apparent destiny 2.2 – 2.9 g/cc (171 lbs./cu.ft.) Turbidity <20 ntu Skid...

  • Page 67: Kdf 55

    11.3.3.1. KDF 55 KDF 55 granules are designed for removing or reducing chlorine and soluble heavy metals. They are also used for controlling scale, bacteria and algae. KDF 55 medium delivers 10 times greater Water treatment costs with KDF 55 filter life than GAC medium are less than half that of GAC KDF 55 Medium...

  • Page 68: Siliphos Filter

    11.3.4. SILIPHOS FILTER Protects water systems in hotels, public buildings, private households and industry against scale formation and corrosion. Prevents “brown” water and clogged pipes. Save energy and money. Extends the life of water instillations. Siliphos is a glassy polyphosphate containing silicate. The application is done by dispensers of variable size.
  • Page 69 11.3.5. 55 WATT UVC HIGHSPECTROTHERM LAMP TUV T8 lamps are double-ended UVC (germicidal) lamps used in professional water and air disinfection units. TUV T8 lamps offer almost constant UV output over their complete lifetime, for maximum security of disinfection and high system efficacy. Moreover, they have a long and reliable lifetime, which allows maintenance to be planned for in advance.
  • Page 70 11.3.6.e-CLEAR HIGH OUTPUT OXYGEN & COPPER IONIZATION CHAMBER SCIENCE EXPLANTION...
  • Page 71 E-CLEAR ECO-FUSION RAINWATER HARVESTING KIT...
  • Page 72 11.4. E-CLEAR ECO-FUSION RAINWATER HARVESTING KIT...

  • Page 73: Rainwater Harvesting Averages For South Africa

    11.4.1. RATER HARVESTING AVERAGES FOR SOUTH AFRICA *Based on 180m home M74 12/12 pitch roof. *1mm of rain = 1 Liter of water per square meter of roof area, minus 15% wastage. RAINWATER HARVESTING AVERAGES FOR SOUTH AFRICA 1200 240 000L 1000 143 000L 117 000L...

  • Page 74: Additional Davey 0.75Kw Submersible Pump

    11.4.9. ADDITIONAL DAVEY 0.75KW SUBMERSIBLE PUMP 11.4.10. e-CLEAR HIGH OUTPUT OXYGEN & COPPER IONIZATION CHAMBER...
  • Page 75 For pricing information, please contact eClear Technologies Office: +27 21 854 6356 Jason: +27 76 611 7803 Fax: +27 21 854 6117 jason@eclearsa.com dave@eclearsa.com www.eclearsa.com www.eclear-water.com...

This manual is also suitable for:
