Owner's Manual
HTX-8800-II
Ultra HD/4K 8x8 HDMI to HDBaseT Matrix Switcher
with POE and HDCP 2.2
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com
Advertisement
Table of Contents
Summary of Contents for Dtrovision PureLink HTX-8800-II
- Page 1 Owner’s Manual HTX-8800-II Ultra HD/4K 8x8 HDMI to HDBaseT Matrix Switcher with POE and HDCP 2.2 PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...
-
Page 2: Table Of Contents
PureLink by Dtrovision ABLE OF ONTENTS Chapter 1. Product Overview, Operation & Specification 1.1 Safety Precautions --------------------------------------------------------------- 1.2 Declaration of Conformity --------------------------------------------------------------- 1.3 What’s in the Box --------------------------------------------------------------- 1.4 Product Introduction --------------------------------------------------------------- 1.5 Front View --------------------------------------------------------------- 1.6 Front Panel Button Operation ----------------------------------------------------- 1.7 Rear View ---------------------------------------------------------------... -
Page 3: Safety Precautions
PureLink by Dtrovision Chapter 1. Introduction 1.1 Safety Precautions • All safety instructions should be read and understood before the unit is operated. • The owner’s manual and safety instructions should be retained for future reference. • Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth only. -
Page 4: Declaration Of Conformity
89/336/EEC (MC) and 73/23/EEC (Low Voltage Equipment Safety), and/or CPU Boards and Power Supplies used Council Directive 93/68/EEC with Matrix, Dtrovision LLC, 535 E Crescent Ave Ramsey, NJ 07446 201-488-3232, declares under sole responsibility, that the product identifies with 93/66/EEC of the Council Directive Low Voltage Equipment Safety. -
Page 5: Product Introduction
PureLink by Dtrovision 1.4 Product Introduction The new HTX-8800 II Ultra HD/4K HDMI to HDBaseT outs with POE and HDCP 2.2 provides switching for up to eight (8) HDMI to any eight (6) HDBaseT outputs and 2 HDMI outputs. PureLink’s legendary EDID/HDCP Management System, consistently praised by system integrators as the most reliable in the industry. -
Page 6: Front Panel Button Operation
PureLink by Dtrovision POWER: Main power switch ON / OFF DISPLAY: View menu and system mode MENU: EDID setup menu UP: Up button DOWN: Down button ENTER: Execution button 1.6 Front panel button operation Creating a switching • Press Output # button •... - Page 7 PureLink by Dtrovision EDID handshake may sound simple; however, with multiple peripheral devices within the chain, display's EDID information easily get lost or blocked while it is traveling to the source device. HTX series matrix switcher provides Auto EDID management system to meet today's sophisticated digital connectivity integration environment.
-
Page 8: Rear View
PureLink by Dtrovision 1.7 Rear View of HTX-8800-U <Back Panel> (Figure 1-2) 1. GND: Connect the Housing to the ground. 2. IR EXT: If the front IR sensor of unit is obstructed or the unit is installed in a closed area out of infrared line of sight, the IR RX receiver included in the package can be inserted to this IR EXT port to extend the IR. - Page 9 PureLink by Dtrovision OWER LED: System power indicator. 2. ARC LED: ARC status indicator. 3. ARC Button: ARC function on/off. Enable ARC: LED ON Disable ARC: LED OFF 4. DC 24V: Connects 24V/1A adaptor to AC wall outlet for power supply. (Don’t need this power supply if connecting to POC supported Matrix) 5.
- Page 10 PureLink by Dtrovision <Application diagram>...
-
Page 11: Product Specification
PureLink by Dtrovision 1.9 Product Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 and HDCP 1.4 Video Bandwidth 18 Gbps up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, Video Resolutions and 1080P 3D@60Hz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, Color Depth 8-bit,10-bit,12-bit HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby (Pass-through) - Page 12 PureLink by Dtrovision Dimensions 483mm [W] x 373mm [D] x 88.6mm [H] Weight 6.7Kg Power Supply Input:AC100~240V 50/60Hz Power Consumption 85W (Max) Operation 32 - 104°F / 0 - 40°C Temperature Storage temperature -4 - 140°F / -20 - 60°C Relative Humidity 20 - 90% RH (no condensation)
-
Page 13: Ir Remote Control
PureLink by Dtrovision 1.10 IR remote control 1.11 Power on /Standby：Power on/off this device. 1.12 Input port selection area：Press these buttons to select input 1-8. Press forward/backward button will cycle from input 1-8. 1.13 Output port selection area：Press these buttons to select output A-H, including ALL. -
Page 14: Ir Control
PureLink by Dtrovision 1.15 IR control The matrix is not only a switcher and extender of multiple HDMI signals to HDMI receivers located remotely, it also passes IR control signal through the IR call-back system to the matrix and HDMI sources. Two-way IR Call –back between matrix, sources and displays from multiple locations. - Page 15 PureLink by Dtrovision 1. At Matrix End: Inset the 3.5mm jacks of the IR TX Emitters included in package into the IR TX Emitter ports at the rear of the matrix corresponding input. The IR signal is added to the HDMI of the input devices, for example, if the user is watching Blue-ray on input 1, the IR signal will be directed through the IR TX1 socket to control the device.
