Starkey Hearing Technologies SURFLINK Operation Manual

Mini mobile adapter
Hide thumbs Also See for SURFLINK:
Table of Contents

Advertisement

Quick Links

Download this manual
MINI MOBILE ADAPTER
O P E R AT I O N S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SURFLINK and is the answer not in the manual?

Questions and answers

Related Manuals for Starkey Hearing Technologies SURFLINK

Summary of Contents for Starkey Hearing Technologies SURFLINK

  • Page 1 MINI MOBILE ADAPTER O P E R AT I O N S M A N U A L...
  • Page 2 SurfLink Mini Mobile Adapter is IMPORTANT: ONLY compatible with SurfLink Remote Microphone 2.

  • Page 3: Table Of Contents

    Table of Contents Introduction Basic Use Controls Overview Operation Low Battery and Charging Multi-Function Push-Button Power On/Off Bluetooth Pairing Interacting with Phone Calls Listening to Music Resetting Typical Use Cases Troubleshooting Regulatory Notices...

  • Page 4: Introduction

    Prior to use, both SurfLink Remote Microphone 2 and SurfLink Mini Mobile Adapter will need to be separately set up. SurfLink Remote Microphone 2 will be synced to your hearing instruments. SurfLink Mini Mobile Adapter will be paired to your...

  • Page 5: Basic Use

    Basic Use To quickly start using SurfLink Mini Mobile Adapter: 1. Ensure SurfLink Remote Microphone 2 has been properly setup with your hearing instruments and is in powered on state. 2. Insert the male microUSB jack on SurfLink Mini Mobile Adapter into SurfLink Remote Microphone 2’s...
  • Page 6 SurfLink Mini Mobile Adapter, press its push- button for 2 seconds and release when the green LED appears. 4. Put your Bluetooth device into pairing mode. NOTE: Some devices may ask for the SurfLink Mini Mobile Adapter PIN, which is 0000.
  • Page 7 LED is slowly pulsing, double-click the push-button. The LED starts rapidly blinking blue, which puts SurfLink Mini Mobile Adapter into Bluetooth Pairing Mode. 6. On your Bluetooth device, select SurfLink Mini to complete the pairing process. 7. A green LED...
  • Page 8 When you hear the incoming call ringtone in your hearing instruments, briefly press and release the push-button on SurfLink Mini Mobile Adapter. o Speak into SurfLink Mini Mobile Adapter microphone. o To end the call, briefly press and release the push-button.
  • Page 9 9. To turn off SurfLink Mini Mobile Adapter, press the push- button for 2 seconds and release it. The red LED briefly appears to provide confirmation.

  • Page 11: Controls Overview

    1. Male MicroUSB Jack Attaches SurfLink Mini Mobile Adapter to SurfLink Remote Microphone 2. 2. Multi-Function Push-Button Provides control over the operational state of SurfLink Mini Mobile Adapter. 3. LED Indicator Identifies the current state of SurfLink Mini Mobile Adapter. 4. Built-In Microphone Picks up your voice and transmits to caller during phone calls.

  • Page 12: Operation

    Operation Low Battery and Charging If SurfLink Mini Mobile Adapter is on and enters a low battery condition, the LED slowly pulses red until it automatically shuts down, or until a power source is applied. When the Mini Mobile Adapter is attached to a power source, the LED becomes solid green and charging automatically begins.

  • Page 13: Multi-Function Push-Button

    USB end of the charging cable to a female USB jack, such as found on a plugged-in wall power adapter, car charger adapter, or computer. You can charge both SurfLink Mini Mobile Adapter and SurfLink Remote Microphone 2 at the same time while they are attached.

  • Page 14: Bluetooth Pairing

    If you are unfamiliar with the Bluetooth pairing process, consult your Bluetooth device’s operations manual. To put SurfLink Mini Mobile Adapter into an active Bluetooth pairing state, ensure it is powered on and not Bluetooth-connected to other devices (the green LED will be slowly pulsing).
  • Page 15 Adapter, press the push-button for 2 seconds and release it, which powers off the Mini Mobile Adapter. You only need to pair SurfLink Mini Mobile Adapter with your Bluetooth device one time, as they should automatically Bluetooth connect when both are powered on and they are within wireless operating range.

  • Page 16: Interacting With Phone Calls

    SurfLink Mini Mobile Adapter. Connecting – Establishes the ability to actively stream audio from a previously paired Bluetooth device to your hearing instruments via SurfLink Mini Mobile Adapter. Interacting with Phone Calls The SurfLink Mini Mobile Adapter allows you to accept, reject, hang up, and transfer phone calls to/from a Bluetooth-connected phone.
  • Page 17 2 seconds to move the call back to Mini Mobile Adapter. During an active phone call, SurfLink Mini Mobile Adapter picks up your voice so that the caller can hear it during the conversation. In noisy environments, position Mini Mobile...

