Indoor Camera Self-Install Guide
Camera Features:
•
HD 1080p video
•
IR night vision
•
Wide dynamic range (WDR)
•
Two-Way Audio
Everything you need to get started:
•
Indoor Camera (ADC-V522IR - included)
•
AC Power adapter (included)
•
Internet connection
•
A computer, tablet or smartphone with WiFi
An Ethernet cable for installation (included)
•
•
Login and password for the alarm.com account to which
you will add the camera
1
Advertisement
Table of Contents
Summary of Contents for EastLink ADC-V522IR
- Page 1 IR night vision • Wide dynamic range (WDR) • Two-Way Audio Everything you need to get started: • Indoor Camera (ADC-V522IR - included) • AC Power adapter (included) • Internet connection • A computer, tablet or smartphone with WiFi An Ethernet cable for installation (included) •...
- Page 2 Indoor Camera Self-Install Guide How to install: Connect Ethernet Cable from Camera to Modem Connect Power - Wait for LED to be Solid Green - 60 seconds Log in to alarm.com account Select the Video tab • If 1st camera on account click Add Camera to account •...
- Page 3 Indoor Camera Self-Install Guide How to Mount the Camera: The Indoor Camera can be mounted indoors by using its mounting bracket To access the Indoor Camera mounting bracket: Find the locked and unlocked icons on the base of the camera. The bottom half of the base is the mounting bracket Twist counter-clockwise until the mark lines up with the unlocked icon Lift the camera away from the mounting bracket...
- Page 4 Indoor Camera Self-Install Guide LED colour Status Description Solid Green Internet connection Local network and internet connection Flashing Green Local network Local network connection only, no internet connection Solid Red No network No local network or internet connection connection Flashing Red System booting Camera is booting Factory reset...
