- Page 1 Aeroex Technologies Inc. Oil Mist Collector Model ARO-4000 Multi-Stage Installation & Service Manual www.aeroex.com Sales 905-655-7295 sales@aeroex.com orderdesk@aeroex.com 01/20 www.aeroex.com orderdesk@aeroex.com...
-
Page 2: Table Of Contents
Table Of Contents Specifications…………………………………….………….…………3 Installation Instructions……….………..…………….……………4 Installation Kit.................5 Oil drain hose Kit................5 Electrical Connection..............6 Direction of rotation................6 Wiring Connection................7 Maintenance...................8 Filter Options Coolant..............9 Filter Options Oil................10 Dimensions..................11 Warranty..................12 01/20 www.aeroex.com orderdesk@aeroex.com... -
Page 3: Specifications
Model ARO-4000 Specifications AEROEX – Oil Mist Collector For highly effective separation of coolant and oil mists including smoke from metalworking machinery and oil reservoirs. Consisting of: Powdered coated mild steel housing. Motor and fan impeller Primary separation pack consisting of 1st stage ME pack and 2nd stage AG agglo pack, and 4 stage FB packs. -
Page 4: Installation Instructions
Installation Instructions • Mount mist collector level. • Units can be mounted directly on top of machines, on a post or on the wall. • Ensure that there is free space to change filters. • Minimize the length of ducting to avoid air flow loses. •... -
Page 5: Installation Kit
Installation Kit Three (3) standard installation kits as follows: Item Description Part # Stand 099AMP-0004 Oil Drain Hose Kit Item Description Part # Drain Hose Kit, c/w 099MPH-0013 1(a) Oil drain hose 10ft 099MPH-0004 1(b) Oil drain bracket A99SPM-0002 1(c) Nipple 099MPB-0001 1(d) -
Page 6: Electrical Connection
Machine mounted mist collectors can be wired into the CNC electrical control. Connect electrical wires on dual voltage motors (230/460/360) according to wire numbers on table. Direction of Rotation Motor: (ARO-4000) - Motor direction arrow is located on the motor - Start/Stop motor - Check rotation direction - If incorrect, switch 2 electrical connections, i.e. -
Page 7: Wiring Connection
Wiring Connection 01/20 www.aeroex.com orderdesk@aeroex.com... -
Page 8: Maintenance
Maintenance The mist collector can operate for long periods without maintenance. The maintenance period will depend on the type of oil, coolant & debris in air stream. Inspect the unit after 3 months, 6 months & 1 year to establish the maintenance interval. Some coolant concentrates will congeal requiring the 1 stage mechanical separator elements and the 2... -
Page 9: Filter Options Coolant
Filter Options Coolant Item # Description Quantity Part Number stage “ME” Mechanical Element A20FMS-0001 stage “AF” Coolant Filter A20FAF-0001 stage “CM” Coolant Mist Filter A20FCM-0004 stage “HF” HEPA Filter 95% @ 0.3 2000HF-2095 microns stage “HF” HEPA Filter HEPA 99.97% 2000HF-2099 @ 0.3 microns (Optional) -
Page 10: Filter Options Oil
Filter Options Oil Item # Description Quantity Part Number stage “ME” Mechanical Element A20FMS-0001 stage “DE” Demister Element A20FDE-0002 Stage “OM#5” Oil Mist Fibre Bed A20FOM-0005 Filter Stage “OM#7” Oil Mist Fibre Bed A20FOM-0007 Filter stage “HF” HEPA Filter 95% @ 0.3 2000HF-2095 microns stage “HF”... -
Page 11: Dimensions
Dimensions 01/20 www.aeroex.com orderdesk@aeroex.com... -
Page 12: Warranty
The Purchaser's sole remedy shall be as stated above. Aeroex Technologies will make good faith effort for prompt correction or adjustment with respect to any product that proves to be defective within warranty.
