Summary of Contents for AvLab AcePro-CE25-1
- Page 1 AcePro-CE25-1 8-Port HDMI 2.0 Splitter with EDID Management Quick Installation Guide www.avlab.com.tw support@avlab.com.tw Made in Taiwan AP4-0098A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................ 2 FEATURES ........................2 PACKAGE CONTENTS ...................... 3 SPECIFICATIONS ......................3 PANEL DESCRIPTIONS ....................4 HARDWARE INSTALLATION ..................... 5 CONNECTION DIAGRAM ....................5 NOTICE ..........................6 WARRANTY ........................7... -
Page 3: Introduction
1. NOT supports (1) Resolution downscaling from 4K2K@60 4:2:2 to 1080P (2) Frame rate conversion (3) 4K2K@60 4:2:2 to 4K2K@60 4:2:0 2. AcePro-CE25-1 can bypass 4K HDR data content, but can NOT process it and make HDR content 100% it into 1080p... -
Page 4: Package Contents
PACKAGE CONTENTS 1x 8-Port HDMI 2.0 Splitter (AcePro-CE25-1) 1x DC 5V wall wart 2x Screw 1x User Manual SPECIFICATIONS Model Name AcePro-CE25-1 Technical Role of usage 1x8 Distribution Amplifier (Splitter) HDMI compliance HDMI 2.0a HDCP compliance HDCP 2.2 / 1.4... -
Page 5: Panel Descriptions
PANEL DESCRIPTIONS 1. Power LED: Lights on when device is ready 2. Signal LED: Input signal LED indicator 3. Signal LED: Output 1-8 signal LED indicator 4. Micro-USB: For technical support only [firmware update] 5. EDID MODE: 0: Ultra HD (4K2K@60) 8/10/12bit 3D HDR video & 7.1ch audio 1: Ultra HD (4K2K@60) 8/10/12bit 3D HDR video &... -
Page 6: Hardware Installation
HARDWARE INSTALLATION Broadcasts HDMI signal to 8 HDMI displays! 1. Switch off all devices, including monitors. 2. Connect to the displays. 3. Connect an HDMI source (such as a Blu-ray Disc player) to the HDMI In. 4. Plug in 5V DC power supply. 5. -
Page 7: Notice
NOTICE is that the display has to support at least Full HD. If default Full-HD EDID still cannot work, user (Please note that the display with lowest resolution must be connected to output 1) Select to Mode 5 - Full-HD(1080p@60) 8bit 2D video &... -
Page 8: Warranty
The AceProAV will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the AcePro-CE25-1 features and specifications is subject to change without further notice. - Page 9 Feb, 2020 Ver. A © Copyright by AceProAV, LLC. All rights reserved.
