- Page 1 iQ EV 2013 VEHICLE CHARGING OPERATIONS QUICK REFERENCE GUIDE GET INFORMED. ROLL.
- Page 2 Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Scion iQ EV. A word about safe vehicle operation This Quick Reference Guide is not a full description of Scion iQ EV operations.
-
Page 3: Table Of Contents
Emergency tire puncture repair kit 31 Floor mat installation Seat belts Star Safety System 32-33 Tire Pressure Monitoring (warning) System Visit your Toyota or Scion dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. -
Page 4: Overview
OVERVIEW Instrument panel Power outside rearview mirror controls Headlight and turn signal controls Steering wheel audio controls* Wiper and washer controls Front passenger occupant classification indicator/ Front passenger seat belt reminder light Emergency flasher button Navigation system* Air Conditioning controls HWD (Heated Windshield Defroster) switch Rear window defogger button Charging timer switch... -
Page 5: Hood Release
Recharge inlet door opener switch AUX port/USB port* Door lock switch Seat heater switches Power outlet Power switch Tilt steering lock release Tire Pressure Monitoring (warning) System reset button Hood release * For details, refer to the “Navigation System Owner’s Manual.”... -
Page 6: Indicator Symbols
(alarm will sound if speed is over 12 mph) 12-volt battery charging system warning* Traction battery warning* If indicator does not turn off within a few seconds of starting EV system, there may be a malfunction. Have vehicle inspected by your Toyota or Scion dealer. - Page 7 Plug-in indicator (yellow/green) Output control warning* SOC (State Of Charge) warning Master warning* Open door warning Airbag SRS warning* Low Tire Pressure Warning* Front passenger occupant classification indicator Headlight low/high beam indicator Turn signal indicator Slip indicator* Electric power steering system warning* Anti-lock Brake System warning* Immobilizer system indicator ECO Driving Indicator Light*...
-
Page 8: Keyless Entry
OVERVIEW Charging inlet Normal charging inlet Quick charging inlet (if equipped) Unlock Unlock Open Open Push Keyless entry Locking operation Unlocking operation Push ONCE: Driver door TWICE: ALL doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will Push relock for safety. - Page 9 Smart Key system Start function Green indicator ON Depress brake Push pedal Carrying NOTE: Shift position must be in Park and brake pedal depressed. Power (without starting EV System) Without depressing the brake pedal, pressing the “POWER” switch will change the operation mode in succession from: ACCESSORY Accessories such as the radio will operate.
-
Page 10: Motor Maintenance
OVERVIEW Hood release Pull Pull up latch and raise hood Engage support rod Motor maintenance Windshield washer fluid tank Inverter coolant reservoir NOTE: Regularly scheduled maintenance will help extend the life of your vehicle and maintain performance. Please refer to the “Warranty & Maintenance Guide.”... -
Page 11: Electric Vehicle System
ELECTRIC VEHICLE SYSTEM Electric Vehicle System The Scion iQ EV uses electricity in a rechargeable traction battery to power the electric motor. The driving range is extended by using regenerative braking to store electricity in the traction battery. This technology is clean and has a low... -
Page 12: Charging
ELECTRIC VEHICLE SYSTEM Charging equipment Charging indicator Charging inlet light Normal charging inlet Charging inlet cap Quick charging inlet (if equipped) Normal charging cable Recharge inlet door (charging port lid) The charging cable included with the vehicle is designed to be connected only to an AC 120V power source. -
Page 13: Detection Function
Charging The Scion iQ EV may be charged immediately, or scheduled to charge at a specific time. Before charging, it is recommended that: -Parking brake is securely set with shift position in “P” -All lights are turned off -The POWER switch is OFF Start charging Step 1 Plug the charging cable into the outlet of the external power source. - Page 14 ELECTRIC VEHICLE SYSTEM Step 3 Press the recharge inlet door opener switch to open the recharge inlet door. The recharge inlet door will not open when the “READY” indicator is on or the power switch is in ON mode. Step 4 Open the charging inlet cap by releasing the clip. Push to open Step 5 Remove the charging connector cap.
- Page 15 Step 6 Insert the charging connector into the charging inlet. - Do not press the latch release button when inserting the connector. - Align the guides and push connector in straight and firmly Guide until it clicks. Step 7 Confirm that the charging indicator is illuminated. (When the charging timer function is in use, the light will turn off several seconds after illuminating.) - Charging will not start if the...
- Page 16 ELECTRIC VEHICLE SYSTEM Charging timer Use of the charging timer can suppress deterioration of the hybrid battery (traction battery) and off-peak electricity can be used effectively. Setting the charging timer Step 1 Stop the vehicle and press the charging timer switch. The Multi-Information Display will switch to the charging timer display.
- Page 17 Step 4 Adjust the set time using the time adjustment button. Push knob to adjust hours/minutes Turn knob to switch between hours/minutes Step 5 Press and hold the charging timer switch. Once set, the time display will change from flashing to solid. Step 6 Turn the POWER switch off.
- Page 18 ELECTRIC VEHICLE SYSTEM Start time vs. Finish time setting Either start or finish time can be scheduled (they cannot be scheduled simultaneously). Start time setting mode Finish time setting mode Timer charging finishes when the traction battery is fully charged. Charging starts at an unspecified time so that the battery will be fully charged at approximately the scheduled finish time.
