enware Custodian WMSSB-000 Installation And Maintenance Instructions Manual

Smart board without/with solenoids
Hide thumbs

Advertisement

Quick Links

Download this manual
The Custodian
Smart Board
Installation and Maintenance Instructions
WMSSB-000 - without solenoids
WMSSB-001 - with solenoids
I00348_Jun 20
Call 1300 369 273
www.enware.com.au
Enware Australia Pty Limited
9 Endeavour Rd Caringbah NSW 2229 Australia
Ph: 02 8536 4000 info
enware.com.au
@
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the Custodian WMSSB-000 and is the answer not in the manual?

Questions and answers

Summary of Contents for enware Custodian WMSSB-000

  • Page 1 The Custodian ® Smart Board Installation and Maintenance Instructions WMSSB-000 - without solenoids WMSSB-001 - with solenoids I00348_Jun 20 Call 1300 369 273 www.enware.com.au Enware Australia Pty Limited 9 Endeavour Rd Caringbah NSW 2229 Australia Ph: 02 8536 4000 info enware.com.au...
  • Page 2 This is achieved by using an Electronic Thermostatic Mixing Valve (eTMV) for temperature control and a solenoid for flow control. The available activation methods depend on the configured mode. Call 1300 369 273 www.enware.com.au...
  • Page 3 12V DC (WMSSB-001 Model) SOLENOID ETMV MIXED TO SHOWER CONTROL HUB SOLENOID MIXED TO BASIN HOT INLET ISOLATION, STRAINER COLD INLET & CHECK VALVE ISOLATION, STRAINER & CHECK VALVE (WMSSB-001 Model) All measurements are in millimetres. www.enware.com.au Call 1300 369 27...
  • Page 4 *AS3500.4 clause 1.9.4.2 - The dynamic pressure differential between hot and cold supplies when mixed at a thermostatic mixing valve shall not exceed 10%. eTMV Flow Sizing Graph FLOW RATE VS PRESSURE LOSS Dynamic pressure (kPa) cold mixed Call 1300 369 273 www.enware.com.au...
  • Page 5 TLI Control Wheel Port Number of Connectors Type of Connector KCC SK9/8 Male Flushing Solenoid Ports Number of Outputs Type of Outputs 10W solenoid Voltage of Outputs Number of Connectors Connector Type KCC SK2/2 Female www.enware.com.au Call 1300 369 27...
  • Page 6 Enware products are to be installed in accordance with the Plumbing Code of Australia (PCA) and AS/NZS3500. Installations not complying with PCA and AS/NZS 3500 may void the product and performance warranty provisions. Reference should also be made to the Australasian Health Facility Guidelines (AHFG), ABCB and Local Government regulations when considering the choice of, and the installation of these products.
  • Page 7 SEE IMAGE 02 CONNECTION TO SHOWER CONNECTION TO BASIN HOT INLET COLD INLET 1/2” BSP MALE 1/2” BSP MALE WMSSB-000 Model ETMV OUTLET CONNECTION HOT INLET COLD INLET 1/2” BSP MALE 1/2” BSP MALE IMAGE 02 www.enware.com.au Call 1300 369 27...
  • Page 8 Jack will be fitted less than 1m above the Custodian Smart Board location. 3. Finally connect the power supply (supplied transformer) to power the Custodian Smart ® Board. Control Hub Overview ETMV B1,B2 B3,B4 TLI1 TLI3 RS485 www.enware.com.au Call 1300 369 27...
  • Page 9 • 2x TLI control wheels (external) • 1x ETMV output (on Smart Board) • 2x shower / basin solenoid outputs (on Smart Board) • 1x flushing solenoid output (external) 12V POWER PACK Smart Flow RS485 ETMV CONTROL HUB Call 1300 369 273 www.enware.com.au...
  • Page 10 CONTROL PANEL Piezo Button Activation PRESS ONCE TO ACTIVATE WC HALF FLUSH WC FULL FLUSH ACTIVATION ACTIVATION BASIN OUTLET SHOWER ACTIVATION ACTIVATION IMAGE 03 Lightly press the piezo button once to activate. SEE IMAGE 03 Call 1300 369 273 www.enware.com.au...
  • Page 11 • Water Pulse: The water will turn off for 1s then back on when it reaches the pre-set time remainder time before the shower turns off automatically. • When Disabled: if the user attempts to use a disabled interface it will flash pink 4 times on all TLI control wheels. www.enware.com.au Call 1300 369 27...
  • Page 12 A calibrated digital thermometer having rapid response time with maximum temperature hold will be required to measure the outlet mixed temperature of the valve. (Enware Code ATMS1200 - Aquablend Test Kit) 1.
  • Page 13 Ensure that all details of the Commissioning Report are completed and signed by the relevant signatories, and a copy is kept with the installer and owner of the premises. The valve is now commissioned and it can be used within the technical limits of operation. www.enware.com.au Call 1300 369 27...
  • Page 14 T=1m 26s: Basin stops, wait 3 seconds T=1m 29s: Basin runs at 15°C for 10 seconds T=1m 39s: Basin stops, wait 3 seconds T=1m 42s: Toilet runs for 3 seconds T=1m 45s: Toilet stops, TLIs return to flashing white Call 1300 369 273 www.enware.com.au...
  • Page 15 The eTMV is constantly monitored for real-time performance by the Enware Smartflow TMV monitoring system. The eTMV will only require minimal preventative maintenance work to ensure it operates at its optimum level of performance.
  • Page 16 15. cleaning Enware products should be cleaned with a soft damp cloth using only mild liquid detergent or soap and water. Do not use cleaning agents containing a corrosive acid, scouring agent or solvent chemicals. Do not use cream cleaners, as they are abrasive.
  • Page 17 60°C temperature) then the TLI with flash orange to show there was an error that needs investigating. 9. The thermal flush process can be stopped at any time by pressing a TLI button, which will send the system back to step 1. www.enware.com.au Call 1300 369 27...
  • Page 18 Hub. SEE IMAGE 11 2. Unplug cables. When unplugging cables, hold the connectors and do not pull on the cables to avoid damage. 3. Replace eTMV Control Hub with a new FIXING SCREW IMAGE 11 one. Call 1300 369 273 www.enware.com.au...
  • Page 19 * Water or power turned off control and clean * eTMV has shut down * Turn on power / water * See Rectification 1 For further assistance, call Enware on 1300 369 273. spare parts Name Part Code Electronic TMV...
  • Page 20  NO  YES  NO  YES  NO If NO, give details and action taken: Valve functioning in accordance with the application requirements:  YES  NO If NO, give details and action taken: Call 1300 369 273 www.enware.com.au...
  • Page 21 Replaced   O-rings and Seals Not Applicable Checked Replaced (max. 5-year intervals)    Thermostatic Element Not Applicable Checked Replaced (max. 5-year intervals)    Valve Replaced   Other Items Replaced: www.enware.com.au Call 1300 369 27...
  • Page 22 Contractor Business Name Contractor Lic / Cert No. (Name) Contractor Name (print) Phone No Name of Authorised Tester (Name) (Licensed Plumber) Signature of Authorised Tester (Signature) Date (Licensed Plumber) (Signature) Owner / Occupier Signature Date Call 1300 369 273 www.enware.com.au...
  • Page 23 All notifications and accompanying forms must be sent to us marked for the attention of the Enware Australia Pty Except as provided or referred to in this document, we Limited, 9 Endeavour Road, Caringbah NSW 2229. We...