  • Page 18: Listening To Music

    Adapter. It is not necessary to press the push- button on Mini Mobile Adapter. Resetting To reset SurfLink Mini Mobile Adapter back to factory settings, ensure it is powered on and not Bluetooth-connected to other devices (the green LED will be slowly pulsing). Double-click the push-button so that the LED starts rapidly blinking blue.

  • Page 19: Led

    The LED indicator provides helpful information about SurfLink Mini Mobile Adapter: SURFLINK MINI MOBILE ADAPTER STATE BEHAVIOR • Mini Mobile Adapter is off and is not attached to a power source. • If Mini Mobile Adapter is off and is attached to a power source, then battery charging is complete.

  • Page 20: Typical Use Cases

    Typical operating scenarios include: SCENARIO Stream SurfLink Remote Microphone 2 audio from a distant talker. Stream an active phone call. Stream music or other audio. Desired hearing instrument microphones to be active, but allow for...
  • Page 21 SurfLink Mini Mobile Adapter (which is powered off). SurfLink Remote Microphone 2 is attached to SurfLink Mini Mobile Adapter and both are powered on. • Press the push-button on Mini Mobile Adapter to answer the phone call.

  • Page 22: Troubleshooting

    Streamed audio is too Bluetooth device is streaming at loud or too soft in hearing non-optimal volume. instruments. SurfLink Mini Mobile Adapter may be unattached from SurfLink Remote LED is slowly pulsing blue, Microphone 2. but no streamed audio is heard in the hearing instruments.
  • Page 23 POSSIBLE REMEDY Adjust volume control on the Bluetooth device. Ensure Mini Mobile Adapter is properly attached to SurfLink Remote Microphone 2. Turn on SurfLink Remote Microphone 2. Move Mini Mobile Adapter closer to your mouth. Move Bluetooth device closer to SurfLink Mini Mobile Adapter.

  • Page 24: Regulatory Notices

    Instructions for Disposal of Old Electronics Starkey Hearing Technologies encourages, and your local community laws may require, that your SurfLink Mini Mobile Adapter be disposed of via your local electronics recycling/disposal process. The below instructions are provided for the benefit of disposal/recycling personnel. Please include this manual with your device when disposing of your SurfLink Mini Mobile Adapter.
  • Page 25 • Pry the battery away from the microUSB using your fingers. Intended Use SurfLink Mini Mobile Adapter is an accessory to a wireless air conduction hearing instrument. It is intended to wirelessly transfer audio signals between a Bluetooth-enabled device and...
  • Page 26 SurfLink Mini Mobile Adapter is designed to comply with the most stringent Standards of International Electromagnetic Compatibility. However, it is still possible that you may experience interference caused by power line disturbances, airport metal detectors, electromagnetic fields from other medical devices, radio signals and electrostatic discharges.
  • Page 27 Use on Aircrafts SurfLink Mini Mobile Adapter should not be used on aircrafts unless specifically permitted by the flight personnel. International Use SurfLink Mini Mobile Adapter is approved to operate at radio frequencies that are specific to your country or region and might not be approved for use outside your country or region.
  • Page 28 WARNING: Use of accessories, components or replacement parts other than those provided by the manufacturer of your SurfLink Mini Mobile Adapter could result in increased electromagnetic emissions and decreased electromagnetic immunity and could result in degradation of...
  • Page 29 WARNING: If Portable Radio Frequency communications equipment is used closer than 30 cm (12 inches) from your SurfLink Mini Mobile Adapter, degradation of the performance of your hearing aid could result. If this occurs, move away from the communications equipment.
  • Page 30 Wireless Technical Description The SurfLink Mini Mobile Adapter operates in the 2.4-2.4835 GHz band with a maximum effective radiated power of 5.7 dBm with transmission modulation type of 1M12FXD. The receiver section of the radio has a bandwidth of 1 MHz.
  • Page 31 FCC/IC Information FCC ID: EOA-CMA IC: 6903A-CMA (Model 500) FCC/IC Notice This device complies with part 15 of the FCC rules and with Industry Canada’s license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause...
  • Page 32 à opérer cet équipement. Hereby, Starkey Hearing Technologies declares that the SurfLink Mini Mobile Adapter is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/ EU. A copy of the Declaration of Conformity can be obtained from the addresses on the next page and from docs.starkeyhearingtechnologies.com...
  • Page 33 Starkey Hearing Technologies 6600 Washington Ave. South Eden Prairie, MN 55344 USA Starkey Hearing Technologies European Headquarters Wm. F. Austin House, Bramhall Technology Park Pepper Road, Hazel Grove, Stockport SK7 5BX United Kingdom The following symbols are used in this...
  • Page 34 © 2017 Starkey Hearing Technologies., Inc. All Rights Reserved. 85430-007 8/17 BKLT2941-01-EE-XX...