- Page 19 After charging Step 1 Pull the charging connector toward you while pressing the latch release button. Step 2 Attach the charging connector cap. Step 3 Close the charging inlet cap, and then close the recharge inlet door. Step 4 Remove the plug from the outlet when the charging equipment will not be used for a long period of time.
-
Page 20: Remote Climate Control
ELECTRIC VEHICLE SYSTEM Remote Climate Control While charging with an external power source, the heater or Air Conditioning can be operated before getting in the vehicle. If the Air Conditioning system is remotely activated while charging, charging will stop but resume when the Air Conditioning system goes off. - Page 21 Multi-Information Display-Charging information Remaining charging time Charging information is displayed on the Multi-Information Display. If the POWER switch is turned to ON mode during charging, the estimated amount of time needed for charge completion will be displayed. After confirming, switch the POWER switch to OFF to turn off the display. The POWER switch will turn off automatically after approximately two minutes.
- Page 22 In the unlikely event that the electrical leakage detection function is not operating properly, contact your Toyota or Scion dealer as soon as possible. Check that it is operating properly by following the procedure below. Step 1 Insert the charging cable into the outlet of the external power source.
-
Page 23: Features/Operations
FEATURES/OPERATIONS Transmission Park* Reverse Neutral Drive Regenerative brake Maximum regenerative brake * The power switch must be in the “ON” mode and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides regenerative braking downhill. For best power economy during normal driving conditions, always drive with the shift lever in the “D”... - Page 24 FEATURES/OPERATIONS Seat adjustments-Front Passenger seat only Seat position (forward/backward) Seatback angle Seat-Folding down rear seat (2) Push (1) Stow the seat belt buckles (4) Fold down (3) Remove...
- Page 25 Lights & turn signals Headlights Low beam Auto Headlights High beam flasher Parking lights High beam Turn signals Right turn Lane change Lane change Left turn Windshield wipers & washers Front Single wipe Interval wipe Pull to wash and wipe Slow Fast Rear...
- Page 26 FEATURES/OPERATIONS Windows Driver side Window lock switch Down Automatic operation Push the switch completely down or pull it completely up and release to fully open or close. To stop window partway, lightly push the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable.
- Page 27 Light control-Instrument panel Brightness control Tilt steering wheel Angle Lock release lever Hold wheel, push lever down, set angle and return lever. NOTE: Do not attempt to adjust while the vehicle is in motion. Seat heaters Left front seat Right front seat...
-
Page 28: Air Conditioning/Heating
FEATURES/OPERATIONS Air Conditioning/Heating Recirculate cabin air (fresh air when OFF) Air Conditioning ON/OFF Use fresh air to quickly cool interior, then change to recirculate for cooler air. Windshield airflow/defogger “MAX” mode Use this mode for quick warming or cooling. Airflow vent* In “... -
Page 29: Audio
Audio Turn to tune stations or select channel, track or chapter Turn Seek station or ON/OFF channel, or select track, file or chapter Display radio control screen Eject disc Display media control screen Display “Setup” screen Refer to the “Navigation System Owner’s Manual” for instructions and more information. -
Page 30: Aux Port/Usb Port
FEATURES/OPERATIONS AUX port/USB port AUX port By inserting a mini plug (not included) into the AUX port, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. USB port By connecting a USB memory or USB-compatible portable audio device to the USB port, you can listen to music from the portable audio device or USB memory through the vehicle’s speaker system. - Page 31 Hill-start Assist Control (HAC) Brake pedal HAC helps prevent rolling backwards on an incline. To engage, push further down on brake pedal while at a complete stop until a beep sounds and slip indicator illuminates. HAC holds for approximately two seconds after releasing brake pedal. Refer to the Owner’s Manual for more details.
-
Page 32: Safety And Emergency Features
SAFETY AND EMERGENCY FEATURES Door locks Driver’s use Unlock Lock Front passenger’s use Lock Unlock Seat belts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. -
Page 33: Emergency Tire Puncture Repair Kit
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota or Scion dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. - Page 34 SAFETY AND EMERGENCY FEATURES Star Safety System All new Toyota vehicles come standard with the Star Safety System , which combines Vehicle Stability Control (VSC), Traction Control (TRAC), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) and Smart Stop Technology (SST). Vehicle Stability Control (VSC) VSC helps prevent loss of traction during cornering by reducing power from the EV system and applying brake force to selected wheels.
- Page 35 Smart Stop Technology (SST) Smart Stop Technology automatically reduces driving torque when the accelerator and brake pedals are pressed simultaneously under certain conditions. Floor mat installation There are two types of Toyota floor mats: carpeted and all-weather. Each vehicle has model-specific floor mats. Installation is easy. To keep your floor mat properly positioned, follow these steps: • Only use floor mats designed for your specific model.
- Page 36 Have a Question? Contact PHONE 1.866.70.SCION MAIL SCION 19001 S. Western Ave. D102, P .O. Box 2742 Torrance, CA 90509-2742 www.scion.com ©2013 Scion, a marque of Toyota Motor Sales, U.S.A., Inc. Printed in U.S.A. 1/13 12-TCS-05917 00505-QRG13-IQEV...
