- Page 1 MOBILE SHOTBLASTER HORNET OWNER’S MANUAL AND PARTS BOOK www.BARTELLGLOBAL.com Doc. # OIPB-C Orig. Rel. – 11/2018 Curr. Rev. - 00...
- Page 2 OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL This Page Left Intentionally Blank...
- Page 3 No part of this work may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or by any information storage or retrieval system without the prior written permission of Bartell Morrison Inc. unless such copying is permitted by federal copyright laws.
- Page 4 OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL SAFETY PRECAUTIONS DANGER EXPLOSION HAZARD Never operate the machine in an explosive atmosphere, near combustible materials, or where ventilation does not clear exhaust fumes. WARNING BURN HAZARD Never come into contact with the engine or muffler when engine is operating or shortly after it is turned off.
-
Page 5: Table Of Contents
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL TABLE OF CONTENTS QUALITY ASSURANCE/ MACHINE BREAK IN WARRANTY INFORMATION SPECIFICATIONS PREVENTATIVE MAINTENANCE AND ROUTINE SERVICE PLAN o ROUTINE SERVICE SCHEDULE o ROUTINE SERVICE INTERVALS OPERATING SAFETY PRECAUTIONS OPERATION INSTRUCTIONS o SETTING UP YOUR SHOT BLASTER o OPERATION o ADJUSTING THE BLAST TRACK o BLAST WHEEL AND SHOT CAGE INSPECTION... -
Page 6: Quality Assurance/ Machine Break In
(12) months from date of purchase, provided that notice of such defective part or portion thereof is given to Bartell Ltd. within the twelve month warranty period. No further or other guarantee or warranty expressed or implied in connection with the sale of the Shot Blaster is given and our sole liability consists in replacing defective parts or portions thereof. -
Page 7: Specifications
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL SPECIFICATIONS HORNET Dimensions Working Width, mm (in) 200 (8) Overall Width, mm (in) 315 (12.6) Overall Length, mm (in) 73-78 (29.2-31.2) Overall Height, mm (in) 100-108 (40-43.2) Weight Weight, kg (lb) 51 (113) Power Source Power kw (HP) 2.1 (2.9) -
Page 8: Preventative Maintenance And Routine Service Plan
However, when in need of parts or major service be sure to see your Bartell dealer. For your convenience, we have provided this space to record relevant data about your Shot Blaster. When in need of parts or service be prepared to provide your Shot Blaster serial number. -
Page 9: Routine Service Schedule
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL ROUTINE SERVICE SCHEDULE Each 3 Each 6 Each 9 Each 12 After 1.5 Each months months months months Routine Service Intervals months or 100 or 200 or 300 or 400 or 50 hrs General Inspection Guards Check... -
Page 10: Operating Safety Precautions
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL OPERATING SAFETY PRECAUTIONS The HORNET Shot Blasters are constructed according to existing safety rules and regulations. These technical precautions should not be removed or changed under any circumstances. While operating the machines the following points should also be kept in mind: The instructions provided in this manual are done so to ensure the operator’s safety as well as that of others, the equipment, and the job site. -
Page 11: Operation Instructions
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL OPERATION INSTRUCTIONS SETTING UP YOUR SHOT BLASTER Your Hornet Shot Blaster comes fully assembled with handle and motor fully installed. Transport the HORNET® and the Dust Collector to the floor which is to be blasted. Shot can now be loaded, and your Shot Blaster is ready for use. -
Page 12: Adjusting The Blast Track
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL After a few meters of blasting close the shot valve and stop the machine. Check the track on the floor. If the track is not evenly blasted, adjust the position of the shot cage as described in the “Adjusting the Blast Track”... - Page 13 OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL This Page Left Intentionally Blank...
-
Page 14: Parts List - Hornet Shot Blaster
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL PARTS LIST – HORNET SHOT BLASTER... -
Page 15: Hornet Shot Blaster - Parts List
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL HORNET SHOT BLASTER – PARTS LIST Item # Part # Description Remarks 8730121200 Blast Chamber 8730121300 Reclaim Chamber 8730151702 Shot Cage 8761330001 Washer 8780206260 Rear Caster 8730110700 Brush Front / Back 8730110701 Brush Left / Right 8730110600 Magnetic Frame... - Page 16 OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL 8790215017 Handle inclined 8730100101 Sieve 8750201020 Power Limiter 115V 8730111200 Cooling block 8730111201 Cover 870542812 Hose Clamp...
-
Page 17: Electrical Diagram - Hornet Shot Blaster
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL ELECTRICAL DIAGRAM – HORNET SHOT BLASTER... -
Page 18: Trouble Shooting
OIPB – C HORNET SHOT BLASTER OWNER’S MANUAL TROUBLE SHOOTING The turbine motor is not working. Has the blast chamber filled with shot and blocked the blast wheel during transportation of the machine? Is the power connection correct? (230V, single phase or 400/460V three phase) Is the motor overload protection tripped? (The turbine switch is also the overload protection) Are the cables in good condition and properly laid? The blast performance is too low. -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Declaration of Conformity / Certificat de conformité / Gelijkvormigheids certificaat Declaración de Conformidad/Declaração de Conformidade/Dichiarazione Di Conformita Bartell Morrison Inc. Bartell Morrison (USA) LLC. 170 Traders Blvd. E 200 Commerce Drive, Unit A Mississauga, Ontario, Canada Freehold, New Jersey, United States of America...
