Replas FLINDERS SETTING Assembly Instructions

FLINDERS
SETTING
2.2m
In Ground
TABLE:
1. Place table top face down on a flat surface.
2. Place Table supports into position.
3. Secure table supports to the table frame using the 40mm hex screws, taking care not to over tighten as this could
strip the thread.
NOTE: Do not tighten screws until all are in position.
BENCHES:
1. Place bench slats face down on a flat surface.
2. Attach bench supports to the bench frame using the 40mm hex screws, taking care not to over tighten as this could strip
the thread.
NOTE: Do not tighten screws until all are in position.
Installation
Once the setting has been is assembled, drill or dig holes as per installation diagram.
Place the supports of the assembled setting into the holes. Position the setting and ensure that it is well braced to prevent
movement and sagging. At this stage it is important to use a spirit level to check that the top is horizontal and the supports are
vertical.
Once satisfied that the setting is positioned correctly, fill the holes with concrete, making sure it is packed firmly beneath and
around the supports.
Once the concrete has set, remove the bracing.
TABLE:
1 X Table Top ‐ pre‐assembled
2 X Table Supports
12 X 12g x 40mm Hex Head screws
ASSEMBLY INSTRUCTIONS
IMPORTANT: Please read carefully before assembling.
COMPONENTS LIST
If you require further installation
assistance, please contact your supplier.
BENCHES:
2 X Bench Tops ‐ pre‐assembled
4 X Bench Supports
16 X 12g x 40mm Hex Head Screws
