Summary of Contents for Altimium IPC-500
- Page 1 Manuel d'utilisation IPC-500 Contrôleur IP Streaming All Rights Reserved Version: IPC-500V1.0.1...
- Page 2 Important Safety Instructions 1. Do not expose this apparatus to 6. Clean this apparatus rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. 7. Unplug this apparatus 2.
-
Page 3: Table Of Contents
Contrôleur IP Streaming Table of Contents Introduction ............................2 Overview ..........................2 Features ............................ 3 Package Contents ........................4 Specifications .......................... 5 Panel Description ........................7 Front Panel ........................7 Rear Panel ........................8 Warranty Terms and Conditions ....................11 01.64.13.31.00 www.altimium.com... -
Page 4: Introduction
Contrôleur IP Streaming Introduction Overview IPC-500 (hereinafter referred to as IP controller) is an IP control box that is used control device controlling, configuring and managing encoders and decoders on the local area network. It integrates Ethernet ports RS232 ports, offering integration-friendly control features——LAN (Web GUI &... -
Page 5: Features
Discover encoders and decoders automatically Supports matrix switching between encoders and decoders Compatible with the configuration file from PC configurator to quickly perform operations on encoders and decoders, such as matrix and video wall Web configuration page 01.64.13.31.00 www.altimium.com... -
Page 6: Package Contents
1 x Power Supply (12 V 1A DC) 1 x Detachable Plug 1 x Phoenix Connector (Male, 3.5 mm, 6 pins) 2 x Mounting Ear 5 x Label Card (49 mm x 15 mm) 01.64.13.31.00 www.altimium.com... -
Page 7: Specifications
Operating Temperature 10% ~ 90%, non-condensing -4°F ~ 140°F (-20°C ~ +70°C) Storage Temperature 10% ~ 90%, non-condensing Voltage: ±1000 V Surge Protection (Tested ten times respectively for the positive and negative voltages) ESD Protection Human body model: 01.64.13.31.00 www.altimium.com... - Page 8 3.67'' x 1.02'' x 5.46'' 170 mm x 80 mm x 250 mm Case Dimension (W x H x D) 6.69'' x 3.15'' x 9.84'' Weight 0.38 kg / 0.84 lbs (without accessories) Certification CE, FCC, RoHS compliant 01.64.13.31.00 www.altimium.com...
-
Page 9: Panel Description
RESET button for five or more seconds, and then release it. It will reboot and restore to its default settings. RESET Note: When the default settings are restored, your custom data is lost. Therefore, exercise caution when using the RESET button. 01.64.13.31.00 www.altimium.com... -
Page 10: Rear Panel
Autodetected duplex level Ethernet port indicators Green Link LED: this green colored LED lights when IP controller actively communicates with a network. Amber Activity LED: this amber colored LED flickers as IP controller is connected to a network. 01.64.13.31.00 www.altimium.com... - Page 11 Contrôleur IP Streaming No. Name Description 1 x LAN2 (C): Connects to a third party controller for controlling, configuring and managing IPC-500 encoders and decoders through LAN control (Web GUI & Telnet). Default protocol: IP Address 192.168.11.243 Subnet Mask 255.255.0.0 Gateway 192.168.11.1...
- Page 12 IP controller for device control process. Connects to a supplied 12 VDC 1 A power DC 12V adapter. 01.64.13.31.00 www.altimium.com...
-
Page 13: Warranty Terms And Conditions
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from a ALTIMIUM authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 14 ALTIMIUM 587 Avenue Blaise Pascal 77550 MOISSY-CRAMAYEL Tél : 01.64.13.31.00 Fax: 01.60.29.62.70 Mail: contact@tesca-audio.com Web: www.altimium.com...
