It is strongly recommended to read the manual carefully before
flying. Inapropriate operations may lead to unitended crashes or
injuries (of the pilot or third parties).
TRANSMITTER OVERVIEW
Left Rotation
Trimmer
1-Key Lift/Land:
Single Press and
Single Beep.
Emergency Stop:
Press and hold for
3 Seconds.
Throttle: Up/Down
PAIRING PROCEDURE:
Turn on the helicopter, then the transmitter; the power indicator light will flash rapidly.
Push the Throttle (Left Stick) fully up, then fully down; when the indicator lights stop
flashing, the remote transmitter is paired.
ON/OFF Button
-1-
Right Rotation
Trimmer
High/Low Speed:
Press button to change
speed modes. A double
beep response indicates
high speed, a single
beep indicates low
speed.
Directional Control:
Forward/Backward
Left/Right Rotation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gyros SYMA S107H Wind Hawk
Summary of Contents for Gyros SYMA S107H Wind Hawk
- Page 1 It is strongly recommended to read the manual carefully before flying. Inapropriate operations may lead to unitended crashes or injuries (of the pilot or third parties). TRANSMITTER OVERVIEW ON/OFF Button Left Rotation Right Rotation Trimmer Trimmer 1-Key Lift/Land: High/Low Speed: Single Press and Press button to change Single Beep.
-
Page 2: Transmitter Battery Installation
TRANSMITTER BATTERY INSTALLATION INSTALLING TRANSMITTER BATTERIES Battery Cover 4 x AA Batteries Open the battery cover on the back side of the transmitter and install 4 alkaline batteries (AA, not included) with the + and – ends facing as shown. Close the battery cover after installing. -
Page 3: Altitude Hold
FLYING INSTRUCTIONS PAIRING PROCEDURE: • Turn on the helicopter (ON/OFF Switch is on the right side of the helicopter) • Turn on the transmitter; the power indicator light will flash rapidly • Push the Throttle (Left Stick) fully up, then fully down (see diagram) •... -
Page 4: Trim Adjustments
TRIM ADJUSTMENTS If the helicopter begins to rotate quickly while hovering (left stick is not moved left/right), please adjust the trim button on the transmitter until the helicopter starts hovering as normal. Right Rotation Trimmer Button Counter-Clockwise Rotation If the helicopter rotates counter-clockwise while hovering (without using the Directional Control Stick), use the Right Rotation Trimmer button to correct and regain stability. - Page 5 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 6 Operating Instructions： *The product is made out of light and thin materials. Inapropriate operations may lead to unitended crashes. It may cause the helicopter to be easily damaged. *After flying the helicopter avoid touching the motors. The motors may be very hot and can cause burns if touched.
- Page 7 Manufacturer Guangdong Syma Model Aircraft Industrial Co., Ltd. The Crossing of No.2 West Xingye Road and North Xingye Road, Laimei. Industrial Park Chenghai District Shantou City Guangdong China. The company has the right of final interpretation of this instruction manual statement.
