- Page 1 Tri-Wheel Wheeled Walker U S E R G U I D E Handle with lever brake Brake cable Handle height adjustment knob Removable basket and tray Large vinyl bag 8 inch (203 mm) wheels...
-
Page 2: Table Of Contents
Control Unit and its use. Important information Novis Healthcare has a policy of continuous product improvement and reserves the Caution right to amend specifications presented in Electrical hazard this guide. -
Page 3: Overview
Overview Box Contents and Inspection Intended Use This wheeled walker is designed for general Carefully remove all components from the ¥ indoor and outdoor use as a walking aid. box and check items against the list below. Any damaged or missing components should The maximum weight capacity is 100 kilograms, ¥... -
Page 4: Set Up
Set Up Unfold the wheeled walker Remove the protective covering from all three wheels, and ensure all other protective coverings have been removed from brakes, frames or handles. Place the wheeled walker on a stable surface. Unfold the frame by spreading both left and right sides outwards. - Page 5 Set Up Align handle and frame holes at the ideal height, and then insert the bolt (from inside the frame) and push until fully inserted. Ensure the bolt head fits securely within the hexagonal frame hole. Place washer on bolt (curved face against frame), screw on the Star Knob and tighten firmly.
-
Page 6: Operation
Operation Using as a walking aid When using the wheeled walker as a walking aid, it is recommended both hands be placed firmly on the handles, with fingers curled around the brake levers so that the walker can be stopped immediately in case of an emergency. The ideal walking technique is to push the walker forward to a comfortable arm’s length, then step in towards the walker, and repeat. -
Page 7: Transport And Storage
Transportation & Storage Removing the basket To remove the basket, lift off the tray and unhook the basket from the hanging hooks. Removing the bag The vinyl bag can be removed for cleaning or as needed. To remove, detach the bag from the frame by undoing the snap fasteners to release the two straps either side, and pull free. -
Page 8: Safety And Maintenance
Safety & Maintenance General Safety Precautions Regular Maintenance Do not use the wheeled walker as a seat Professional inspection of the or attempt to sit on the tray or basket. wheeled walker is recommended at least once a year. A risk assessment should always be carried ¥... -
Page 9: Cleaning
Cleaning Do not use high pressure cleaners, steam cleaners or harsh, caustic chemicals for cleaning. Frame Bag and tray Wipe the wheeled walker frame with a damp cloth. Regularly clean the soft materials and tray using a mild detergent solution up For more stubborn dirt, use a mild detergent solution to 40 °C, or wash with alcohol-based up to 40 °C. -
Page 10: Warranty
To obtain compensation, you will need to provided documentary evidence Novis will undertake at its option, to repair or replace, of the loss or damage suffered and documentary free of charge, each product or part thereof on the... - Page 11 Specifications Tri-Wheel Wheeled Walker NAME COLOUR 7.9 kg PRODUCT WEIGHT 870 > 970 mm OVERALL HEIGHT OUTER DIMENSIONS 570 mm OVERALL WIDTH 203 mm (solid) WHEELS Steel MATERIALS FRAME 100 kg WALKER SAFE WORKING LOAD 5 kg TRAY AND BASKET ARTG 176830 CONFORMS TO Tri-Wheel User Guide...
- Page 12 Pressure care and patient handling specialists novis.com.au 1300 738 885...
