Summary of Contents for Newland EM3080-W
- Page 1 SCANNING MADE SIMPLE EM3080-W OEM scan engine integration guide...
- Page 3 All pictures in this manual are for reference only and actual product may differ. Regarding to the product modification and update, Fujian Newland Auto-ID Tech. Co., Ltd. reserves the right to make changes to any software or hardware to improve reliability, function, or design at any time without notice. The information contained herein is subject to change without prior notice.
- Page 4 Revision History Version Description Date V1.0.0 Initial release. July 3, 2018...
-
Page 5: Table Of Contents
Table of Contents Chapter 1 Introduction ............................1 Overview ................................1 Illumination ............................... 1 Chapter 2 Installation ............................2 General Requirements ............................. 2 ESD ................................2 Dust and Dirt ..............................2 Ambient Environment ........................... 2 Thermal Considerations ..........................2 Installation Orientation ..........................3 Optics ................................ - Page 6 Timing Sequence ............................. 9 Chapter 4 Interfaces ............................10 Host Interface Connector ..........................10 Dimensions of the Host Interface Connector (unit: mm) ................11 FFC Cable (unit: mm) ..........................11 Communication Interfaces ..........................12 Control Interfaces ............................13 Trigger ................................ 13 Beeper ................................
-
Page 7: Chapter 1 Introduction
Support all mainstream 1D and 2D barcodes. Convenient configuration through scanning barcodes. Outstanding near-field reading and wide viewing angle Illumination The EM3080-W has a white LED for supplementary lighting. The illumination can be programmed On or Off. -
Page 8: Chapter 2 Installation
Chapter 2 Installation General Requirements ESD protection has been taken into account when designing the EM3080-W and the engine is shipped in ESD safe packaging. Always exercise care when handling the engine outside its package. Be sure grounding wrist straps and properly grounded work areas are used. -
Page 9: Installation Orientation
The figure below illustrates a front view of the EM3080-W after installation, with the engine’s decoder board on the top, and illumination and lens on the front. The EM3080-W installed in this manner allows its lens to be seen from the outside. -
Page 10: Window Material And Color
Window Material and Color CIS’s responsiveness (mainly to wavelengths of white light）should be taken into consideration when choosing window material and color, in order to achieve the possible highest spectral transmission, lowest haze level and homogeneous refractive index. It is suggested to use PMMA or optical glass with spectral transmittance over 90% and haze less than 1%. -
Page 11: Ambient Light
Eye Safety The EM3080-W uses LED to create the illumination beam. The LED is bright, but testing has been done to demonstrate that the engine is safe for its intended application under normal usage conditions. However, the user should avoid looking into the beam. -
Page 12: Mounting
Mounting The illustrations below show the mechanical mounting dimensions for the EM3080-W. The structural design should leave some space between components. Front View (unit: mm) Left View (unit: mm) -
Page 13: Bottom View (Unit: Mm)
Bottom View (unit: mm) -
Page 14: Chapter 3 Electrical Specifications
Chapter 3 Electrical Specifications Power Supply Do not power up the EM3080-W until it is properly connected. Be sure the power is cut off before connecting a flexible cable to or disconnecting a flexible cable from the host interface connector. -
Page 15: Operating Current
Operating Current ，V Ta=23 ℃ =3.3V Operating Current Sleep Current Unit 55.1 (typical) 100.5 (max.) Timing Sequence The following diagram indicates the typical timing for the Power-up sequence of the engine. Notes: 1. In the diagram above, A shows the time it takes for the engine to power up. 2. -
Page 16: Chapter 4 Interfaces
Chapter 4 Interfaces Host Interface Connector The following table lists the pin functions of the 12-pin host interface connector on the EM3080-W. PIN# Signal Function Not connected. 3.3V power supply. Power-supply ground. TTL level 232 receive data. TTL level 232 transmit data. -
Page 17: Dimensions Of The Host Interface Connector (Unit: Mm)
Dimensions of the Host Interface Connector (unit: mm) The EM3080-W uses a 12-pin ZIF connector (bottom contact). This connector can be connected to a host device with an FFC cable. FFC Cable (unit: mm) A 12-pin FFC cable (contacts on the same side or on opposite sides) can be used to connect the EM3080-W to a host device. -
Page 18: Communication Interfaces
USB COM Port Emulation: The USB port on the host device is emulated as a serial port with the same data transmission and configuration as a real serial port. A driver is required. USB DATAPIPE: This protocol is defined by Newland. A driver is required when using this protocol to communicate with the engine. ... -
Page 19: Control Interfaces
Control Interfaces Trigger Driving the TRIG pin (PIN 12) on the host interface connector low for over 10ms causes the EM3080-W to start a scan and decode session. If a barcode is decoded, the EM3080-W waits for the voltage at the TRIG pin to turn high (or the trigger to be released) after sending the data to the Host. -
Page 20: Beeper
Beeper The EM3080-W provides a pin (BUZZ, PIN 9) on the host interface connector that provides a PWM output to an external driver circuit for generating audible feedback to the user to indicate statuses like power up or good read. The PWM output is not strong enough to drive a beeper, thus a beeper driver circuit is needed. -
Page 21: Chapter 5 Development Tools
The EVK is provided to help users to test and evaluate the EM3080-W, which contains beeper & beeper driver circuit, LED & LED driver circuit, trigger & reset buttons, TTL-232 to RS-232 converter & TTL-232 to USB converter, RS-232 &... - Page 22 SCANNING MADE SIMPLE D-A-C-H United Kingdom France Russia Newland EMEA HQ +31 (0) 345 87 00 33 +49 (0) 6182 82916-16 +44 (0) 1442 212020 +39 (0) 345 8804096 +31 (0) 345 87 00 33 info@newland-id.com info@newland-id.de sales@newland-id.co.uk france@newland-id.com russia@newland-id.com newland-id.com...
