A S S E M B LY I N S T R U C T I O N S
4" / 5" EZ Mount Post for Arbors
9 1/8 in [23.2 cm]
17 in [43.1cm]
Please read through before starting installation.
Check Box for These Contents
In the event of missing or defective parts please call our customer service department at
1 800 282 9346 (Mon. to Fri. 8:00 AM to 4:00 PM EST).
Removable Donut (2) 4in Part Number 11145 / 5in Part Number 11148
1.
Pipe Anchor Assembly (1) Ø1 5/8" x 26 1/8" - 11147
2.
3.
5/8" (16mm) Self-Augering Stainless Steel Screw (4) 20016
Tools You Will Need
· Sledge Hammer (5 or 10 lbs)
· Cordless Drill with Phillips Bit
· Spirit Level
· Adjustable Wrench
· Tape Measure
Ø3 3/4 in [9.5cm] for 4" EZ Mount
Ø4 3/4 in [12.1cm] for 5" EZ Mount
Ø1 5/8 in
[4.1 cm]
1
2
3
V1.0/082718
