  • Page 1 HYDRO SS 700 ► BENCH TOP OPERATOR’S MANUAL NOTICE Read & Understand Retain for Future Reference...
  • Page 2 Purchase Date Model ID Number Vendor Information Notes...
  • Page 3: General Safety

    GENERAL SAFETY The Hydro SS 700 uses a high-speed component to atomize water, the following safety precautions must be observed at all times: Read operator’s manual carefully and thoroughly. Understand all safety warnings and instructions before attempting operation of the unit. DO NOT OPERATE THE UNIT DRY (FULL WATER SUPPLY IS REQUIRED IN THE SUMP).
  • Page 4 NOTIFICATION WARNING THE HYDRO SS 700 CAN BE AUTOMATED WHEN USED IN CONJUNCTION WITH A CONTROL. THE FAN MAY NOT APPEAR POWERED BUT COULD SUDDENLY BEGIN HIGH-SPEED ROTATION AS A FUNCTION OF THE PRESET CONTROL. WARNING HIGH-SPEED ROTATION, NEVER OPERATE UNIT WITHOUT THE HOUSING AND SAFETY GUARDS INSTALLED.
  • Page 5 POSITIONING Small structures In applications requiring only one unit, install the unit anywhere along one end wall, propelling the fog upward and Controller location area horizontally down the length of the structure. If there is forced ventilation, choose the intake end of the structure.
  • Page 6: Placement Guidelines

    PLACEMENT GUIDELINES Where to Place Locate a stable and level area to set the unit. Place at the edge of a bench or shelf and propel the fog towards an open area or isle way. As a general rule, the higher the better. Allow adequate room in front of and below the fan for the unobstructed propulsion of the fog.
  • Page 7: Installation

    INSTALLATION Connect Water Supply: Hydro SS units come equipped with a standard garden hose connector and 1/4” water line tubing. Simply connect to an available hose bib. Turn water on and allow a few minutes for the unit to fill. Remove sump lid to observe if unit fills properly.
  • Page 8 Lubricate Motor: Remove two blue plugs at the top of the motor. Apply 4-5 drops of light grade petroleum based oil at each bearing location 1 to 2 times a year or as needed. Replace blue plugs. See Fig. 3 Cleaning Blade Assembly: After removing the blade assembly, remove the stainless plate and O-ring.
  • Page 9: Troubleshooting

    TROUBLESHOOTING Issue Corrective Action INITIAL START-UP 1. Fan Blade Does Not Spin 1. Check power supply. Toggle switch ON is up position. If using a controller, try bypassing it and plug unit directly into a power outlet. Check for a faulty power cord.
  • Page 10: Service And Repair

    SERVICE & REPAIR Atomizing Ring/Front 10-24 Guard Assembly Flange Nuts Using a 3/8” nut driver or wrench, remove four 10-24 Motor flange nuts located at the back of the housing. To remove and reinstall the Atomizing Ring/Front Guard Assy. assembly, it needs to be rotated horizontally in order to clear the lip of the front Fig.
  • Page 11: Part Identification

    PART IDENTIFICATION DESCRIPTION PART NO. Atomizing Ring 400-001 Front Guard 400-002 Motor 1/20hp 115V 400-110 Rear Guard 400-127 Blade Assembly 400-128 Housing 400-100 SST Support a-620 SST Water Feed Tube 400-130 Pivot Location 10 Sump 400-131 11 Float Valve Assembly 400-012 12 Flow Control Valve 400-016 14 15...
  • Page 12 Jaybird Manufacturing, Inc. reserves the right to verify the legiti- macy of claimed defects. The provisions of this warranty do not apply to...
