Installation Instructions
ELEKTROMAT
SE 8.60 FU-25,40
Model: 10004398 30012
-en-
Status: 09.07.2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the ELEKTROMAT SE 8.60 FU-25,40 and is the answer not in the manual?

Questions and answers

Summary of Contents for GFA ELEKTROMAT SE 8.60 FU-25,40

  • Page 1 Installation Instructions ELEKTROMAT SE 8.60 FU-25,40 Model: 10004398 30012 -en- Status: 09.07.2020...
  • Page 2 GfA ELEKTROMATEN GmbH & Co. KG Wiesenstraße 81 D-40549 Düsseldorf www.gfa-elektromaten.de info@gfa-elektromaten.de...
  • Page 3: Table Of Contents

    Table of contents General safety information ....................4     Technical Data ........................ 5     Mechanical installation ....................6     Electrical installation ....................... 8     Limit switch adjustment ....................9     Emergency manual operation ..................10  ...
  • Page 4: General Safety Information

    1 General safety information Specified normal use The drive unit is intended for sectional doors with full counter-balancing. The safe operation is only guaranteed with normal specified use. The drive unit is to be protected from rain, moisture and aggressive ambient conditions. No liability for damage caused by other applications or non-observance of the information in the manual.
  • Page 5: Technical Data

    2 Technical Data Type SG 40 Output torque 80 (-) Output speed OPEN 12-60 Output speed CLOSE 12-24 Output speed CLOSE > 2,5m 12-30 Output shaft / hollow shaft 25,40 Maximum holding torque Maximum door weight 3200 Supply voltage 1N~ 230 Operating current 7,35 Operating frequency...
  • Page 6: Mechanical Installation

    3 Mechanical installation Prerequisites The permissible loads on walls, fastenings, mountings and transmission elements must not be exceeded, even for maximum holding torques or locking torques (▶ refer to technical data). Connection elements: ▶ Self-locking connection ▶ Utilize the hole diameter ▶...
  • Page 7 Mounting Fourt threads are provided for mounting. ▶ Use at least 2 of these. Additional mounting options...
  • Page 8: Electrical Installation

    4 Electrical installation Warning - Danger to life from electric current!  Switch the mains OFF and check that the cables are de-energised  Observe the applicable regulations and standards  Make the electrical connection according to standard  Use suitable tools Performing electrical installation ▶...
  • Page 9: Limit Switch Adjustment

    5 Limit switch adjustment The adjustment of the final limit positions OPEN and CLOSE is described in the instructions for the door control panel.
  • Page 10: Emergency Manual Operation

    6 Emergency manual operation Emergency manual operation is designed for opening or closing the door without power supply. Its activation interrupts the control voltage. Electrical operation is no longer possible. Warning – Injuries due to incorrect operation!  Switch off voltage. Warning - Danger of the door dropping! If you need to apply more than the permissible force of 390N (according to DIN EN 12604/DIN EN 12453) to move the door by emergency manual operation, this...
  • Page 11 Ⓐ: Attach tool (①). Switch on by turning to the right until stop (②). Ⓑ: Switch on by pulling the red handle. Ⓐ+Ⓑ: Open (③) or close (④) the door by pulling the chain by hand. Ⓐ: Attach tool (⑤). Switch off by turning to the left until stop (⑥).
  • Page 12: Completing Commissioning / Inspection

    7 Completing commissioning / inspection Check the following components and then install all covers. Gearbox Check the drive unit for loss of oil (a few drops can be neglected). Protect the output-shaft permanently against corrosion. Mounting Check that all connection elements (consoles, torque mounts, screws, locking rings, etc.) are secure and in proper condition.
  • Page 13: Declaration Of Incorporation / Declaration Of Conformity

    EMC Directive 2014/30/EU within the meaning of RoHS Directive 2011/65/EU The following requirements from Appendix I of GfA ELEKTROMATEN GmbH & Co. KG the Machinery Directive 2006/42/EC are met: declare under our sole responsibility that the 1.1.2, 1.1.3, 1.1.5, 1.2.2, 1.2.3, 1.2.6, 1.3.2,...
