Page 2: Important Safety Information
WARNING! Avoid serious injury from falling or sliding out. Always use Restraint System. Your child's safety depends on you. Proper stroller use cannot be assured unless you follow these instructions. DO NOT USE STROLLER UNTIL YOU READ AND UNDERSTAND THESE INSTRUCTIONS. IMPORTANT SAFETY INFORMATION How to Keep Your Child Safe While Using this Stroller ADULT ASSEMBLY REQUIRED. - Page 3 Parts List Stroller Handle Parent Tray Stroller Frame Basket Tube Washers (2) Brake Assembly with Rear Axle Rear Wheels (2) Front Wheels (2) Cotter Pins (2) Front Bars Hub Caps Screws (6) Reversible Seats Pins (2)
- Page 4 HOW TO ASSEMBLE YOUR STROLLER To Open Stroller 1. Remove any cardboard inserts or plastic ties used to protect the product during shipment. 2. Release the locking latch on the Stroller Frame. 3. Unfold to full open position. 4. Remove the sticker from the Front Wheel Assembly. Remove and discard both screws from the Front Wheel Assembly.
- Page 5 To Attach Basket 1. Align the Basket Tube with the Basket Frame in the rear of the stroller as shown. 2. Press in spring loaded buttons on Basket Tube and slide into the Basket Frame until both buttons click into place.
- Page 6 To Attach Stroller Handle 1. Slide the Stroller Handle down to the stroller frame until the holes on each side of the Stroller Handle can be seen in the frame. 2. Secure the Stroller Handle with a screw on each side of the frame.
- Page 7 To Attach Front Wheels 1. Align Front Wheel as shown. 2. Push Front Wheel up into the Front Wheel Assembly until a “Click” is heard. 3. Repeat for other wheel. Tug firmly on each wheel assembly to be sure wheels are securely in place.
- Page 8 3. Push both brake assemblies onto rear leg tubes at the same time until spring loaded buttons click into place. NOTE: If brake assemblies do not click and hold in place, the spring button may be stuck, not protruding through the hole in the tube. Use a screwdriver or pliers to move the button so that it protrudes out of the hole in the tube.
- Page 9 To Attach Reversible Seats WARNING When using this product with only one child, only use the E seat position. Reversible Seats can be positioned in these directions: A. Facing Parent B. Facing Away from Parent C. Facing Each Other D. Back to Back E.
- Page 10 To Attach Front Bars CAUTION To prevent injury to your child, take care when inserting bar into frame. 1. Align Front Bar pins over the holes on the Seat Catch and push in until a “Click” is heard on both sides. Repeat this step for other Front Bar.
- Page 11 HOW TO PROPERLY USE YOUR NEW STROLLER To Operate Brakes 1. Push levers on both rear wheels down to lock. 2. Pull levers up to unlock. To Secure child in Stroller Seat WARNING Avoid serious injury from child falling or sliding out. Always use restraint system. Do not use product without full 5 point Harness Restraint.
- Page 12 To Adjust Shoulder Strap Height NOTE: For a secure fit, straps should be at or below the child’s shoulder. Adjust straps to higher positions as your child grows. 1. To readjust shoulder restraints, unbuckle the back of the seat and push the buckle back through 2.
- Page 13 To Install Infant Neck Roll Infant neck roll is to be used with newborns who can not hold their head up. It should be used only when the seat is reclined. It can be removed when a child can hold their head up unassisted. When using the infant neck roll, be sure that the shoulder restraint straps are fed through the holes on either side.
- Page 14 1. To recline seat, pull adjustment bar located on the top of the seat to one of 4 positions: • Upright • Middle (2 positions) • Full Recline NOTE: For both seats to recline fully, the seats are best positioned when facing parent or facing away from parent.
- Page 15 To Fold Stroller 1. Lock the brakes. 2. For the tightest fold, either: a) Remove rear seat facing the handle. OR b) Remove front seat and make sure Rear Seat is facing forward. 3. Close canopy. 4. Pull up on triggers and push stroller handle forward slightly.
- Page 16 7. Remove Reversible Seat restraint straps from pockets in basket. 8. Place the removed seat facing other seat and tuck it in front of the tray. Secure it with the belts to keep it in place. Make sure that the belts are secure especially when using to travel.
- Page 17 Thank you for choosing Dream On Me and congratulations on joining The DOM Family, a family that has been transforming lives for 30 years! We appreciate your feedback and wish you the very best in the coming years with your new addition. If you have any questions or concerns please don’t hesitate to reach out and a...
