- Page 1 User Manual Version 1.2.1 August 2019 Redpine Signals, Inc. 2107 N. First Street, #680 San Jose, CA 95131. Tel: (408) 748-3385 Fax: (408) 705-2019 info@redpinesignals.com Email: www.redpinesignals.com Website: Redpine Signals, Inc. Proprietary and Confidential...
- Page 2 User Manual Version 1.2.1 About this Document This document describes the usage of the RS9113DB n-Link® Driver for testing transmit & receive Regulatory Performance for Wi-Fi protocols. Disclaimer: The information in this document pertains to information related to Redpine Signals, Inc.
-
Page 3: Table Of Contents
Table 3: Regulatory Domain Input in Transmit Tests........... 10 Table 4: Channel Width Values....................12 Table 8: List of Antennas Used for RS9113DB FCC/IC Certification....16 Table 9: Command to Program Antenna Type for Wi-Fi..........17 Table 12: Command to Program Transmit Power for Wi-Fi........18 Table 15: Low, Mid and High Channel Frequencies for Wi-Fi........ -
Page 4: Introduction
User Manual Version 1.2.1 1 Introduction The software provided for the RS9113DB n-Link® modules is named OneBox-Mobile. The software currently supports performance testing for Wi-Fi. The subsequent sections explain the use of OneBox-Mobile software on an x86 platform. Installation and operation of the driver on specific representative processor platforms have been explained in the Appendix sections. - Page 5 6. Please type “dmesg” on the terminal and press enter key and check for the below print 7. Please go to directory /work/Regulatory_test/host/releases 8. Please read section 2 for performing WLAN Tests Redpine Signals, Inc. Proprietary and Confidential Page 5...
-
Page 6: Wlan Performance Test Application Usage
The “transmit” utility, present in the “release” folder allows the configuration of the following parameters and starts the transmission of packets. 1) Transmit Power 2) Transmit Data Rate 3) Packet Length 4) Transmit Mode 5) Channel Number Redpine Signals, Inc. Proprietary and Confidential Page 6... -
Page 7: Transmit Command
2432 This is not supported in the current release. On-air testing in DFS channels should be avoided till the module is certified for DFS. Cabled tests can be run in these channels. Redpine Signals, Inc. Proprietary and Confidential Page 7... - Page 8 Center Frequency (MHz) (GHz) (MHz) Number 2437 2442 2447 2452 2457 2462 2467 2472 2484 5180 5200 5220 5240 5260 5280 5300 5320 5500 5520 5540 5560 5580 5600 5620 5640 5660 5680 Redpine Signals, Inc. Proprietary and Confidential Page 8...
-
Page 9: Table 1: Channel Numbers And Corresponding Center Frequencies
1 to enable aggregation. The packet length is divided into chunks of size 1792 bytes and aggregated. This parameter applies only to the Burst mode transmission and is ignored in the case of Continuous mode of transmission. Redpine Signals, Inc. Proprietary and Confidential Page 9... -
Page 10: Examples
Data rate – 54Mbps Packet Length – 1000 bytes Transmit mode – 1 (continuous mode). Channel number – 11 External PA – disabled Rate flags – 0 Aggregation – disabled (ignored in continuous mode) Redpine Signals, Inc. Proprietary and Confidential Page 10... -
Page 11: Receive Tests
<start/stop>: Parameter to start or stop logging the statistics. Enter 0 to start logging and 1 to stop logging. On-air testing in DFS channels should be avoided till the module is certified for DFS. Cabled tests can be run in these channels. Redpine Signals, Inc. Proprietary and Confidential Page 11... -
Page 12: Examples
Ensure that the DRIVER_MODE is set as below: DRIVER_MODE = 2 Run the following command to install the Driver in Performance Test mode: # sh wlan_insert.sh Next, follow the instructions below to run the Transmit and Receive tests. Redpine Signals, Inc. Proprietary and Confidential Page 12... -
Page 13: Command Usage
The above command starts continuous wave transmission with the following configuration. Channel number – 6 Type – Single tone Transmit Power – 2dBm # ./onebox_util rpine0 cw_mode 6 3 1 The above command stops continuous wave transmission. Redpine Signals, Inc. Proprietary and Confidential Page 13... -
Page 14: Fcc And Ic Declaration
Number is not visible while installed inside another device, then the device should display the label on it referring the enclosed module. In that case, the final end product must be labeled in a visible area with the following: Redpine Signals, Inc. Proprietary and Confidential Page 14... - Page 15 User Manual Version 1.2.1 “Contains Transmitter Module FCC ID: XF6-RS9113DB” “Contains FCC ID: XF6-RS9113DB” The OEM should not provide information to the end user regarding installation or removal of this RF module or change RF related parameters in the user manual of the end product.
-
Page 16: Confirmation On Unlawful Usage Of Tx Power With Respect To Certified Antennas
4 Confirmation on Unlawful Usage of TX power with respect to Certified Antennas This is to confirm that Redpine Signals, Inc., will ensure that the following information is included in the RS9113DB (FCC ID: XF6-RS9113DB, IC ID: 8407A-RS9113DB) Module’s Programming Manual for customers who use this module with different antennas to help them comply with the FCC/IC regulatory requirements for products which use the module’s modular... -
Page 17: Commands To Program Transmit Power
Input Parameters VAP Name (string like wifi0, wifi1, etc.) Integer value in dBm Output Parameter None Reset Required Usage iwconfig<vap_name>txpower<val_in_dBm > Example The command below sets the Wi-Fi transmit power to 15dBm: Redpine Signals, Inc. Proprietary and Confidential Page 17... -
Page 18: Maximum Transmit Power And Attenuation Values
5260 5500 5720 Bandwidth(5GHz U-NII- 2) 802.11a (5GHz 5745 5785 5825 U-NII- 3) 802.11n 20MHz 5745 5785 5825 Bandwidth (U- NII- 3) Table 8: Low, Mid and High Channel Frequencies for Wi-Fi Redpine Signals, Inc. Proprietary and Confidential Page 18... -
Page 19: Maximum Transmit Power And Attenuation Values For Pifa Antenna
802.11 MCS0 n_20MHz MCS4 MCS7 802.11a (5GHz U- NII-1) 802.11n MCS0 20MHz MCS4 (5GHz U- NII-1) MCS7 802.11a (5GHz U- NII-2) 802.11n MCS0 20MHz MCS4 (5GHz U- NII-2) MCS7 802.11a (5GHz U- Redpine Signals, Inc. Proprietary and Confidential Page 19... -
Page 20: Grant Note
20 cm from all persons, and must not be co-located or operating in conjunction with other antennas or transmitters within a host device, except in accordance with FCC multi transmitter product procedures. ***** Redpine Signals, Inc. Proprietary and Confidential Page 20...
