- Page 1 Operating Manual Alarm Unit Type M2118 Mostec AG Tel. + 41 61 921 40 90 Mess- und Regeltechnik + 41 61 921 40 83 Lausenerstrasse 13a Internet www.mostec.ch CH-4410 Liestal, Switzerland E-Mail info@mostec.ch...
- Page 2 Technical description The alarm unit M2118 is used to check or control any type of signal current or voltage signal. It converts the input signal to an internal standard signal of for example 0 to 100.0%. In this range two alarm contacts can be set independently.
- Page 3 <+> and <-> and confirm with the <ENTER> key. If the code is wrong, the instrument quits the user menu (in case you do not know your code any more, call MOSTEC we have a unlock code). If the code is correct, it can be modified with the keys <+>...
- Page 4 Connect the link cable with Adapter to the Computer and the display. (see I, page 6) 1. start "Mpro" 2. Choose "M2118" in menu "Instrument" <A> 3. Choose "Linear conversion table" under "Range" <B> 4. Choose "Adjust the limit contacts" <C>...
- Page 5 F. Adjusting the output signal range with programming software Connect the link cable with the Computer and the display. (see I, page 6) 1. start "Mpro" 2. Choose "M2118" in menu "Instrument" <A> 3. Choose "Linear conversion table" under "Range" <B> 4. Choose "Adjust the output signal" <D>...
- Page 6 Contact us if there are problems or questions concerning the software. Non-liability The company Mostec AG developed and tested the software "Mpro" with largest care. Mostec is not responsible for any damages whatsoever, including loss of information, interruption of business, personal injury and/or any damage or consequential damage without limitation, incurred before, during or after the use of our products.
-
Page 7: Technical Data
Pressure control: Dimensions (mm): Supply SP1 95% Transmitter · to over pressure · ® valve · M2118 SP2 10% · · Output to pump · (SP = Setpoint) Analog instrument, recorder, or process computer V1.06 © 17.10.2011 MOSTEC AG, CH-4410 Liestal... - Page 8 Fine-adjust current output max. value 0000 ß(ESC)/(ENT) â (+) / á (-) àtARe (ENT)à (+)/(-) Adjust tare on / off ß(ESC)/(ENT) Leave the menu without saving the value Leave the menu and save the value V1.06 © 17.10.2011 MOSTEC AG, CH-4410 Liestal...
