- Page 1 U S E R G U I D E BGAN Installation & antenna orientation How to prepare the Orbit, Moxa & BGAN modem How to install and pre-orientate the BGAN Antenna How to fine adjust the BGAN antenna Summary How to configure BGAN communication in Atlas Tests in case of not being able to communicate &...
- Page 2 3. Verify that BGAN SIM card is activated correctly including data plan. HOW TO INSTALL AND PRE-ORIENTATE THE BGAN ANTENNA The BGAN system operates with a directional antenna which means that the orientation of the antenna is crucial for its opera- tion and good coverage.
- Page 3 12. In the lower part of the STATUS box (indicated as Pointing Info as shown below) you can find the recommended orienta- tion and inclination of the BGAN antenna. Now screw on the support boom to the mast according to this orientation and incli- ne the BGAN antenna as indicated.
- Page 4 1. Now disconnect the ethernet cable from your PC and plug it back into the Moxa Nport. 2. Power on the BGAN modem. 3. The BGAN LEDs carry out a startup sequence that lasts 25-30 seconds. Wait until the Power LED on the front panel starts blin-king with the other two LEDs off.
- Page 5 BGAN antenna and therefore to the satellite coverage signal. It is recommended to leave the BGAN antenna screwed onto the support boom with a value of 2,5 V or more for an optimal connection and never less than 2 V.
- Page 6 There are two different points to test: A. Moxa NPORT 5110 - Orbit data logger To test the communication with the data logger through a Moxa, previously configured for working with a BGAN, the following steps must be carried out: 1.
- Page 7 BGAN SATELLITE | INSTALLATION & ANTENNA ORIENTATION 3. Open a web browser and type the IP address of Moxa (192.168.128.101). With this we should see the Moxa configuration page. * In other case, we should check the Moxa configuration. To check it, use the software ‘NPort Administrator’ This software must be ALWAYS opened as an administrator.
- Page 8 ATTENTION: Doing this only in the case of communication problems, data consumption implied. - Make sure that the SIM is active. - Make sure that the IP from which you are trying to connect to the BGAN has permission in the Firewall to make the com- munication.
