Summary of Contents for FSI F-HVF1101
- Page 1 PORTABLE AIR HEATERS MANUAL FSI OIL INDIRECT FIRED AIR HEATER MODELS: F-HVF1101, F-HVF2101, & F-HVF3101 311 Abbe Rd. Sheffield Lake, Ohio 44054 Phone: 440-949-2400 Fax: 440-949-2900 Email: sales@fsinorth.com 03/16 Visit us on the web at www.fsinorth.com...
- Page 2 CONSTRUCTION HEATER GENERAL HAZARD WARNING READ INSTRUCTIONS CAREFULLY. READ AND FOLLOW ALL INSTRUCTIONS. PLACE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, LIGHT, ADJUST OR OPERATE THE HEATER. IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
- Page 3 TECHNICAL DATA F-HVF1101 F-HVF2101 F-HVF3101 112800 BTU/H 160400 BTU/H 276300 BTU/H 1060 CFM 1060 CFM 1950 CFM 0.86 GAL/H 1.23 GAL/H 2 GAL/H K-1 KEROSENE K-1 KEROSENE K-1 KEROSENE NO.1 OR NO.2 FUEL OIL NO.1 OR NO.2 FUEL OIL NO.1 OR NO.2 FUEL OIL...
- Page 4 IMPORTANT: READ AND UNDERSTAND THIS MANUAL PRIOR TO ASSEMBLING, STARTING UP OR CONDUCTING MAINTENANCE ON THIS HEATER. USING THE HEATER INCORRECTLY CAN CAUSE SERIOUS INJURY. KEEP THIS MANUAL FOR FURTHER REFERENCE. 1. DESCRIPTION This series of indirect heaters is particularly suited to heating medium to large-sized rooms or areas.
- Page 5 2. SAFETY INFORMATION (cont.) 2.1 REFUELLING: 2.1.1. Personnel appointed to carry out refueling must be qualified and fully familiar with this manual and current regulations on how to refuel heaters safely. 2.1.2. Only use the type of fuel specified on the heater’s identification plate. 2.1.3.
- Page 6 6. OPERATING PRINCIPLES A. Combustion chamber and burner, B. Fan, C. Motor, D. Pump, E. Tank, F. Chimney The pump draws fuel from the tank and brings it to the operating pressure. The fuel is brought to the nozzle that sprays it into the combustion chamber.
- Page 7 8. CLEANING THE FILTERS (CONT.) 8.1. FUEL TANK FILTER (pic 1) 8.1.1. Remove tank (A) cap. 8.1.2. Take out the filter (B) from the tank. 8.1.3. Clean the filter (B) from the tank. 8.1.4. Put the filter (B) back in the tank. 8.1.5.
- Page 8 11. PREVENTIVE MAINTENANCE SCHEDULE COMPONENT MAINTENANCE FREQUENCY MAINTENANCE PROCEDURE Fuel tank Clean once a year or as required Empty and rinse the tank with clean fuel (SEE PAR. 9.) Filters Clean or replace once a year or as required Clean the filters (SEE PAR. 8.) (make sure they are intact) Fuel pump filter Clean or replace once a year or as required...
