- Page 1 AcePro-CEC4-1 4K HDMI HDBaseT Extender with IR & PoC Quick Installation Guide Transmitter Receiver www.avlab.com.tw support@avlab.com.tw Made in Taiwan AP4-0096A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................ 2 FEATURES ........................2 SPECIFICATIONS ......................3 PANEL DESCRIPTIONS ....................4 PACKAGE CONTENTS ...................... 5 CONNECTION DIAGRAM ....................5 IR PASS-THROUGH ......................6 HDMI PIN DEFINITION ...................... 7 HARDWARE INSTALLATION..................... 7 NOTICE ..........................8 WARRANTY ........................9... -
Page 3: Introduction
The AcePro-CEC4-1 includes two units: transmitting unit AcePro-CEC4-1-TX and receiving unit AcePro-CEC4-1-RX. The transmitting unit is used to capture the input HDMI / DVI signals with IR control packets and carry the signals via one cost effective Cat.5/5e/6 cable. The receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR signals. -
Page 4: Specifications
SPECIFICATIONS Model Name AcePro-CEC4-1 Technical Role of usage Transmitter [TX] HDMI compliance HDMI Deep Color, full 3D & 4K2K@30 HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 / 4K2K@30 HDMI over UTP... -
Page 5: Panel Descriptions
5. Power LED: Power indicator LED 6. Link LED: Link indicator LED 7. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to the receiving unit AcePro-CEC4-1- Receiving unit ► AcePro-CEC4-1-RX 1. HDMI OUT: Connect to a HDMI display with a HDMI male-male cable 2. -
Page 6: Package Contents
PACKAGE CONTENTS 1x 4K HDMI HDBaseT Extender (AcePro-CEC4-1[TX & RX]) 1x IR blaster 1x IR receiver 1x 12V DC power supply 4x Screw 1x User Manual CONNECTION DIAGRAM... -
Page 7: Ir Pass-Through
IR PASS-THROUGH [IR Extenders] IR Blaster IR Receiver [IR Sockets] IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR receiver from the other end to control the devices corresponding to the IR signals. IR RECEIVER: plug in the IR receiver to receive all IR command signals from the IR remote controls of the corresponding devices. -
Page 8: Hdmi Pin Definition
4. Connect a Cat-5/5e/6 cable between the transmitting and receiving units. 5. Make sure this Cat-5/5e/6 cable is tightly connected and not loose. 6. Plug in 12V DC power supply unit to the power jack of the receiving unit AcePro-CEC4-1-RX or the transmitting unit AcePro-CEC4-1-TX. -
Page 9: Notice
NOTICE 1. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B. 2. Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets. -
Page 10: Warranty
1 year from the date of purchase from the AVLT-POWER or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The AVLT-POWER, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surge. - Page 12 Oct, 2019 Ver. A © Copyright by AVLT-POWER, LLC. All rights reserved.
