OPERATING MANUAL FOR

SPRING

REFRIGERATED DISPLAY

00763-00

Table of Contents

Need help?

Do you have a question about the SPRING and is the answer not in the manual?

Questions and answers

Summary of Contents for Eurocryor SPRING

Page 1 OPERATING MANUAL FOR SPRING REFRIGERATED DISPLAY 00763-00...
Page 3 INTRODUCTION AND QUALITY CONTROL 1. HANDLING AND STORAGE 2. DESCRIPTION OF COUNTER 3. REGULATION, USAGE AND PRESCRIPTION 4. ENVIRONMENTAL CONDITIONS 5. TECHNICAL DATA 6. INSTALLATION 7. DISPLAY CASE SET-UP 8. INDICATION FOR CLEANING AND MAINTENANCE 9. WASTE DISPOSAL 10. CONTROL PANEL 11.
Page 4 INTRODUCTION AND QUALITY CONTROL EURO’CRYOR congratulates you on your choice to purchase our display counter SPRING. It is important to keep this manual with care for any further consultation. It is recommended also, to pay particulary attention to the prescriptions...
Page 5: Handling And Storage
1. HANDLING AND STORAGE Transport carried out without pallet or wooden box • Insert the forklift truck prongs as indicated in the two following pictures. Keep a minimum distance between the 600 mm. prongs making sure that they are properly centered in the middle of the cabinet.
Page 6 Transport carried out on pallet or wooden box • Insert the forklift truck prongs in the shown points. • Insert the forklift truck prongs right to the end to avoid overturning. Lifting-up • There must be the greatest possibile points distance between the prongs to increase the stability.
Page 7 DESCRIPTION OF COUNTER The refrigerated counter SPRING is suitable for the display and sale of deli products. It is standard model, available in six linear lengths (1250, 1563, 1875, 2500, 3125, 3750) plus four refrigerated corner models (938 + open corner, 938 + closed corner, 135° corner, 225° corner), all of them with or without compressor unit.
Page 8 BACK-SHELF PAPERHOLDER REFRIGERATED STORAGE UNIT LOAD LINE CONDENSATOR CONDENSING WATER TRAY DATA LABEL POWER ELECTRONIC REAR CLOSURE SUPPLY CABLE PANEL CANOPY OPEN FRONT GLASS SIDE GLASS THERMOMETER FRONT FACIA DECORATION CURVED PANEL LOWER DECORATION...
Page 9: Environmental Conditions For Installation
REGULATIONS, USAGE AND PROHIBITIONS Euro’Cryor’s display cases have been designed and produced exclusively for the display of fresh foodstuffs and beverages inside the refrigerated sections. it is absolutely forbidden to use the case to display pharmaceutical products. Before using the cabinet, read carefully the instructions quoted in this manual and instruct the operator about the use.
Page 10: Technical Features
(installation conditions example) 5. TECHNICAL FEATURES General features General features (25° C / 60% R.H.) Operating temperature +2° C / +4° C Climatic class (EN441) Goods temperature class (EN 441) Refrigeration type Ventilated Evaporating temperature -10° C Refrigerant R404A Defrosting type Stop-compressor Liquid pipe entry size 6 mm...
Page 11 Linear displays cabinets features Electrical features (230Vac / 50HZ) 1250 1563 1875 2500 3125 3750 Lenght (mm) Anti-mist fan (W) Canopy light (W) Evaporator fans (W) Mezzanine shelf light (option) (W) Rated output without condensing unit (W) Condensing unit (W) Rated output with condensing unit Technical / Refrigerating features (25°...
Page 12: Installation
Technical / Refrigerating features (25° C / 60% R.H. ) 90” DX/SX 135” 270 DX/SX 225” Counter model Extraction rate (W) Refrigerant mass (kg) Compressor model NE6210GK NE6210GK NE6210GK NE6210GK Display deck area (m²) 1.56 1.93 1.96 2.13 Display volume (m³) 0.28 0.34 0.35...
Page 13 Over structure assembly Fig. D Fig. D-1 Fig. D Fig. D-2 Fig. D-3 Fig. D-4 Fig. D-5...
Page 14 Fig. D-6 Fig. D-7 M6x10 Fig. D-8, D-9 Fig. D-8 Fig. D-9 Fig. D-10 Fig. D-11...
Page 15 Side panel assembly Fig. M-1, M-2 Fig. E Fig. E-1 Fig. E-2 Fig. E-3 Fig. E-4 Fig. E-5 Fig. E-5...
Page 16 Fig. E-6 Fig. E-7 Glass end installation...
Page 17 Central glass installation on Spring with non refrigerated angle...
Page 18 Multiplexing When a display cabinet must be joined to another one (multiplexing), a kit with the necessary part is supplied (see picture below) N° 1: insulating sponge. N° 2: box with screws and pins. N° 3: canopy union angle bar. N°...
