Summary of Contents for Northern Tool and Equipment Ironton 75429
- Page 1 2-in-1 Air Operated Grease Gun Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #75429 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Grease Gun ........................7 Assembly Instructions .......................... 7 Before Each Use ............................ 9 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Ironton 2-in-1 Air Operated Grease Gun is a manual lever or air operated grease gun with 16 oz. lubricant capacity. Packaging Contents • • • 1/4" NPTF I/M Type Quick Main Housing Manual Handle Coupler • • •... - Page 5 this equipment for a purpose for which it was not intended. • Industrial or commercial applications must follow OSHA requirements. ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury.
-
Page 6: Specific Operation Warnings
⚠CAUTION GREASE GUN USE AND CARE • Do not force the grease gun. Products are safer and do a better job when used in the manner for which they are designed. Plan your work and use the correct product for the job. •... -
Page 7: Main Parts Of Grease Gun
Main Parts of Grease Gun Subassembly Main Housing Connector Rigid Coupler Assembly or Flexible Hose Assembly Tube Container Manual Handle Assembly Instructions Page 7 of 19... - Page 8 Pneumatic Use Assembly • Attach the flexible hose or rigid coupler to the main housing. See Figure 1. Figure1 • Insert the tube container into the main housing. See Figures 2 and 3. Figure 2 Figure 3 Manual Lever Grease Gun Assembly •...
-
Page 9: Before Each Use
• Attach the manual handle (#24) to the tube container (#19). See Figure 5. Figure 5 The completed assembly is shown below in Figures 6 and 7. Figure 6 Figure 7 Before Each Use ⚠WARNING • Disconnect from air supply before changing accessories or servicing. Before each use, prime the grease gun by following the Operation Instructions until grease flows from the tip (#10a). -
Page 10: Operating Instructions
Operating Instructions ⚠WARNING • Always wear the proper protective equipment, including ANSI Z87.1 compliant eye protection. • High Pressure Fluid Hazard. Do not use a hose pressure rating that is less than the grease gun. • Do not exceed the max pressure of 6000 PSI. •... - Page 11 Air System Layout ○ ○ 1 Air grease gun 9 Drain Daily ○ ○ 2 Air Hose 3/8” (I.D.) 10 1/2” or Larger Pipe and Fitting ○ ○ 3 Oiler 11 Air Dryer ○ ○ 12 1” or Larger Pipe and Fitting 4 Pressure Regulator ○...
- Page 12 • Remove the cap and/or lid from both ends of the cartridge (not included). Insert the cartridge into the tube container in the orientation indicated on the cartridge. Make sure that the cartridge is as far in as possible. See Figures 10 and 11. Figure 10 Figure 11 •...
- Page 13 Filler Pump Loading Refer to Figure 15. • Pull back on the tube handle (#22) until it is fully extended. Lock it into place with the locking plate (#23). • Insert the filler plug on the end of the hose of a filler pump (not included) into the fill nozzle (#12) of the grease gun.
-
Page 14: After Each Use
Using the Manual Grease Gun This air-powered grease gun can be used as a manual grease gun with the manual handle. • Remove the gun body from the tube container by turning it counter-clockwise. See Figure 18. • Fill the tube container with grease by following the Grease Loading instructions. •... -
Page 15: Troubleshooting
Maintain the grease gun by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. Keep your grease gun in good repair. Keep handles dry, clean, and free from oil and grease. -
Page 16: Parts Diagram
Parts Diagram Parts List Part Number Part Description Quantity Main housing Air inlet Trigger assembly Trigger Set screw Piston assembly Spring Front housing Connecter Rigid coupler assembly Flexible hose assembly Air vent valve Fill nozzle Gasket Lock nut Washer Plunger Backlash gasket Spring Tube container... -
Page 17: Replacement Parts
Replacement Parts • For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. •... -
Page 18: Limited Warranty
Limited Warranty Northern Tool and Equipment Company, Inc. ("We'' or ''Us'') warrants to the original purchaser only (''You'' or ''Your'') that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 19 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 19 of 19...