-
Page 16: Cable Termination
PureLink by Dtrovision 1.16 Cable Termination • CATx (HDBaseT) cable • RS-232 (HTX matrix switcher) • LAN cable • RS-232 (HTX extenders) CATx (HDBaseT) Cable Termination HTX series matrix switcher and extenders are designed with TIA/EIA-568-B Standard. Please ensure that each PIN layout of the cable is corresponding with the picture below before connecting the cable. - Page 17 PureLink by Dtrovision TIA/EIA-568B Signal Wire color Digital RGB Orange/ White TMDS Data2+ Orange TMDS Data2- Green/ White TMDS Data1+ Blue TMDS Data0+ Blue/ White TMDS Data0- Green TMDS Data1- Brown/ White TMDS Clock+ Brown TMDS Clock- PureLink offers TotalWire CAT-X high performance cable for your CATx cable needs. PureLink also offers extended warranty of HTX products when CX cables are used together.
- Page 18 PureLink by Dtrovision RS-232 Cable Termination (for Control) Note) Straight cable must be used for the communication with HTX series matrix switcher The following table shows the pinout of the RS-232 connector. DB9 cables are available with male-to-male, female-to-female, and male-to-female connectors. HTX series matrix switcher's RS-232 port uses a female DB9 connector and therefore requires a cable with a male connector.
-
Page 19: Installation Guidelines
PureLink by Dtrovision Straight-through Cable End 1 Wire Color End 2 Wire Color Orange/ White Orange/ White Green Green Green/ White Green/ White RS-232 Cable Termination (for HTX receiver pass-thru) Blue Blue 3-pin Phoenix connector is used for RS-232 communication Blue/ White Blue/ White between HTX matrix switcher... - Page 20 PureLink by Dtrovision Default LAN communication parameters: IP address: 192.168.0.100 Mac address: 0x00,0x15,0x09,0x22,0x4c,0x87...
-
Page 21: Chapter 2. Communication Code Configuration
PureLink by Dtrovision Chapter 2. Communication Code Configuration 2.1 Control Programmer’s Guide (Code Structure and Examples) This section is designed for programmers who wish to create their own control programs using the command code. All PureLink digital matrix routers provide a simple character stream control used by external control devices attached to a PureLink device. -
Page 22: General Rules For Command Codes
PureLink by Dtrovision 2.4 General Rules for Command Codes The commands are coded in ASCII and HEXA. Please refer to Table 2.1 on pg. 17 for detailed descriptions of keys and functions. A basic command code setup is shown below; Ex) *999CI01O01! ... -
Page 23: Command Ack Value Response
PureLink by Dtrovision Table 2.1 Command Codes Characters Table The table below shows command code characters (keys), which are used to generate control commands, their functions, and short function descriptions. Function Description and Example Byte ASCII 0x2A Start the command Header Code 0x21 End the command... -
Page 24: Connecting Switches
PureLink by Dtrovision Router ID Error Indicates that the wrong ID number was entered Command Code Ack Value Examples Command Code Ack Value as appears in the control Explanation of Result Entered program *999CI01O01! *255sC I01O01 ! The command was successfully executed The command was not executed because *999CO01! ... -
Page 25: Disconnecting Switches
PureLink by Dtrovision *999CI01O01-04! Connect Input 1 to Output 1, 2, 3, and 4 *999PTP! Connect Input 1 to Output 1, Input 2 to Output 2, Input 3 to Output 3 and Input 4 to Output 4 2.7 Disconnecting Switches The characters and numbers in a Disconnect command tell the system which input or output to disconnect. - Page 26 PureLink by Dtrovision EDID Setting *999EDIDI01E3! p : write E3 EDID (1080p, HD audio) to input # 1 List of EDID 1080p, Stereo Audio 2.0 1080p, Dolby/DTS 5.1 1080p, HD Audio 7.1 1080i, Stereo Audio 2.0 1080i, Dolby/DTS 5.1 1080i, HD Audio 7.1 3D, Stereo Audio 2.0 3D, Dolby/DTS 5.1 3D, HD Audio 7.1...
-
Page 27: Connection Status Check
PureLink by Dtrovision 2.8 Status Check A connection status can be checked to confirm that the switch has been correctly executed or to confirm correct routing to multiple outputs. The characters and numbers in a status command tell the system which input or output to check. 1. -
Page 28: Chapter 3. Additional Information
PureLink by Dtrovision Chapter 3. Additional Information 3.1 Manufacturer’s Warranty (3-Years) PureLink warrants this HTX series matrix switcher to be free from defects in workmanship and materials, under normal use and service, for a period of three (3) year from the date of purchase from PureLink or its authorized resellers.