Page 19 SI/YES OUI/JA NO/NEIN 3.9 x 9...
Page 21 Shelves adjustment Valve adjustment...
Page 22 Electrical connections Warning: before proceeding with the following operations, check that the electrical installation complies with the standard laws regulating such installation in the country concerned. The device’s power supply must be independent from the other supplies and separately insulated; before the supply socket, it is compulsory to install a differential bipolar magnetothermic switch with 30mA sensitivity.
Page 23 After having removed the electronic control panel, work on the electronic circuit board trimmer “3” with a small size screw driver. 7. DISPLAY CASE SET-UP First Start-up Before making the display case working, we recommend to clean it using a neutral soap and non- abrasive sponges, then wipe it away.
Page 24: Cleaning And Maintenance
The display cabinets without the incorporated group are not equipped with the water discharge evaporating system. Therefore it is highly recommended to empty frequently the drip pan in order to avoid unpleasant overflows. 8. CLEANING AND MAINTENANCE BEFORE ANY OPERATION, REMOVE THE POWER SUPPLY PLUG RECOMMENDED PROTECTIVE GLOVES.
Page 25: Waste Disposal
Periodically check the normal downflow of the condensing water. Ordinary maintenance Carry out, at least once a year by skilled personnel, a general check of the glasses opening system, on the electric system and on the refrigerating circuit. Should it be necessary to top up with refrigerating gas, use a station equipped with two ¼ SAE valves, to screw on the appropriate fittings placed near the compressor.
Page 26: Control Panel
10. CONTROL PANEL MAIN SWITCH ELECTRONIC THERMOSTAT USED LIGHT SWITCH 10.1 Electronic Thermostat We recommend to the final user not to programm the instrument; for any changement of the set parameters, unless it is the changement of the temperature setpoint, we suggest to contact the installer.
Page 27 10.4 Use and function of the key Spare parts • ID 961: cod. 30004064 • Probe: cod. 30006840 LED description KEYS description...
Page 28 10.5 In order to change the parameters To change the set parameters (chapter 10.3) follow the diagram below. Press for 5 seconds Scroll Change Confirm parameter value value parameter parameter parameter parameter parameter parameter Press this key to go back. Warning: after having modified the parameters switch off and then switch on the instrument.
Page 29 10.6 Password The password allows access to programming parameters. In the standard configuration password is not present. To enable and assign it the desired value, access the “Programming” menu, within the folder with the “diS” label. If password is enabled, you will see it at the entrance of the “Programming” menu.
Page 30 10.10 Parameter description...
Page 31: Electrical Diagram
11. ELECTRICAL DIAGRAM • A: Counter switch. • A1: light switch. • K1, K2: Canopy ballasts (L1, L2) • K3: L3 ballast (option). • FLR/RV: net filter plus adjustment fan • L1, L2: canopy light. • L3: Mezzanine shelf light (option) •...
Page 32 ELECTRICAL DIAGRAM N. 34...
Page 33 ELECTRICAL DIAGRAM FOR SPRING BREAD SECTION The SPRING cabinet bread section is a section without ventilation and has got only the lighting in the top canopy. The chapters of this operating manual, where possible, are valid also for the SPRING BREAD...
Page 34: Warranty Conditions
12. WARRANTY CONDITIONS EURO’ CRYOR guarantees that the goods sold are free from flaws and defects and guarantees the quality of the materials used, under normal use conditions. The warranty period is twelve months from the date of delivery of the goods, during which the company commits to replacing the parts it considers to be faulty in terms of manufacturing or materials at his own discretion.
Page 35: Spare Parts
14. SPARE PARTS...
Page 38 Tav. AC - Ver. 0...
Page 39 Tav. AP - Ver. 0...
Page 40 Tav. AQ - Ver. 0...
Page 41 Tav. AR - Ver. 0...
Page 44 Viale delle Industrie 35047 Solesino (PD) ITALY Tel. 0429.707311 Fax 0429.706000 http: \\www.eurocryor.it e-mail: commercialeitalia@eurocryor.it e-mail: export@eurocryor.it...
