- Page 1 Instruction Manual Audi 4G+ PAS TDC2 for AUDI , Q7...
-
Page 2: Table Of Contents
INDEX Specifications Main Spec. ---------------------------------- Diagram ------------------------------------- Components -------------------------------- Components (Option) ---------------------- Exterior -------------------------------------- Settings Dip Switch ---------------------------------- Original button ----------------------------- Touch Control ------------------------------ OSD Menu ---------------------------------- Installation CAN Connection ---------------------------- Caution -------------------------------------- GU Electronic... -
Page 3: Specifications
- Possible to switch input mode through original button 2. Features Possible to install capacitive touch screen with frame (Option) Possible to register IR code of DVD/DTV Display dynamic PAS(Parking assistance system) Easy installation with plug & play power/LVDS cable GU Electronic... -
Page 4: Diagram
Specification 3. Diagram INTERFACE LVDS COMMAND SYSTEM EEPROM RECEIVER LVDS DIGITAL RGB Scaler LVDS RELAY (PIP) RGB+Sync REAR CAMERA REAR CAMERA POWER TFT-LCD LVDS GU Electronic... -
Page 5: Components
Specification 4. Components RGB Navi Cable 1EA Power Cable 1EA Touch Cable(KD-900) 1EA LVDS Cable 1EA GU Electronic... -
Page 6: Components (Option)
Specification 4. Components (Option) Q7 8.2” Plastic Bracket ① ② Q7 8.2” Capacitive Touch Screen ①: remove the protective plastic ②: replace the OEM bracket with the Provided bracket A4 8.2” Capacitive Touch Screen Touch Cable Touch Board GU Electronic... -
Page 7: Exterior
② G DATA (Green) ② REAR_POWER (Red) ③ B DATA (Blue) ③ CAN-HIGH (Orange) ④ SYNC (White) ④ CAN-LOW (Green) ⑤ GND (Black) ⑤ CAN-HIGH (Purple) ⑥ DMB IR (Green) ⑥ CAN-LOW (White) ⑦ DVD IR (Orange) ⑦ GND (Black) GU Electronic... -
Page 8: Settings
ON : AUDI A4 / Q7 8.2 “ Car model ON : AUDI A4 / Q7 8.2 “ OFF : AUDI A4 / Q7 8.2 “ * Example AUDI A4 / Q7 8.2 “ ※ Both of DTV(A1) and DVD(A2) are through Front input GU Electronic... -
Page 9: Original Button
Steering wheel - 1 Steering wheel - 2 (Switching mode ) (Switching mode) ※ It is necessary to connect CAN wire to use the original button ※ You can choose the Steering wheel type from the OSD Menu (p.15) GU Electronic... -
Page 10: Touch Control
- Touch calibration Touch the OEM screen in any mode more Touch the “+” correctly than 7sec. for calibration (This function can be activated only one time after switching mode) - DVB-T/DVD Control Press Touch (Anywhere) Press Icon DVB-T GU Electronic... - Page 11 [Play/Pause] [DISC UP] [stop] [DISC DOWN] [Audio] [Play next [FR] chapter] [Play previous [FF] chapter] ※ To use this function, It is necessary to offer the remote IR code to manufacturer or setting OSD IR – Ctrl（P. 20） GU Electronic...
- Page 12 ④ Moving from third menu to first menu in order ⑤ Moving from first menu to third menu in order ⑥ Moving up, Increasing value ⑦ Moving down, Decreasing value Mode state Second menu Third menu First menu GU Electronic...
-
Page 13: Osd Menu
※ Press “MENU” button on Key board Config - NAVI-RGB : Setup for the type of RGB Config - DVB-T(DMB) : Setup for the type of DVB-T(DMB) Config - DVD : Setup for the type of DVD Reset : Reset all value GU Electronic... - Page 14 AV Mode : When the “REAR TYPE” is OEM • ON : Using the “Rear input” as AV3 OFF : Not used FrontCam-Type : Setup for front camera • ExtDevice - External rear camera OEM - Original carmer GU Electronic...
- Page 15 FrontCam-RcvOpt : Selecting time of displaying Front camera before switching to RGB, • DVD, OEM from Rear NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) Select time of display AV2(DVD) AV2(DVD) 1~30 second SteeringMode : Setting Handle wheel button (Refer.9) • ON- MODE or NAV OFF- OFF GU Electronic...
- Page 16 Settings 3. OSD Menu ※ Press “MENU” button on Key board - NAVI(RGB) Image / Screen - DVD, DVBT, NAVI-AV, REAR, FRONT Image GU Electronic...
- Page 17 1. OEM type : When switching to “D” gear from “R” gear , Press the “P“ button or drive up 20km to display AV/RGB/OEM screen 2. Normal type : When switching to “D” gear from “R” gear, The AV/RGB/OEM screen is shown right away GU Electronic...
- Page 18 OEM Button in Horizontal / Vertical menu ※ Pressing this Horizontal / Vertical menu, The OSD screen automatically disappears. Please adjust from the parking line Screen. Left Right Down - Transparency – Setting to the transparency of Parking guide line GU Electronic...
- Page 19 • OSD – Transparency • OSD – Language : Setting language of ODS menu • - IR – Ctrl (p.20) - Utility MENU Utility Factory Reset Execute Cancel IR-Ctrl Version ADPc10KRX - 170409 Utility Utilityy– INTERFACE SOFTWARE • GU Electronic...
- Page 20 ③ Press a button on the remote control separately of DVD/DTV then the IR code will be appeared on “New code” menu. Press the same button one more time to confirm the IR code. (Cfm code = confirm code) GU Electronic...
-
Page 21: Installation
Installation 1. CAN installation ① Please remove the indicated grey connector from the OEM plug & plug connector ② Please connect the OEM grey connector to the provided connector in the direction of the protruding portion GU Electronic... -
Page 22: Can Connection
LVDS cable must be connected correctly according to the manual • Insulate the end of wire by using electrical tape • The installation should be done by expert • GU electronic does not take any responsibility for any problem • caused by wrong installation... - Page 23 GU Electronic For your better driving...
