Bathroom Organiser
Assembly Instructions
- please keep for future reference
260.96.089
464/3944
Dimensions
Width - 16cm
Depth - 48cm
Height - 58cm
Important
– Please read these instructions fully before starting assembly
Issue 6 - 18/05/2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the 260.96.089 and is the answer not in the manual?

Questions and answers

Summary of Contents for JD Williams 260.96.089

  • Page 1 Bathroom Organiser Assembly Instructions - please keep for future reference 260.96.089 464/3944 Dimensions Width - 16cm Depth - 48cm Height - 58cm Important – Please read these instructions fully before starting assembly Issue 6 - 18/05/2017...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, recommend the use page 2 this could cause damage.
  • Page 3: Tools Required

    Components - Panels Please check you have all the panels listed below Components - Fittings Note: may be supplied than are required. Male Camlocks x 18 Female Camlocks x 18 35mm Screws x 4 12mm Screw x 28 Hinge x 4 Runners (2 Set) Dowel x 4 push here...
  • Page 5 Assembly Instructions Step 1 1. Connect 4 x Hinges F to Panels 1 and 2 using 2 x Screw E per Hinge. Total 8 Screws. Step 2 1. Connect Panels 10 and 11 to Panel 12 as shown using 4 x Screw Step 3 1.
  • Page 6 Assembly Instructions Step 4 1. Connect 2 x Drawer Runners D1 to Panels 10 and 11 as shown using 3 x Screw E per Runner. 6 Screws Total Step 5 1. Insert 7 x Male Camlocks and 2 x Dowels into Left Side Panel 3.
  • Page 7 Assembly Instructions Step 6 1. Connect Side panels 3 and 4 to panles 5 7 and 8 as shown by locating Male camlocks into adjacent holes. Insert 14 x Female Camlocks C as shown and Tighten with a Phillips Screwdriver For more information on camlocks, see the m“using Camlocks”...
  • Page 8 Assembly Instructions Step 8 1. Slide Drawer into position. push here Glider Mechanism Assembly Complete...
