Vertical CD Player
Please read and retain these instructions for future reference
SPECIFICATIONS
Tuner:
Frequency Range: FM 87.5 - 108 MHz
CD Player:
Type: Single disc multi-play compact disc player
Signal readout: Non-contact, 3-beam semiconductor laser pickup
D/A converter: Multi bit D/A converter
Frequency response: 20 - 20,000 Hz
USB host
Interface: Complies with USB 1.1 (Full Speed)/2.0 Mass Storage Class. Support Bulk
only and CBI protocol.
Support file: MPEG 1 Layer 3 WMA (Non DRM)
Bitrate support: MP3 (32 ~ 320 kbps) WMA (64 ~ 160 kbps)
General:
Speakers: 76cm (3.0 in) cone x 2
Speaker impedance: 8 Ω
Output power: 1.5 W per channel, min. RMS driven into 4 Ω at 1 kHz with no more
than 10% total harmonic distortions
Input terminal: AUDIO IN (φ 3.5) x 1
Power Sources:
AC/DC adapter (Included)
Input AC 100 – 240V ~ 50/60Hz
Output DC 5V 1.2A
Power stand-by: <1W
Frequency band: 2.400GHz - 2.480GHz
Compatible Bluetooth Profile: A2DP (Advanced Audio Distribution Profile), AVRCP
(Audio/Video Remote Control Profile)Bluetooth 2.1 +EDR
G295
Instructions for Use
v002: 15/05/20
Advertisement
Table of Contents
Related Manuals for Coopers of Stortford G295
Summary of Contents for Coopers of Stortford G295
-
Page 1: Specifications
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 SPECIFICATIONS Tuner: Frequency Range: FM 87.5 - 108 MHz CD Player: Type: Single disc multi-play compact disc player Signal readout: Non-contact, 3-beam semiconductor laser pickup... -
Page 2: Table Of Contents
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 Please read this instruction manual thoroughly before starting and ensure you are familiar with the operation of your new Vertical CD Player. -
Page 3: General
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 GENERAL Please ensure that the equipment is positioned in a well ventilated area and ensure that there is at least 10 cm (4”) of free space along the sides and top of the equipment.10 cm (4”) 10 cm (4”) ... -
Page 4: Location Of Controls
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 LOCATION OF CONTROLS 1. Left speaker 11. Right speaker 21. Audio in Jack 2. CD Door 12. Play/Pause, FM Scan Button 22. Clock set button 3. - Page 5 Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 Remote control 1. Standby button 2. Play/Pause/Scan Button 3. Stop / MEM Button 4. Volume Button 5. Repeat/Random/Preset- Button 6. Numeric Buttons 7.
-
Page 6: System Connections
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 SYSTEM CONNECTIONS Make sure to unplug the AC/DC-power lead before making any connections. POWER SOURCES This Music System operates on 100~240V~ 50/60Hz. Do not attempt to operate the radio on any other power source. -
Page 7: Using The Remote Control Correctly
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 B. INSTALLING BATTERIES INTO THE REMOTE CONTROL The remote control operates on one CR2025 battery (included). To activate the remote control, remove the insulation tab inserted in the battery compartment. -
Page 8: Cd Disc Operation
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 Hints for Best Reception The receiver has a build-in FM wire antenna hanging from the back of the cabinet. This wire should be totally unwrapped and fully extended for the best reception. -
Page 9: Bluetooth Operation
2. Press MODE button on the remote control or MODE button to turn on the BLUETOOTH mode. 3. If the unit is not paired with any Bluetooth device, the display will flash “BT ”. 4. Activate your Bluetooth device and select the search mode. 5. “G295” will appear on your Bluetooth device list. -
Page 10: Usb Operation
Please read and retain these instructions for future reference v002: 15/05/20 6. Select “G295”and enter “0000” for the password if necessary. 7. To disconnect the Bluetooth function, press the MODE button to switch to another mode or disconnect the function from your Bluetooth device. -
Page 11: Aux In Operation
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 AUX IN OPERATION 1. Use a connection lead to connect the portable audio player etc. to the AUDIO IN socket. When using video equipment, connect the audio output to this unit and the video output to a television. -
Page 12: Care Of Compact Discs
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 your sleep time in power on mode: 1. To activate the sleep function, press the SLEEP button, the display will show “Sleep Timer- OFF,120,90,60,45,30,20,10 ”... -
Page 13: Warnings And Safety Instructions
CHILDREN OF LESS THAN 3 YEARS SHOULD BE KEPT AWAY UNLESS CONTINUOUSLY SUPERVISED. THE USE OF ANY ACCESSORY ATTACHMENTS NOT RECOMMENDED BY COOPERS OF STORTFORD MAY CAUSE INJURIES AND INVALIDATE ANY WARRANTY YOU MAY HAVE. DO NOT LET THE POWER CABLE HANG OVER THE EDGE OF A TABLE OR COUNTER, OR TOUCH HOT... -
Page 14: Plug Wiring (Uk & Ireland)
Vertical CD Player G295 Instructions for Use Please read and retain these instructions for future reference v002: 15/05/20 DO NOT PLACE ON OR NEAR HEAT SOURCES. DO NOT USE THIS APPLIANCE FOR ANY OTHER USE THAN THE INTENDED USE IT IS DESIGNED FOR. -
Page 15: Disposal
Please read and retain these instructions for future reference v002: 15/05/20 DISPOSAL • Coopers of Stortford use recyclable or recycled packaging where possible. • Please dispose of all packaging, paper, cartons, packaging in accordance with your local recycling regulations. •...
