- Page 1 TENS ELECTROTHERAPY FOR TARGETED PAIN RELIEF INSTRUCTION MANUAL All TN100 Models...
-
Page 3: How Does It Work
Congratulations on purchasing the Theralief ™ TENS Electrotherapy unit for quick and effective pain relief. TENS TECHNOLOGY TENS (Transcutaneous Electrical Nerve Stimulation) has been used for decades by doctors and physical therapists for the safe and effective management of acute and chronic pain. This technology is now available for home use without a prescription. - Page 4 5. Do not apply stimulation while bathing or in a shower. Use only on clean, dry skin and in a dry area. 6. If you have one of the following conditions, please consult with your physician before purchasing or using this device: Acute disease, malignant tumor, infectious disease, pregnant, heart disease, high fever, abnormal blood pressure, lack of skin sensation or an abnormal skin condition, any condition requiring the active supervision of a physician.
-
Page 5: Adverse Reactions
• That the device has no curative value; • That the device is a symptomatic treatment and, as such, suppresses the sensation of pain that would otherwise serve as a protective mechanism; • If the user has suspected or diagnosed epilepsy, the user should follow precautions recommended by his or her physician;... - Page 6 ENVIRONMENTAL CONDITION FOR TRANSPORT AND STORAGE Fragile; handle with care Keep dry Dispose of the battery-containing device according to local, state or federal laws. Properly recycle. Normal working ambient temperature: -5°C–40°C (23°F–104°F) Normal working ambient humidity: ≤80% Store and transport ambient temperature: -10°C–50°C (14°F–22°F) Store and transport ambient humidity: ≤90% SETUP Take the product and accessories out of the box, and snap the control unit onto the gel electrode pad.
- Page 7 OPERATING INSTRUCTIONS Please follow the step-by-step instructions below to operate your Theralief ™ device. 1. Check the battery used in the control unit. 2. Snap the control unit onto the white side of the gel electrode pad. 3. Remove the clear backing from the black side of the electrode pad and keep it in a safe place. Do not discard! Then stick the black side of the pad to your skin in an area where you feel pain.
- Page 8 STEP 1 CHECK THE BATTERY USED IN THE CONTROL UNIT The control unit comes with a built-in rechargeable battery, and can be used directly out of the box. If the LED light on the turned-on control unit keeps flashing (once per second), it means the battery is running out.
- Page 9 STEP 5 SELECT ONE OF THE STIMULATION MODES Press the “+” or “-” button and hold for 2 seconds to select the desired pulse mode indicated by the light flashing and sound beeping: 1, 2, 3, 4, or 5 times represents Mode 1 (combination), Mode 2 (62.5Hz), Mode 3 (12.5–55.6Hz), Mode 4 (1.2Hz), and Mode 5 (100Hz), respectively.
-
Page 10: Directions For Use
• Keeping the electrode pad covered with the clear backing after use will extend its lifespan. The electrode pad is disposable and should be replaced when it loses its adhesiveness. To purchase additional electrode pads, please contact Conair Corporation at 1-800-3-CONAIR. -
Page 11: Performance Specifications
Contact Conair for replacements at 1-800-3-CONAIR. Do not let the sticky side of the pad touch anything other than your skin. Be careful not to handle with greasy fingertips. -
Page 12: Troubleshooting
If the moisture does not help to make the pad adhere better, you will need to order a replacement. You can order a replacement at www.conair.com or call Conair for replacements at 1-800-3-CONAIR. - Page 13 Type BF applied part Attention, Consult accompanying documents Storage temperature & relative humidity Date of manufacture Guidance and manufacturer’s declaration – electromagnetic emission The device is intended for use in the electromagnetic environment specified below. The customer of the user of the device should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment –...
- Page 14 Guidance and manufacturer’s declaration – electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should assure that it is used in such an environment. Emission test IEC 60601 test level Compliance level Electromagnetic environment – guidance Floors should be wood, concrete or Electrostatic ±6 kV contact...
- Page 15 Guidance and manufacturer’s declaration – electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of the device should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment – guidance Portable and mobile RF communications equipment should be used no closer to any part of the device, including cables, than...
- Page 16 To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the device is used exceeds the applicable RF compliance level above, the device should be observed to verify normal operation.
- Page 17 • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by Conair Corporation, the manufacturer of this product and the party responsible for compliance, could void the user’s authority to operate the equipment.
-
Page 18: Limited One-Year Warranty
(U.S. AND CANADA ONLY) Conair will repair or replace (at our option) your control unit free of charge for 12-months from the date of purchase if the appliance is defective in workmanship or materials. To obtain service under this warranty, return the defective product to the service center listed below, together with your purchase receipt and $5.00 for... - Page 20 Please register this product at www.conair.com/registration SERVICE CENTER CONAIR CORPORATION Service Department 7475 North Glen Harbor Blvd. Glendale, AZ 85307 Visit us on the web at: www.conair.com ©2016 Conair Corporation stock.image Model TN100 15PS018177 IB-14094...
