Pro9500
H I G H BRI GHT NESS
PER FOR MANCE PR OJECT O R
WI TH 3L C D TE CHNO LO GY
Optional Accessories
> Replacement Lamp .................................. RLC-063
> Universal Ceiling Mount Kit ..................WMK-005
> Wireless Presentation Gateway .............WPG-360
®
> Extended Express Exchange ........PRJ-EE-10-03
Projection Distance 4:3 Screen Size
M Feet M Inches
0.9 2.95 0.45–0.75 17.7–29.5
1.5 4.9 0.75–1.25 29.5–49
2 6.5 1.0–1.7 39–67
4 13.1 2–3.3 78.7–130
5 16.4 2.5–4.2 98.4–165
8 26.2 4–6.7 157.5–263.8
ViewSonic Corporation's QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Sales: (888) 881-8781 . SalesInfo@ViewSonic.com . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange details. Specifications subject to change without
notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks
stated herein are the property of their respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved [15424-00B-01/10] PRO9500
For more product information, visit us on the web at ViewSonic.com
DISPLAY Type
Resolution
Color Depth
Lens
Lens Shift
Keystone
Projection Size
Throw Distance
Throw Ratio
Lamp
Lamp Life
Brightness
Contrast Ratio
Aspect Ratio
INPUT SIGNAL Computer & Video NTSC M (3.58MHz), 4.43MHz, PAL (B, D, G, H, I, M, N),
Frequency
COMPATIBILITY PC
Mac
®
CONNECTOR RGB Input
RGB Output
RGB-BNC
Digital Input
Component
Composite Input
S-Video Input
USB
Audio Input
Audio Output
Mic In
Control
Network
AUDIO Speaker
POWER Voltage
Consumption
CONTROLS
Basic
OSD
PICTURE Menu: Brightness, Contrast, Gamma, Color Temp, Color, Tint, Sharpness,
Active IRIS, My Memory
IMAGE Menu: Aspect, Over Scan, V position, H position, H Phase, H size,
Auto Adjust Execute
INPUT Menu: Progressive, Video NR, Color Space, Component, Video Format,
HDMI Format, HDMI Range, Computer IN, Frame Lock, Resolution
SETUP Menu: Auto Keystone, Keystone H/V, Perfect Fit, Auto ECO Mode, ECO Mode,
Mirror, Standby mode, Monitor out
AUDIO Menu: Volume, Speaker, Audio Source, HDMI Audio, MIC Level, MIC Volume
SCREEN Menu: Language, Menu Position, Blank, Start up, Myscreen, Myscreen Lock,
Message, Source Name, Template, CC
OPTION Menu: Auto Search, Auto Keystone, Direct Power ON, Auto Power OFF,
USB Type B, Lamp Time, Filter Time, My Button, My Source, Service (Fan Speed, Auto
Adjust, Ghost, Filter Message, Key Lock, Remote FREQ, Communication,
Information, Factory Reset)
NETWORK Menu: Setup, Projector Name, My Image, AMX D.D,
Presentation, Information, Service
SECURITY Menu: Security password change, Myscreen password, PIN Lock, Transition
Detector, My Text Password, My Text Display, My Text Writing, Security Indicator, Stack Lock
OPERATING Temperature
CONDITIONS Humidity
Altitude
NOISE LEVEL Normal / Eco-mode 36dB / 29dB
DIMENSIONS Physical
(W x H x D) Packaging
WEIGHT Net
Gross
REGULATIONS
PACKAGE CONTENTS
WARRANTY
0.63" (x3) 3LCD Poly-Si TFT with Micro Lens
XGA 1024x768 (Native) / UXGA 1600×1200 (compressed)
24 bits, 16.7 million colors (8+8+8)
1.7× Manual optical zoom / Manual focus
Vertical 10:0-4:1 at Horizon 1:1 / Horizon 11:9-9:11 at Vertical 10:0-4:1
Vertical digital keystone correction: +/– 30 degrees
30"–300" / 0.8m–7.6m diagonal
2.95ft-29.9ft / 0.9m-9.1m
1.5-2.5:1
245 watt
3000 / 5000* hours (Normal / Eco-mode)
5000 Lumens
1800:1 (typ) 3500:1 (max)
4:3 (native)
SECAM, SD (480i/576i), ED (480p/576p), HD (720p/1080i/1080p)
Fh: 31–106KHz, Fv: 56–120Hz
Analog: VGA to UXGA
Analog: Up to WSXGA+
15-pin mini D-sub
15-pin mini D-sub
BNC-5 (x 1 set)
HDMI 1.3
RCA (x3)
RCA jack
4-pin mini-Din
Type A: for PC-less slide show presentation - support JPEG,
BMP, TIFF, PNG, GIF from USB flash drive.
Type B: for direct presentation from PC (not Mac compatible),
Mouse Control
3.5mm mini jack (x2), RCA (L/R) x1 Pair
RCA (L/R) x1 Pair
3.5mm mini jack (x1)
RS-232 (DB-9), 3.5mm mini jack (wired remote)
RJ45
8W (x2)
100~240 VAC (Auto Switching), 50/60Hz (universal)
420W (typ) / <0.5W (stand-by mode)
STANDBY/ON, INPUT, MENU
41ºF–95ºF (5ºC–35ºC)
10%–85% (non-condensing)
0 to 6,000 ft (1,800m), operational up to 10,000 ft (3048m)
at reduced reliability and performance
15.8 × 4 × 12.5 (in) / 401 × 103 × 318 (mm)
22 × 7.7 × 16.5 (in) / 560 × 197 × 420 (mm)
10.4 lb. (4.7 kg)
17.8 lb. (8.1 kg)
UL60950-1/C-UL, FCC part 15 Class B, CE approval:
EN61000-3-2, EN61000-3-3, EN55022, EN55024 (EMC
directive), EN60950-1 (low voltage directive); WEEE, RoHS
C-Tick (Australia/New Zealand), NOM, ErP
ViewSonic Projector, power cable, RGB cable,
remote control with batteries, Lens Cap, Quick Start Guide,
ViewSonic Wizard CD (with User Guide)
3-year limited warranty on parts, 1-year limited warranty
on lamp, 1st year Express Exchange ® service.
