Insignia NS-DLS86BK Quick Setup Manual

NS-DLS86BK_18-0181_QSG_V1_EN.ai 1 3/27/2018 3:27:31 PM NS-DLS86BK_18-0181_QSG_V1_EN.ai 1 3/27/2018 3:27:31 PM
QUICK SETUP GUIDE
86" Compact
Folding
Light Stand
NS-DLS86BK

PACKAGE CONTENTS

• Light stand
• Carrying case
• Quick Setup Guide

FEATURES

• Legs fold in a reversible way to minimize folded height
• Versatile and compact for easy set up
• Five-section light support with screw knob section locks
• Perfect for studio lights, flash heads, umbrellas, reflectors, and
background supports
• Offers sturdy support in the studio and is easy to transport to
other locations
• Compatible with cameras that have a tripod mount
Before using your new product, please read these instructions to prevent any damage.
V1
FINAL
FOR PRINT
Flat size (W×H): 9 × 12 in. (228.6 × 304.8 mm)
Final folded size: 9 × 6 in. (114.3 × 304.8 mm)
# ITEM
1 1/4" mounting
screw
2 Section knob
3 Leg position
knob
4 Leg extension
knob
DESCRIPTION
Use this screw to mount a device, such as
a studio light, flash head, or umbrella
bracket.
Note: Some studio flash heads or umbrella
brackets slide all the way over this mount area
and fasten in place with a locking clamp.
• Tighten to lock each section in place.
• Loosen to extend or shorten each
section.
• Tighten to lock the leg positions.
• Loosen to position the legs.
• Tighten to lock the leg extensions.
• Loosen to extend or shorten the leg
extensions.
