- Page 1 RD-10 10 Input / 10 Output Remote Monitor and Remote Control Manual Revision: 2010-08-10 Covers Firmware Revisions: 4.0 & Higher Covers PCB Revisions: American Communication Systems Discover the Power of Communications ™ http://www.ameradio.com TO ORDER – VISIT...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Specifications General Information Hardware Installation Operation Product Programming Technical Notes Contact Information... -
Page 3: Specifications
SPECIFICATIONS Voltage/Current: Operating Voltage 12 VDC Operating Current 15 mA LED Current 2 mA each Relay Current 17 mA each Audio Inputs Input Level 400 mVRMS Input Impedance 470KΩ Dynamic Range 25 dB Format DTMF SINAD Ratio 9 dB Band Width 2.5% Twist 10 dB... -
Page 4: General Information
GENERAL INFORMATION The RD-10 is a single function remote control and alarm, with status monitor for placement in the field. It has ten open collector outputs that can be set for momentary, latched, or repetitive On/Off output from a manual DTMF keypad, another RD-1, RD-10 or an RC-10. -
Page 5: Hardware Installation
HARDWARE INSTALLATION Be certain to follow standard anti-static procedures when handling any of Midian’s products. P1-1 to P1-10: Opto-Isolated Inputs: These are the high side status inputs of the opto isolators. See Isolator Terminal statement on P1-12. P1-11: V Com-2: This is a V common for inputs 5-10 of the optional opto isolators. In the schematic you will notice that one side of each opto isolator is connected to V Common. -
Page 6: Operation
If the output receives another command to turn on while the actual state of the output is still on, the on time will be reset. The RD-10 can be programmed to report the actual output state as opposed to the internal output state. - Page 7 The security timing is disabled when using the manual communication method to allow manual dialing from a hand held or mobile radio. The RD-10 transponds with an audible low→high (on) or high→low (off) tone sequence. All spontaneous reporting of input status, output status or alarms is disabled. However, the manual operator can query the RD-10 to transmit the output, input or alarm status.
- Page 8 Report Alarm Status #XXXG*4# XXX is the 0 to 3 digit base address assigned when the unit was programmed. G is the addressed I/O Group. The unit will report the status of the addressed alarm with a low→high or high→low tone sequence. For more information about alarm conditions please refer to the Help files in the Remote Programmer.
- Page 9 Security The RD-10 provides a secure mode of operation to eliminate false operation from spurious transmissions and helps thwart hacking attempts. The lead-in tone is timed at 200ms and the following tones are timed using a base of 50ms on time and 50ms inter-digit time.
-
Page 10: Product Programming
KL-3 Instruction Manual or the Remote Programmer online help files. To connect the RD-10 to the KL-3 cable, attach the ground lead of the KL-3 to P1-20 (Ground) of the RD-10, and the programming lead of the KL-3 to P1-16 (Programming Input) of the RD-10. NOTE: Attaching the wrong leads can lead to failure of the unit. -
Page 12: Technical Notes
TECHNICAL NOTES No technical notes are available at this time. MIDIAN CONTACT INFORMATION Midian Electronics Inc. 2302 East 22 Street Tucson, Arizona 85713 USA Orders: 1-800-MIDIANS Phone: 520-884-7981 Fax: 520-884-0422 E-mail: sales@midians.com Web: www.midians.com... - Page 14 This page intentionally left blank...
